UNIT 57 REVIEW QUESTIONS ANSWER KEY GO BACK TO INDEX

57-1) What factors should be considered when selecting an oil fired furnace?

57-2) What is the proper service clearance that should be allowed when installing a

furnace?

57-3) What is the firing rate of a furnace with a Beckett AFG-FG burner and a 0.75 gph

70-B nozzle? (refer to Table 57-1)

55-4) What is the heating capacity of an 80% efficient furnace with a Beckett AFG-FG

burner and a 0.75 gph 70-B nozzle? (refer to Table 57-1)

57-5) What would be the required vacuum for an oil furnace located 5 feet above the oil

tank with a horizontal run of 20 feet?

57-6) What national standard is a good reference when installing oil furnaces?

57-7) What free air opening would be required for an oil furnace installed in a confined

space if the air was coming through horizontal ducts and the furnace had a Beckett

AFG-FG burner and a 0.65 gph 70-W nozzle? (refer to Table 57-1)

57-8) Calculate the equivalent length of a 6 inch diameter chimney connector with two

57-9) How high must the chimney be above the connector entrance for the connector in

question 8 to operate properly?

57-10) What type of material must be used for chimney connector in a crawlspace?

57-11) Describe where the barometric damper should be installed in the chimney

connector.

57-12) How would the primary control need to differ to accommodate power venting?

57-13) What is a disadvantage to direct venting an oil fired furnace?

57-14) What problems can arise from an oversized oil storage tank?

57-15) How much fuel should a properly sized oil storage tank hold?

57-16) What is the function of an oil safety valve?

57-17) Give a pre-start checklist when checking a newly installed oil furnace.

That the correct nozzle size has been selected for desired input rate.

All shipping supports are removed.

191

Reset button on the primary control is pushed down.

Flame observation door and all cleanout access covers are closed.

The thermostat is set to HEAT at a temperature higher than the room.

57-18) What measurements should be taken when setting up a new oil furnace?

57-19) What national publication is a good reference for chimney construction?

57-20) What types of appliances may oil furnaces be common vented with?
