Chapter 9: Relational Database Design by ER- and EER-to-Relational Mapping
1
CHAPTER 9: RELATIONAL DATABASE DESIGN BY ER- AND EER-TO–
RELATIONAL MAPPING
Answers to Selected Exercises
9.3 – Try to map the relational schema of Figure 6.14 into an ER schema. This is part of
a process known as reverse engineering, where a conceptual schema is created for
an existing implemented database. State any assumptions you make.
Answer:
Note: We represented BOOK_AUTHORS as a multi-valued attribute of BOOK in the above
ER diagram. Alternatively, it can be represented as a weak entity type.
9.4 – Figure 9.8 shows an ER schema for a database that may be used to keep track of
transport ships and their locations for maritime authorities. Map this schema into a relational
schema, and specify all primary keys and foreign keys.
Answer:
SHIP
SNAME OWNER TYPE PNAME
Copyright © 2016 Pearson Education, Inc., Hoboken NJ
9.5 Map the BANK ER schema of Exercise 7.23 (shown in Figure 7.21) into a relational
schema. Specify all primary keys and foreign keys. Repeat for the AIRLINE schema (Figure
7.20) of Exercise 7.19 and for the other schemas for Exercises 7.16 through 7.24.
Partial Answer:
BANK
CODE NAME ADDR
ACCOUNT
9.6 – 9.9: No solutions provided.
