22.1 From Figure B.10.1, it can be seen that the molten salt is heated by a fired heater in the
circulating loop. This implies that heat is added to the reactor, i.e., the reaction is
22.2 Pressure at the bottom of a column decreases.
Pbot = Ptop + Ptrays
The pressure drop across the column is due to the pressure drop caused by the gas
flowing upwards through the layer of liquid on the trays. This pressure drop is due mainly
to the weir height which will not change. Thus, the pressure at the top of the column will
22-2
22.3
22-3
22.3 (cont’d)
22-4
22-5
22.5
22-6
22.6
22-7
22.7 Many alternatives listed after examples in chapter 22
22.8
22.8 (cont’d)
22-9
22.9
22-10
22.10
22.11
22-11
22.12
22-12
22.12 (cont’d)
22-13
22.13
22-14
22.14
22-15
22.15
22-16
22.15 (cont’d)
22-17
22.15 (cont’d)
