CCNA Guide to Cisco Networking, Fourth Edition Chapter 6 Lab Solutions
Chapter 6 Lab Solutions
Instructor Tips Lab 6.1
Continue using the lab teams for these labs. It is preferable for the labs in this chapter to
be done in one sitting, as the configurations are not saved.
It is important to make sure students do the Chapter 5 labs correctly before going on to
the Chapter 6 labs. You may want to tell them to make sure they can ping up and down
the routers before they start the chapter 6 labs.
Activity Questions Lab 6.1
5. Global configuration mode.
9. You can refer to routers by name in commands.
10. Should know about all routers since the students should have just configured the ip
host command for each.
12. Interface configuration mode; only this interface.
15. Tells the router to attempt to keep this interface in up/up state.
Review Questions Lab 6.1
1. What mode must you be in to configure IP addresses on a Cisco router?
2. What is the purpose of a host name table?
3. What is the command to point to another router or server for host name resolution?
4. What is the clock rate command used for?
5. What does the no shutdown command do?
Instructor Tips Lab 6.2
Cisco’s TFTP server software is included with the instructor files. It is a single file named
tftpserv.exe. Load this on the Windows computer you will use as the TFTP server and
CCNA Guide to Cisco Networking, Fourth Edition Chapter 6 Lab Solutions
Activity Questions Lab 6.2
7. show run
12. Answer varies, but an example would be c2600-i-mz.123-15b.bin
Review Questions Lab 6.2
1. What is the purpose of a TFTP server?
2. What is the purpose of a default gateway?
3. What prompt and command are used to copy the active configuration to a TFTP
server?
4. What prompt and command are used to copy the IOS to a TFTP server?
5. List two show commands that display the IOS image filename.
Activity Questions Lab 6.3
6. Enter TEXT message. End with the character ‘#’.
19. Hopefully yes.
Review Questions Lab 6.3
1. What is the purpose of the banner command?
2. What does MOTD stand for?
3. What is the purpose of the description command?
4. What mode must you be in to configure a banner?
5. What mode must you be in to configure a description?
Instructor Tips Lab 6.4
In this lab, the students will be telnetting to each other’s routers. There may be an
overwhelming temptation for many to mess around. You may want to warn them not to
reconfigure their teammates’ routers.
Activity Questions Lab 6.4
6. IP address plus IOS version
9. Hopefully yes
12. Hopefully yes; f0/0 interface is not listed in the show command output.
16. Hopefully yes; series of exclamation points; answer varies.
18. It is customized to have a longer repeat count and bigger datagram.
21. Network (3)
23. ICMP
26. Not exactly; it is a vty line password.
30. You can visualize the entire internetwork by telnetting to each router and using the
show cdp neigh command.
32. Application (4)
Review Questions Lab 6.4
1. What is the purpose of the CDP protocol?
2. Is CDP enabled by default on all Cisco routers?
3. What is the difference between ping and extended mode ping?
4. What mode and command are used to disable CDP on an interface?
5. What mode and command are used to disable CDP on the entire router?
Instructor Tips Lab 6.5
Only the person configuring the lab-e router will do Steps 9 through 19, which will
configure the lab-e router to boot from the TFTP server using the IOS that was
previously copied to the server. The other team members should observe the process.
All students will continue configuring their routers in Step 20.
Activity Questions Lab 6.5
7. Answer varies – mine is c2600-i-mz.123-15b.bin; answer varies but is probably
something like 0x2102 (last character will probably be a “2”); flash unless there are
boot system commands to the contrary.
13. The configuration register setting.
24. varies – mine is rommon 1>
Review Questions Lab 6.5
1. What are two ways to control the boot procedure for loading the IOS?
2. What would happen during bootup if the configuration register were set to 0x2101?
3. Why might you want to use a series of boot system commands in your configuration?
Instructor Tips Lab 6.6
No routers are necessary for this lab. All the students need is a Windows computer with
Internet access. This means this lab can be done at home or at workstations other than
the ones connected to the routers.
CCNA Guide to Cisco Networking, Fourth Edition Chapter 6 Lab Solutions
Activity Questions Lab 6.6
16. 2; FastEthernet0/0 10.44.125.76 /24 and FastEthernet0/1 8.8.8.1 /24
19. No DNS lookup; Configure ip-domain-lookup command on the router in CLI mode
22. No; FastEthernet0/1 is down just as the connection test said it was
Review Questions Lab 6.6
1. Can Cisco’s SDM be used to configure everything on a router?
2. What did the SDM do in response to you changing an IP address and why is this
important?
3. The show interfaces CLI command will notify you if an interface is down. What
additional information will the SDM give you regarding the down interface?
