Chapter 3: Using Classes and Objects 35

Chapter 3: Using Classes and Objects

Lab Exercises

Topics Lab Exercises

String Class

Prelab Exercises

Working with Strings

Random Class Rolling Dice

Math Class Computing Distance

Wrapper Classes Experimenting with the Integer Class

Panels Nested Panels

36 Chapter 3: Using Classes and Objects

Prelab Exercises

Sections 3.2-3.5

These exercises focus on the String, Random, and Math classes defined in the Java Standard Class Library. The main

concepts are in the text in sections 3.2-3.5. The goals of the lab are for you to gain experience with the following concepts:

• Declaring a variable to be a reference to an object—for example, the following declares the variable quotation to be a

reference to a String object:

• Declaring a variable to be a reference to an object and creating the object (instantiating it) using the new operator—for

example,

• Invoking a method to operate on an object using the dot operator—for example,

invokes the length method which returns the length of the quotation String or

quotation except all letters are lower case. These invocations would be used in a program in a place appropriate for an

integer (in the first case) or a String (in the second case) such as an assignment statement or a println statement.

• Invoking static or class methods—these are methods that are invoked using the class name rather than an object name.

The methods in the Math class are static methods (basically because we don’t need different instances of Math whereas

there are lots of different String objects). Examples are

and

• Importing the appropriate packages—usually when you use classes from a library you need to put the import declaration

Chapter 3: Using Classes and Objects 37

Exercises

1. Fill in the blanks in the program below as follows: (Section 3.2, especially the example in Listing 3.1, should be helpful):

(a) declare the variable town as a reference to a String object and initialize it to “Anytown, USA”.

(b) write an assignment statement that invokes the length method of the string class to find the length of the college

String object and assigns the result to the stringLength variable

(d) complete the assignment statement so that change2 is the same as change1 except all capital O’s are replaced with

the asterisk (*) character.

(e) complete the assignment statement so that change3 is the concatenation of college and town (use the concat method

of the String class rather than the + operator)

// **************************************************

// StringPlay.java

________________________________________________________; // part (a)

int stringLength;

String change1, change2, change3;

}

2. The following program should read in the lengths of two sides of a right triangle and compute the length of the

hypotenuse (recall that the length of the hypotenuse is the square root of side 1 squared plus side 2 squared). Complete it

by adding statements to read the input from the keyboard and to compute the length of the hypotenuse (you need to use a

Math class method for that).

38 Chapter 3: Using Classes and Objects

// *******************************************************************

// RightTriangle.java

public class RightTriangle

{

public static void main (String[] args)

Scanner scan = new Scanner(System.in);

————————————————————-;

// Compute the length of the hypotenuse

————————————————————-;

}

3. In many situations a program needs to generate a random number in a certain range. The Java Random class lets the

programmer create objects of type Random and use them to generate a stream of random numbers (one at a time). The

following declares the variable generator to be an object of type Random and instantiates it with the new operator.

The generator object can be used to generate either integer or floating point random numbers using either the nextInt

method (either with no parameter or with a single integer parameter) or nextFloat (or nextDouble) methods,

respectively. The integer returned by nextIn(t could be any valid integer (positive or negative) whereas the number

returned by nextInt(n) is a random integer in the range 0 to n-1. The numbers returned by nextFloat() or nextDouble()

are floating point numbers between 0 and 1 (up to but not including the 1). Most often the goal of a program is to

generate a random integer in some particular range, say 30 to 99 (inclusive). There are several ways to do this:

• Using nextInt(): This way we must use the % operator to reduce the range of values—for example,

will return numbers between 0 and 69 (because those are the only possible remainders when an integer is divided by

70 – note that the absolute value of the integer is first taken using the abs method from the Math class). In general,

using % N will give numbers in the range 0 to N -1. Next the numbers must be shifted to the desired range by

adding the appropriate number. So, the expression

Math.abs(generator.nextInt()) % 70 + 30

will generate numbers between 30 and 99.

Chapter 3: Using Classes and Objects 39

• Using nextInt(70): The expression

will return numbers between 0 and 69 (inclusive). Next the numbers must be shifted to the desired range by adding

the appropriate number. So, the expression

will generate numbers between 30 and 99.

• Using nextFloat: In this case, we must multiply the result of nextFloat to expand the range—for example,

returns a floating point number between 0 and 70 (up to but not including 70). To get the integer part of the number

we use the cast operator:

The result of this is an integer between 0 and 69, so

shifts the numbers by 30 resulting in numbers between 30 and 99.

The method nextFloat can be replaced by nextDouble to get double precision floating point numbers rather than

single precision.

Fill in the blanks in the following program to generate the random numbers as described in the documentation. NOTE

that that java.util.Random must be imported to use the Random class.

// **************************************************

// LuckyNumbers.j ava

{

Random generator = new Random();

int lucky1, lucky2, lucky3;

// Generate lucky1 (a random integer between 50 and 79) using the

Working with Strings

The following program illustrates the use of some of the methods in the String class. Study the program to see what it is

doing.

// ***************************************************************

// StringManips.j ava

// Test several methods for manipulating String objects

// ***************************************************************

phraseLength = phrase.length();

middleIndex = phraseLength / 2;

// get the substring for each half of the phrase

firstHalf = phrase.substring(0,middleIndex);

secondHalf = phrase.substring(middleIndex, phraseLength);

1. Declare a variable of type String named middle3 (put your declaration with the other declarations near the top of the

program) and use an assignment statement and the substring method to assign middle3 the substring consisting of the

2. Add an assignment statement to replace all blank characters in switchedPhrase with an asterisk (*). The result should be

3. Declare two new variables city and state of type String. Add statements to the program to prompt the user to enter their

hometown—the city and the state. Read in the results using the appropriate Scanner class method – you will need to have

the user enter city and state on separate lines. Then using String class methods create and print a new string that consists

Chapter 3: Using Classes and Objects 43

Rolling Dice

Write a complete Java program that simulates the rolling of a pair of dice. For each die in the pair, the program should

generate a random number between 1 and 6 (inclusive). It should print out the result of the roll for each die and the total roll

Computing Distance

The file Distance.java contains an incomplete program to compute the distance between two points. Recall that the distance

between the two points (x1, y1) and (x2, y2) is computed by taking the square root of the quantity (x1 – x2)2 + (y1 – y2)2. The

program already has code to get the two points as input. You need to add an assignment statement to compute the distance

and then a print statement to print it out (appropriately labeled). Test your program using the following data: The distance

between the points (3, 17) and (8, 10) is 8.6023… (lots more digits printed); the distance between (-33,49) and (-9, -15) is

68.352.…

// ************************************************************

// Distance.java

// Computes the distance between two points

// ************************************************************

Chapter 3: Using Classes and Objects 45

Formatting Output

File Deli.java contains a partial program that computes the cost of buying an item at the deli. Save the program to your

directory and do the following:

2. Add the import statements to import the DecimalFormat and NumberFormat classes.

4. Add the statement to declare fmt to be a DecimalFormat object as specified in the comment.

of $4.25 per pound and 41 ounces). Use the formatting object money to print the unit price and total price and the

formatting object fmt to print the weight to 2 decimal places.

***** CSDeli *****

46 Chapter 3: Using Classes and Objects

// ************************************************************

// DeliFormat.java

// Computes the price of a deli item given the weight

// (in ounces) and price per pound — prints a label,

// nicely formatted, for the item.

// ************************************************************

import java.util.Scanner;

public class Deli

{

// —————————————————

// main reads in the price per pound of a deli item

// and number of ounces of a deli item then computes

// the total price and prints a “label” for the item

// —————————————————

// it to format numbers with at least one digit to the left of the

// decimal and the fractional part rounded to two digits.

// prompt the user and read in each input

System. out. println (“Welcome to the CS Deli! ! \n “);

System.out.print (“Enter the price per pound of your item: “);

Playing With Cards

Write a class that defines an enumerated type named Rank with values ace, two, three, four, five, six,

seven, eight, nine, ten, jack, queen, king. The main method should do the following:

1. Declare variables highCard, faceCard, card1, and card2 of type Rank.

3. Print a line, using the highCard and faceCard objects, in the following format:

4. Declare two variables card1 Val and card2Val of type int and assign them the face value of your card1 and card2

5. Print two lines, using the card1 and card2 objects and the name method, as follows:

A two card hand: (print card1 and card2)

Hand value: (print the sum of the face values of the two cards)

48 Chapter 3: Using Classes and Objects

Experimenting with the Integer Class

Wrapper classes are described on pages 138-140 of the text. They are Java classes that allow a value of a primitive type to be

“wrapped up” into an object, which is sometimes a useful thing to do. They also often provide useful methods for

manipulating the associated type. Wrapper classes exist for each of the primitive types: boolean, char, float, double, int, long,

short, and byte.

Write a program IntWrapper that uses the constants and methods of the Integer class (page 140 for a short list, pages 819-820

for a complete list) to perform the following tasks. Be sure to clearly label your output and test your code for each task before

proceding.

1. Prompt for and read in an integer, then print the binary, octal and hexadecimal representations of that integer.

2. Print the maximum and minimum possible Java integer values. Use the constants in the Integer class that hold these

3. Prompt the user to enter two decimal integers, one per line. Use the next method of the Scanner class to read each of

them in. (The next method returns a String so you need to store the values read in String variables, which may seem

Chapter 3: Using Classes and Objects 49

Nested Panels

The program NestedPanels.java is from Listing 3.8 of the text. Save the program to your directory and do the following:

2. Modify the program by adding a third subpanel that is twice as wide, but the same height, as the other two

3. Compile and run the modified program. Again, experiment with resizing the frame and observe the effect on the

components.

4. Now add a statement to the program to set the preferred size of the primary panel to 320 by 260. (What would be the

purpose of this?). Compile and run the program to see if anything changed.

5. Now add another panel with background color blue and size 320 by 20. Add a “My Panels” label to this panel and

then add this panel to the primary panel before adding the other panels. Compile and run the program. What was the

effect of this panel?

// ************************************************************

// NestedPanels.java Author: Lewis/Loftus

// Demonstrates a basic component hierarchy.

// ************************************************************

// ——————————————————–

// Presents two colored panels nested within a third.

// ——————————————————–

public static void main (String[] args)

{

JFrame frame = new JFrame (“Nested Panels”);

frame.setDefaultCloseOperation (JFrame.EXIT_ON_CLOSE);

// Set up first subpanel

JPanel subPanel1 = new JPanel();•

// Set up second subpanel

JPanel subPanel2 = new JPanel();

subPanel2.setPreferredSize (new Dimension(150, 100));

// Set up primary panel

JPanel primary = new JPanel();

frame.getContentPane().add(primary);

frame. pack () ;

frame.setVisible(true);

}
