Network+ Guide to Networks, 8th Edition 2-3
3. The next section of the text outlines a tour of the physical network illustrated in Figure 2-
1. Point out that a network begins at the demarcation point in the entrance facility. The
tour covers three stops:
4. Review the components of the tour outlined in the text:
a. Entrance facility
b. demark (demarcation point)
c. MDF (main distribution frame/facility)
d. data room
e. racks
5. Use Figures 2-11 and 2-12 to discuss racks used for attaching devices such as routers,
servers, switches, patch panels, audiovisual equipment, or telephony equipment.
6. Explain to students that rack system provide mounting hardware for network equipment
to optimize the use of square footage in equipment rooms and ensure adequate spacing,
access, and ventilation for these devices.
7. Mention that racks may be wall- or ceiling-mounted, or freestanding on the floor.
8. Explain that racks are measured in rack units (RU or U), with the standard being 42U tall
(6 feet).
10. Use Figure 2-14 to discuss hot aisle/cold aisle rack layout.
11. Discuss the three basic types of cable installations allowed by structured cabling
standards:
12. Use Figure 2-15 to illustrate a horizontal wiring configuration.
13. Use Figure 2-16 to illustrate a cable installation using UTP from the data room to the
