CCNA Guide to Cisco Networking, Fourth Edition Chapter 5 Lab Solutions

Chapter 5 Lab Solutions

The labs in this manual are written for IOS version 12. You can upgrade your routers’

IOS to version 12 if necessary. If you don’t upgrade to version 12, the lab commands will

be slightly different in some cases. The “show version” command displays which IOS

version you are using.

Students will work with their teams. If possible, put no more than five students on a

team. In this way, every student is configuring a router. For these labs, you can use any

Windows computer that has HyperTerminal installed. Windows Vista requires a

download of HyperTerminal. You can get that free from

www.hilgraeve.com/htpe/download.html.

Instructor Tips Lab 5.1

If necessary, use the erase start command to erase the startup configuration on the

routers before students begin this lab.

Activity Questions Lab 5.1

There are no activity questions in this lab.

Review Questions Lab 5.1

1. For what is a transceiver used?

2. This lab connects routers directly to each other via serial cables. Is this a typical

configuration? If not, to what equipment does the DCE end of the serial cable usually

connect?

3. What does a rollover (console) cable look like?

4. What kind of port does the console cable attach to on the computer?

5. What kind of port does the UTP patch cable attach to on the router?

Instructor Tips Lab 5.2

Make sure HyperTerminal is installed on the computers being used to configure the

CCNA Guide to Cisco Networking, Fourth Edition Chapter 5 Lab Solutions

routers. HyperTerminal is not installed by default when you install Windows. It is also not

included with Windows Vista.

Activity Questions Lab 5.2

There are no activity questions in this lab.

Review Questions Lab 5.2

1. What program on a Windows computer is typically used for configuring a Cisco

router?

2. What are the important settings to configure in HyperTerminal to access a Cisco

router?

3. Where is the HyperTerminal program in most Windows computers?

4. Which port on a router do you use to connect the rollover cable when configuring the

router with HyperTerminal?

5. You can use the auxiliary port on a router to access it with HyperTerminal. How

would you be accessing the router if you used this port?

Activity Questions Lab 5.3

1. Answer varies.

3. Answer varies.

5. cisco

15. routername> (answer varies)

16. If you configure both an enable and enable secret password, the enable secret will

Review Questions Lab 5.3

1. When configuring a router, when would you choose basic management setup rather

than extended setup?

2. Which passwords are you prompted for when using the initial configuration dialog?

3. What does the current interface summary show you?

4. How can you break out of setup if you make a mistake?

5. What do square brackets [ ] in a prompt for input indicate?

6. Under what condition are you automatically prompted to enter the initial configuration

dialog?

7. What command and prompt puts you into the initial configuration dialog?

8. Why is it important to configure an enable or enable secret password on a router?

Activity Questions Lab 5.4

3. You only have to type characters until the input is unique and cannot be confused

with another command at that prompt.

6. routername(config-line)# (name varies)

13. All the way back to privileged EXEC mode – routername# (name varies)

18. It copies the running configuration in RAM over the startup configuration in NVRAM.

Review Questions Lab 5.4

1. Which passwords are you not prompted for when using the system configuration

dialog?

CCNA Guide to Cisco Networking, Fourth Edition Chapter 5 Lab Solutions

You are not prompted for the console or aux passwords.

2. Which mode must you be in to configure the VTY, console, and auxiliary passwords?

3. What does the prompt look like if you are in the mode that is the correct answer for

Review Question #2?

4. What two commands are used to create the line passwords after you are at the

prompt you specified in Review Question 3?

5. What is the only router password encrypted by default?

Activity Questions Lab 5.5

2. The console password, which is a type of line password.

6. The show commands available in user EXEC mode.

8. Answer varies but an example would be aaa1346.bin.

12. routername# (name varies)

14. Show commands available in enable mode; Because much information

needs to be protected by a password.

16. Internet Protocol (IP)

18. IP address to MAC address mappings.

20. NVRAM

22. Answer varies.

24. RIP

26. Normally yes; it is the same at the time of bootup, but if you change the

27. The history of commands that have been typed at this prompt since the

28. Shows the previous commands.

30. Moves the cursor to the beginning of the line.

32. Moves the cursor backward one word at a time.

34. Completes the command.

37. Yes, there are more than 10 commands in the buffer; yes.

Review Questions Lab 5.5

1. Within the lab exercise, what exactly did the “?” show you?

2. Is the “?” prompt sensitive?

3. Which two commands display information about the IOS file?

4. What command increases the history size?
