Mathematics Chapter 7 Homework Alpha Beta Gamma Record

Unlock access to all the studying documents.

View Full Document

Activity Pred

Optim

time (a)

Most likely

time (m)

Pessim

time (b)

Exp

time

Var

Std

dev

EST EFT LST LFT Slack Critical? Critical path =

A – 1.00 2.00 3.00 2.00 0.11 0.33 0.00 2.00 0.00 2.00 0.00 Y Project length = 35.50 days

B – 1.00 1.50 5.00 2.00 0.44 0.67 0.00 2.00 1.00 3.00 1.00 N Project variance = 0.6944

C A 0.50 1.00 1.50 1.00 0.03 0.17 2.00 3.00 2.00 3.00 0.00 Y Project std deviation = 0.8333 days

G E 2.00 2.00 2.00 2.00 0.00 0.00 5.00 7.00 7.00 9.00 2.00 N

I H 2.00 2.50 6.00 3.00 0.44 0.67 8.00 11.00 10.00 13.00 2.00 N

J E 1.00 3.00 5.00 3.00 0.44 0.67 5.00 8.00 5.00 8.00 0.00 Y

K D 2.00 2.00 2.00 2.00 0.00 0.00 4.00 6.00 6.00 8.00 2.00 N

L K, J 1.00 2.00 3.00 2.00 0.11 0.33 8.00 10.00 8.00 10.00 0.00 Y

M L 2.00 2.00 2.00 2.00 0.00 0.00 10.00 12.00 10.00 12.00 0.00 Y

N M 1.00 1.00 1.00 1.00 0.00 0.00 12.00 13.00 12.00 13.00 0.00 Y

O N 0.50 0.50 0.50 0.50 0.00 0.00 13.00 13.50 13.00 13.50 0.00 Y

P I 0.50 0.50 0.50 0.50 0.00 0.00 11.00 11.50 13.00 13.50 2.00 N

Q O, P 0.50 1.00 1.50 1.00 0.03 0.17 13.50 14.50 20.50 21.50 7.00 N

R Q 0.00 0.00 0.00 0.00 0.00 0.00 14.50 14.50 21.50 21.50 7.00 N

T S 3.00 0.00 0.00 14.50 17.50 14.50 17.50 0.00 Y

U T 2.00 0.00 0.00 17.50 19.50 17.50 19.50 0.00 Y

V U 2.00 0.00 0.00 19.50 21.50 19.50 21.50 0.00 Y

W R, V 3.00 0.00 0.00 21.50 24.50 21.50 24.50 0.00 Y

X W 1.00 0.00 0.00 24.50 25.50 24.50 25.50 0.00 Y

Y X 1.00 0.00 0.00 25.50 26.50 25.50 26.50 0.00 Y

Z Y 4.00 0.00 0.00 26.50 30.50 26.50 30.50 0.00 Y

AA Z 1.00 0.00 0.00 30.50 31.50 30.50 31.50 0.00 Y

Internet Case: Alpha Beta Gamma Record (Thrift Print)

A-C-E-J-L-M-N-O-S-T-

U-V-W-X-Y-Z-AA-BB

E C, B 2.00 2.00 2.00 2.00 0.00 0.00 3.00 5.00 3.00 5.00 0.00 Y

F C, B 1.00 1.00 1.00 1.00 0.00 0.00 3.00 4.00 8.00 9.00 5.00 N
