TEACH Lesson Plan
IANNUCCI AND HOWERTON: Dental Radiography: Principles and Techniques, 5th Edition
6 Dental X-Ray Equipment
CHAPTER LESSON PLAN & OBJECTIVES
Lesson 6.1: Dental X-Ray Equipment
1. Define the key terms associated with dental x-ray equipment.
2. Discuss the regulation of dental x-ray machines at the federal, state, and local levels.
3. Recognize dental x-ray machines used for intraoral and extraoral exposures.
CHAPTER TEACHING FOCUS
• Students will have the opportunity to understand the operating procedures for the specific equipment
Chapter 6: Dental X-Ray Equipment 2
TEACH Lesson Plan
IANNUCCI AND HOWERTON: Dental Radiography: Principles and Techniques, 5th Edition
CHAPTER PRETEST
Have the students answer these questions prior to covering this chapter to understand where they stand
in relation to the content.
1) What type of film is placed inside the mouth?
a) Interoral
b) Extraoral c) Intraoral
d) X-ray oral
2) What type of film is placed outside the mouth?
a) Interoral
b) Extraoral c) Intraoral
d) X-ray oral
3) What contains the x-ray tube that produces dental x-rays and is also known as the tube housing?
a) Tubehead
b) Extension arm c) Cathode
d) Anode
4) What allows the dental radiographer to regulate the x–ray beam?
a) Tubehead
b) Extension arm c) Control panel
d) On-off switch
5) What regulates the x-ray beam and includes the timer and the kVp and mA selectors?
a) Tubehead
b) Extension arm c) Control panel
d) Control devices
8) What is used with the beam alignment device to further restrict the size of the x-ray beam?
a) Collimating device
b) Film holder c) Extension arm
d) PID
9) The typical intraoral dental x-ray machine consists of which of the following three component parts?
a) Receptor holder, collimator, and lead
apron
b) Sensor, film holder, and plastic grip
c) Bite block, control device, and PID
d) Tubehead, extension arm, and control
panel
10) What film holder is used during endodontic procedures, such as a root canal?
a) XCP
b) Precision film holder c) EndoRay
d) Root canal film holder
Chapter 6: Dental X-Ray Equipment 3
TEACH Lesson Plan
IANNUCCI AND HOWERTON: Dental Radiography: Principles and Techniques, 5th Edition
CHAPTER PRETEST ANSWERS
1) c
Because intra means within, intraoral film is placed inside the mouth.
p. 54
6) b
A receptor holder is a device used to hold and align intraoral dental x-ray receptors in the mouth.
p. 56
Chapter 6: Dental X-Ray Equipment 4
TEACH Lesson Plan
IANNUCCI AND HOWERTON: Dental Radiography: Principles and Techniques, 5th Edition
Classroom Preparation
Lesson 6.1: Dental X-Ray Equipment
INSTRUCTOR PREPARATION
Textbook Objectives Covered
1. Define the key terms associated with dental x-ray equipment.
2. Discuss the regulation of dental x-ray machines at the federal, state, and local levels.
National Standards Covered
ABHES DAI (Dental Assisting I – Basic)
• Section A: Curriculum, Competencies, Externship and/or Internal Clinical Experience:
• Clinical equipment function and maintenance:
• Identify and control the various functions for dental equipment in a clinical setting (4.a)
ABHES DAII (Dental Assisting II – Advanced)
• Section A: Curriculum, Competencies, Externship and/or Internal Clinical Experience:
• Clinical equipment function and maintenance:
• Identify and control the various functions for dental equipment in a clinical setting (6.a)
CODA Standards for Dental Assisting Programs
• Standard 2: Educational Program:
• The curriculum must include content at the in-depth level in dental radiology. Students must
CODA Standards for Dental Hygiene Programs
• Standard 2: Educational Program:
• Curriculum content: Dental sciences content must include tooth morphology, head, neck and oral
Chapter 6: Dental X-Ray Equipment 5
TEACH Lesson Plan
Lesson Preparation Checklist
• Prepare lecture from TEACH lecture slides available on Evolve.
Materials and Supplies
• computer
Instructor Note
Chapter 6: Dental X-Ray Equipment 6
TEACH Lesson Plan
IANNUCCI AND HOWERTON: Dental Radiography: Principles and Techniques, 5th Edition
Classroom Preparation
Lesson 6.1: Dental X-Ray Equipment
STUDENT PREPARATION (5* hrs)
1
spell the key term. They should bring completed cards to class for an activity.
READ – Textbook (pp. 54–57)
ANSWER – Workbook Module 2: Equipment, Film, and Processing Basics
• Basic Terminology Crossword Puzzle, questions 1-9 (p. 41)
2
charged for such an inspection. They should bring completed work to class for an activity.
READ – Textbook (p. 54)
ANSWER – Textbook
• Quiz Questions:
• Multiple Choice, question 1 (p. 59)
• True or False, questions 9, 10 (p. 59)
and machines. They should bring their findings to class for an activity.
4
READ – Textbook (pp. 55–56)
ANSWER – Textbook
• Quiz Questions: True or False, questions 11–13 (p. 59)
5
ANSWER – Workbook Module 2: Equipment, Film, and Processing Basics
• Completion and Short Answer: Dental X-Ray Machines, question 2 (p. 42)
6
READ – Textbook (pp. 56–58)
ANSWER – Textbook
• Quiz Questions: Multiple Choice, questions 6-8 (p. 59)
READ – Textbook (pp. 54–56)
ANSWER – Textbook
Chapter 6: Dental X-Ray Equipment 7
TEACH Lesson Plan
IANNUCCI AND HOWERTON: Dental Radiography: Principles and Techniques, 5th Edition
STUDENT PREPARATION (5* hrs) (Continued)
7
READ – Textbook (pp. 56–59)
ANSWER – Textbook
• Quiz Questions: True or False, questions 14, 15 (p. 59)
ANSWER – Workbook Module 2: Equipment, Film, and Processing Basics
• Multiple Choice: Beam Alignment Devices, questions 1–6 (p. 42)
All
REVIEW – Laboratory Manual*
• Module 2: Equipment Used in the Radiology Clinic (pp. 327-347)
PRACTICE – Laboratory Manual*
• Module 2: Equipment Used in the Radiology Clinic (pp. 349-354)
Chapter 6: Dental X-Ray Equipment 8
TEACH Lesson Plan
IANNUCCI AND HOWERTON: Dental Radiography: Principles and Techniques, 5th Edition
50-Minute Lesson Plan
Lesson 6.1: Dental X-Ray Equipment
LECTURE OUTLINE (10 min)
1
KEY TERMS: SLIDES 4-5 (pp. 54–57)
• Describe the key terms associated with dental x-ray equipment.
2
REGULATION: SLIDE 6 (p. 54)
• Discuss the regulation of dental x-ray machines at the federal, state, and local levels.
3
INTRAORAL AND EXTRAORAL EXPOSURE MACHINES: SLIDE 7 (pp. 54–55)
• Discuss dental x-ray machines used for intraoral and extraoral exposures.
LEARNING ACTIVITIES (choose one or more to equal 40 min)
1
REVIEW (20 min)
• Using the key terms flash cards that the students created as a homework assignment, have
the students split into pairs. Have one student state the definition of the term and the other
supply the term name. Switch roles and also have the students supply the terms to each other
and have the other give the definition. Continue until all have been identified.
• Appropriate Settings: Traditional classroom, flipped classroom
a homework assignment, have the students share their finding with the class. Make a list of
their findings on the board.
• Appropriate Settings: Traditional classroom, flipped classroom
4
&
5
DISCUSS (10 min)
• Call on a student to identify an advantage or disadvantage of using a portable dental x-ray
unit. Continue until all aspects of a unit have been sufficiently identified.
• Appropriate Settings: Traditional classroom, flipped classroom
REVIEW
• See the Simulations activities at the end of the Lesson Plan.
Chapter 6: Dental X-Ray Equipment 9
TEACH Lesson Plan
IANNUCCI AND HOWERTON: Dental Radiography: Principles and Techniques, 5th Edition
CRITICAL THINKING QUESTION
A woman is scheduled for a full series of radiographs. The dental radiographer is using the XCP
instruments for the series and is prepared to start the procedure. Upon placement of the XCP and
film in the patient’s mouth, the patient appears to be very uncomfortable with the procedure and
removes the XCP and film immediately, stating she is in pain. She says it hurts the roof of her
mouth and she can’t bite down to hold it in place. What adjustments will the dental radiographer
need to make with this radiographic technique?
Discussion Guidelines: The patient appears to have a very shallow palate, which is not a good indicator
Chapter 6: Dental X-Ray Equipment 10
TEACH Lesson Plan
IANNUCCI AND HOWERTON: Dental Radiography: Principles and Techniques, 5th Edition
Assessments
Chapter 6: Dental X-Ray Equipment
ASSESSMENTS BY OBJECTIVE
1
Workbook Module 2: Equipment, Film, and Processing Basics
• Basic Terminology Crossword Puzzle, questions 1-9 (p. 41)
2
Evolve Instructor Resources
• Test Bank: Multiple Choice, question 1
Workbook Module 2: Equipment, Film, and Processing Basics
3
Workbook Module 2: Equipment, Film, and Processing Basics
• Completion and Short Answer: Dental X-Ray Machines, question 1 (p. 42)
5
Evolve Instructor Resources
• Test Bank: Multiple Choice, questions 2-5
Workbook Module 2: Equipment, Film, and Processing Basics
• Completion and Short Answer: Dental X-Ray Machines, question 2 (p. 42)
6
Evolve Instructor Resources
• Test Bank: Multiple Choice, questions 7, 13
• Identification and RINN Assembly Review (pp. 81-84)
Laboratory Manual
• Module 2: Equipment Used in the Radiology Clinic (pp. 327-354)
Chapter 6: Dental X-Ray Equipment 11
TEACH Lesson Plan
IANNUCCI AND HOWERTON: Dental Radiography: Principles and Techniques, 5th Edition
Simulations
Chapter 6: Dental X-Ray Equipment
SIMULATIONS BY OBJECTIVE
Dental X-Ray Identification (15 min)
5
Equipment Needed
• dental x-ray machine
• Post-it notes
REVIEW
work for accuracy.
Typodonts and Film Holders (30 min)
6
&
7
Equipment Needed
• typodonts
• various types of film holders and beam alignment devices
PRACTICE
