Database Storage & Design Chapter 10b Homework We have completed the modifications of the QACS database

Chapter 10B – Managing Databases with Oracle Database

Page 10B-161

T. Create a new table named PAYROLL, as shown in Figure 10B-90. Use the column

characteristics shown in Figure 10B-90. Note that PayrollEntryID is a surrogate key,

with initial value 20180001 and incrementing by 1.

CREATE TABLE PAYROLL (

PayrollEntryID Int NOT NULL,

EmployeeID Int NOT NULL,

PayrollCategoryID Int NOT NULL,

PayDate DATE,

U. Populate the PAYROLL table using the data stored in the PAYROLL_TEMP table.

Hint: You will have one record in the PAYROLL table for every record in the

PAYROLL_TEMP table, and your final table will have 20 records. Hint: see Exericse

10B.72G for how to manage the sequence.

Chapter 10B – Managing Databases with Oracle Database

Page 10B-162

Chapter 10B – Managing Databases with Oracle Database

Page 10B-163

V. We have completed the modifications of the QACS database, and are done with the

temporary PAYROL_TEMP table. We could delete it if we wanted to, but we will

keep the PAYROLL_TEMP table in the database.

❖ ANSWERS TO MORGAN IMPORTING PROJECT QUESTIONS

If you have not completed the discussion of the Morgan Importing database at the end of

Chapter 7, work thorough the Chapter 7 Morgan Importing Project Questions now. Use the MI

database that you created in the Chapter 7 MI Project Questions as the basis for your answers

to the following questions:

A. Using the examples in this chapter as a template:

• For Oracle Database 12c Release 2: Use the Oracle Enterprise Manager to create a

tablespace named MICH10B, a user named MI_CH10B_USER with a password of

Chapter 10B – Managing Databases with Oracle Database

Page 10B-165

Chapter 10B – Managing Databases with Oracle Database

Page 10B-166

The process is simpler for Oracle Database XE 11.2: Follow the instructions on pages 10B29-

10B-33. After creating the workspace, exit the XE 11.2 Database Administration Utility. Here is

a screen shot of the crucial part of the process:

After creating the above user, the database will need to be created and populated with data. As mentioned

in the text, it is assumed that you have already created and populated this database, but probably in

another account. So re-run the scripts to create and populate the tables in the new user account. Files

Chapter 10B – Managing Databases with Oracle Database

Page 10B-167

Using the MI database, create an SQL script named MI–Create-Views-and-Functions.sql to

answer parts B through E.

Answers to parts B through E are below and in the file DBP-e14-Oracle-MI-Create-Views-and-

Functions.sql.

B. Create and test a user-defined function named LastNameFirst that combines two

parameters named FirstName and LastName into a concatenated name field formatted

LastName, FirstName (including the comma and space).

Tested in view that follows in part C.

C. Create and test a view called PurchasingAgentSummaryView that contains the

employee name of any MI employees who purchase items for the company,

concatenated and formatted as LastName, FirstName (including the comma and space)

in a field named PurchasingAgentName, ITEM.ItemDescription, ITEM.PurchaseDate,

STORE.StoreName, STORE.City, and Store.Country.

SELECT * FROM PurchasingAgentSummaryView;

Chapter 10B – Managing Databases with Oracle Database

Page 10B-168

D. Create and test a user-defined function named FirstNameFirst that combines two

parameters named FirstName and LastName into a concatenated name field formatted

FirstName LastName (including the space).

CREATE OR REPLACE FUNCTION FirstNameFirst

(varFirstName IN Char,

Tested in view that follows in part E.

E. Create and test a view called ReceivingAgentSummaryView that contains the employee

name of any MI employees who received items for the company, concatenated and

formatted as FirstName LastName in a field named ReceivingAgentName,

SHIPMENT_RECEIPT.ReceiptNumber, SHIPMENT.ShipmentID,

SHIPPER.ShipperName, SHIPMENT.EstimatedArrivalDate, and the date and time of the

receipt. Hint: use the Oracle TO_CHAR function to extract the date and time from the

ReceiptDateTime field.

Chapter 10B – Managing Databases with Oracle Database

Page 10B-169

SELECT * FROM ReceivingAgentSummaryView;

Using the MI database, create an SQL script named MI–Create-Triggers.sql to answer

parts F and G.

F. Assume that the relationship between SHIPMENT and SHIPMENT_ITEM is M-M.

Design triggers to enforce this relationship. Use Figure 10B-72 and the discussion of that

G. Write and test the triggers you designed in part F. Note that you may need to create

Oracle Database views in order for the triggers to work properly.

Note: The answers to Project Questions F and G are combined in the following discussion.

SQL solutions to these questions are below and in the file DBP-e15-Oracle-MI-Create-

Triggers.sql.

Both SHIPMENT and

SHIPMENT_ITEM are

Required

SHIPMENT

[Parent]

SHIPMENT_ITEM

[Child]

Chapter 10B – Managing Databases with Oracle Database

Page 10B-170

There are three actions that need triggers:

(1) Controlling the reassignment of a SHIPMENT_ITEM from one SHIPMENT to another

(1) Controlling the reassignment of a SHIPMENT_ITEM from one SHIPMENT to

another.

This is similar to a trigger we wrote for Exercise 10B.70, and we’ll use the same logic here. We

will also need the same logic in the next trigger. Note that this problem is also similar to the one

discussed in Chapter 7 and illustrated in Figure 7-29.

Chapter 10B – Managing Databases with Oracle Database

Here is the trigger code:

CREATE OR REPLACE TRIGGER Reassign_SHIPMENT_PI

INSTEAD OF UPDATE ON Shipment_Assignment

FOR EACH ROW

DECLARE NewShipmentNumber Int;

MovingItemID Int;

OldShipmentNUmber Int;

NewShipment Int;

NumberOfItems Int;

BEGIN

Chapter 10B – Managing Databases with Oracle Database

Page 10B-172

/* The SHIPMENT_ITEM is the only SHIPMENT_ITEM in the SHIPMENT. */

/* Delete the SHIPMENT and allow the cascade

behavior to also delete the SHIPMENT_ITEM */

DELETE FROM SHIPMENT

WHERE SHIPMENTID = OldShipmentNumber;

DBMS_OUTPUT.PUT_LINE

(‘********************************************************************’);

DBMS_OUTPUT.PUT_LINE

(‘ You have reassigned the only shipment item in:’);

DBMS_OUTPUT.PUT_LINE (‘ ‘);

DBMS_OUTPUT.PUT_LINE (‘ Shipment = ‘||OldShipmentNumber);

DBMS_OUTPUT.PUT_LINE (‘ Number of Items = ‘||NumberOfItems);

DBMS_OUTPUT.PUT_LINE (‘ Shipment Item = ‘||MovingItemID);

DBMS_OUTPUT.PUT_LINE

UPDATE SHIPMENT_ITEM

SET ShipmentID = NewShipmentNumber

WHERE PurchaseItemID = MovingItemID;

DBMS_OUTPUT.PUT_LINE

(‘********************************************************************’);

DBMS_OUTPUT.PUT_LINE (‘ ‘);

DBMS_OUTPUT.PUT_LINE

(‘ Trigger Reassign_SHIPMENT_PURCHASE_ITEM’);

DBMS_OUTPUT.PUT_LINE (‘ ‘);

Chapter 10B – Managing Databases with Oracle Database

Page 10B-173

To test this trigger, use:

(1) To reassign a SHIPMENT_ITEM to a different SHIPMENT from an existing

SHIPMENT with only one SHIPMENT_ITEM:

Chapter 10B – Managing Databases with Oracle Database

Page 10B-174

(2) To reassign a SHIPMENT_ITEM to a different SHIPMENT from an existing

SHIPMENT with more than one SHIPMENT_ITEM:

SET SERVEROUTPUT ON;

(2) Deleting a SHIPMENT when the last SHIPMENT_ITEM is deleted.

We will use the logic in Figures 7-28 and 7-29 for this case. In this logic, one type of employee

Chapter 10B – Managing Databases with Oracle Database

Page 10B-175

To test these, run the following commands:

SELECT * FROM DeleteShipmentItem;

SELECT * FROM DeleteShipmentItemShipment;

Chapter 10B – Managing Databases with Oracle Database

Page 10B-176

Figure 7-28 contains the logic to delete all but the last INVOICE_ITEM. The trigger requires us

to check the number of SHIPMENT_ITEMs in a SHIPMENT. If the number of

SHIPMENT_ITEMS is greater than one, we allow the deletion. If the number of

SHIPMENT_ITEMS is exactly one, we will not allow the deletion and then send an error

BEGIN

/* Determine if this is the last SHIPMENT_ITEM in the SHIPMENT */

ShipmentNumber := :OLD.ShipmentID;

DeleteItemID := :OLD.PurchaseItemID ;

Chapter 10B – Managing Databases with Oracle Database

Page 10B-177

/* Print the error message

*/

DBMS_OUTPUT.PUT_LINE

(‘********************************************************************’);

DBMS_OUTPUT.PUT_LINE (‘ ‘);

DBMS_OUTPUT.PUT_LINE

(‘ Number of Items = ‘|| NumberOfShipmentItems);

DBMS_OUTPUT.PUT_LINE

(‘ Shipment Item = ‘|| DeleteItemID);

DBMS_OUTPUT.PUT_LINE (‘ ‘);

DBMS_OUTPUT.PUT_LINE

(‘********************************************************************’);

END IF;

IF NumberOfShipmentItems > 1 THEN

/* Deletion of INVOICE_ITEM. */

DELETE FROM SHIPMENT_ITEM

WHERE ShipmentID = ShipmentNumber

AND PurchaseItemID = DeleteItemID;

DBMS_OUTPUT.PUT_LINE

(‘********************************************************************’);

DBMS_OUTPUT.PUT_LINE (‘ ‘);

DBMS_OUTPUT.PUT_LINE

(‘ Trigger Allow_Deletion_of_SI’);

DBMS_OUTPUT.PUT_LINE (‘ ‘);

DBMS_OUTPUT.PUT_LINE
