CCNA Guide to Cisco Networking, Fourth Edition Chapter 2 Lab Solutions
Chapter 2 Lab Solutions
Activity Questions Lab 2.1
There are no activity questions in this lab.
Review Questions Lab 2.1
1. Which of the devices that you used in this lab are considered LAN equipment?
2. Which of the devices that you used in this lab are considered WAN equipment?
3. In Figure 2-1, are computers A, B, and C on the same network as D, E, and F?
4. In Figure 2-1, are computers A, B, and C on the same network as G, H, and I?
5. How does the bridge operate to filter traffic between the two attached segments in
your network?
6. In Figure 2-1, how does the router operate to filter traffic between the segments off of
E0, E1, and S0?
7. What kind of domains do bridges and switches create?
8. What kind of domains do routers create?
9. If the LANs in Figure 2-1 are 100-Mbps systems, which computers are sharing this
bandwidth?
2
Activity Questions Lab 2.2
Characteristic
Device(s)
Operates at upper layers to
translate between different
protocol suites
-gateway
Filters traffic based on MAC
address
-bridge
-switch
Introduces the most latency on
a network
-gateway
Boosts the signal but does not
segment the network
–hub
-repeater
Operates differently
depending on whether
nonroutable or routable
protocols are in use
-brouter
Creates broadcast domains
-router
Creates a virtual circuit
between sender and receiver
-switch
Forwards broadcast traffic
-bridge
-switch
-hub and repeater
Filters traffic based on logical
address
-router
-brouter
Associated with the term
“microsegmentation”
-switch
Creates subnetworks
-router
Connects computers in a
physical star and uses “shared
bandwidth”
–hub
CCNA Guide to Cisco Networking, Fourth Edition Chapter 2 Lab Solutions
Creates collision domains
-bridge
-switch
-router
-brouter
Operates at layer 1 of the OSI
model
–hub
Operates at layer 2 of the OSI
model
-bridge
-switch
-brouter
Operates at layer 3 of the OSI
model
-brouter
-router
Review Questions Lab 2.2
1. When is it appropriate to introduce a router into your network?
2. What can bridges do that hubs and repeaters cannot do?
3. When would introducing a brouter on your network be appropriate?
4. What are the advantages and disadvantages of using a gateway on your network?
5. What is the benefit of replacing hubs on your network with switches?
Activity Questions Lab 2.3
2.
Segment
Address
1
2
3
4.
Port
Address
1
MAC of A
CCNA Guide to Cisco Networking, Fourth Edition Chapter 2 Lab Solutions
2
MAC of B
3
MAC of C
4
MAC of D
5
MAC of E
6
MAC of F
7
MAC of G
8
MAC of H
9
MAC of I, J, K, and L
Review Questions Lab 2.3
1. How many collision domains are defined in Figure 2-2?
2. How many collision domains are defined in Figure 2-3?
3. Examine Figure 2-2. If a frame from computer A has a destination MAC address for
computer D, which devices will see the layer 2 information?
4. Examine Figure 2-3. If a frame from computer A has a destination MAC address for
computer D, which devices will see the layer 2 information?
5. Examine Figure 2-3. In terms of network performance, what is the difference
between computers A through H and I through L?
6. What will a bridge and switch do with a frame for which it has no information about
the destination in its table?
7. How do bridges and switches handle broadcast frames?
8. Why is a switch considered more effective than a bridge in terms of increasing
network performance?
CCNA Guide to Cisco Networking, Fourth Edition Chapter 2 Lab Solutions
5
between other nodes on the network segment.
9. In general, how do bridges and switches dynamically create their tables?
10. What happens to tables when bridges and switches are turned off?
Activity Questions Lab 2.4
2. Wireless security standard that replaced WEP and uses the TKIP algorithm WPA
4. This mode specifies that the client device associates with an access point
5. The wireless network name that is often broadcast so that clients can associate using
10. This mode specifies that the client device communicate directly with other client
6
14. Multiple access points connected in infrastructure mode ESS
15. The IEEE standard that specifies 54 Mbps in the 2.4 GHz range 802.11g
16. Organization developed to promote 802.11 usage Wi-Fi Alliance
Review Questions Lab 2.4
1. What is the greatest advantage of using wireless?
2. What is the greatest disadvantage of using wireless?
3. In terms of bandwidth, is an access point more like a switch or a hub? Explain.
4. Which is more efficient and why? CSMA/CD or CSMA/CA?
5. How does a wireless client know which access point to associate with?
