2. The forces (F1and F2)are each about 40 lbf. This magnitude of force may be
21
6.15: PROBLEM DEFINITION
Situation:
Water jet f rom a fire hose on a boat.
d=4in,V=60mph = 88.0ft/s.
Find:
Tensionincable(lbf).
Sketch:
Properties:
Water (50 ◦F), Table A.5: ρ=1.94 slug/ft3.
PLAN
Apply the momentum equation.
SOLUTION
Force and momentum diagrams
Flow rate
Momentum equation (x-direction)
22
6.16: PROBLEM DEFINITION
Situation:
Water jet f rom a fire hose on a boat.
T=5.0kN, v=50m/s.
Find:
Mass flow rate of jet (kg/s).
Diameter of jet (cm).
Sketch:
Properties:
Water (5◦C), Table A.5: ρ=1000kg/m3.
PLAN
Apply the momentum equation to find the mass flow rate. Then, calculate diameter
using the flow rate equation.
SOLUTION
Force and momentum diagrams
Momentum equation (x-direction)
Flow rate
23
24
6.17: PROBLEM DEFINITION
Situation:
Piston water guns used to shoot water from one raft to another.
After volleys, rafts are drifting apart.
Water is ejected from piston water gun at a flow rate of 1 gal/s.
Diameter of gun exit is 1.5 in.
Find:
The momentum flux (N) generated by ejecting water from a water gun.
PLAN
a. SketchaCV,aFDandaMDaspreparationforemployingthemomentum
equation.
b. Employ the momentum equation (also called the Impulse-Momentum Eqn).
SOLUTION
a. SketchaCV,aFDandaMD.
b. Employ the Linear Momentum Equation.
Determine the velocity of the jet
25
Using the FD and the MD, we set up the following equation, where F = force of
the person compressing the piston.
6.18: PROBLEM DEFINITION
Situation:
Pressurized air drives a water jet out of a tank. The thrust of the water jet reduces
the tension in a supporting cable.
W= 200 N,T=10N.
d=12mm,H=425mm.
Find:
The pressure in the air that is situated above the water.
Sketch:
Pressurized Air
Water
H
Vertical Cable
Jet–diameter d
Assumptions:
Assume that the Bernoulli equation can be applied (i.e. assume irrotational and
steady flow).
Properties:
Water (15 ◦C), Table A.5: ρ=999kg/m3.
PLAN
Apply the momentum equation to find the exit velocity. Then, apply the Bernoulli
equation to find the pressure in the air.
SOLUTION
Section area of jet
27
Momentum equation (cv surrounding the tank; section 2 at the nozzle)
Bernoulli equation (location 1 is on the water surface, location 2 is at the water jet).
28
6.19: PROBLEM DEFINITION
Situation:
Free water jet from upper tank to lower tank, lower tank supported by scales A
and B.
Find:
Force on scale A (lbf).
Force on scale B (lbf).
Sketch:
Properties:
Water (60 oF): ρ=1.94 slug/ft3,γ=62.4lbf/ft3.
PLAN
Apply the momentum equation.
SOLUTION
Force and momentum diagrams
29
Flow rate
Projectile motion equations
Momentum equation (x-direction)
Momentum equation (y-direction)
30
6.20: PROBLEM DEFINITION
Situation:
Gravel flows into a barge that is secured with a hawser.
Q=50yd3/min = 22.5 ft3/s, v=10ft/s.
Find:
Tensioninhawser: T
Sketch:
Assumptions:
Steady flow.
Properties:
γ=120lbf/ft3
PLAN
Apply the momentum equation.
SOLUTION
Force and momentum diagrams
Momentum equation (x-direction)
31
6.21: PROBLEM DEFINITION
Situation:
A hemispherical nozzle sprays a sheet of liquid through an arc.
Find:
An expression for the force in y-direction to hold the nozzle stationary.
Fy=Fy(ρ, v, r, t).
Sketch:
v
y
d
θ
θ
PLAN
Apply the momentum equation.
SOLUTION
Momentum equation (y-direction)
32
6.22: PROBLEM DEFINITION
Situation:
The design of a conical rocket nozzle.
Find:
Show that T=˙mVe1+cos α
2.
PLAN
Apply the momentum equation.
SOLUTION
Momentum equation (x-direction)
Exit Area
33
6.23: PROBLEM DEFINITION
Q=0.15 m3/s, S=0.9.
Find:
Components of force to hold vane stationary (kN).
Sketch:
PLAN
Apply the momentum equation.
SOLUTION
Force and momentum diagrams
Mass flow rate
Momentum equation (x-direction)
34
Momentum equation (y-direction)
35
6.24: PROBLEM DEFINITION
Situation:
Afixed vane in the horizontal plane.
v1=70ft/s, v2=65ft/s.
Q=1.5cfs, S=0.9.
Find:
Components of force to hold vane stationary (lbf).
Sketch:
PLAN
Apply the momentum equation.
SOLUTION
Force and momentum diagrams
Momentum equation (x-direction)
y-direction
36
6.25: PROBLEM DEFINITION
Situation:
A horizontal, two-dimensional water jet deflected by a fixed vane.
v1=40ft/s, w2=0.2ft, w3=0.1ft.
Find:
Components of force, per foot of width, to hold the vane stationary (lbf/ft).
Assumptions:
Neglect elevation changes.
Neglect viscous effects.
Properties:
Water, Table A.5: ρ=1.94 slug/ft3.
PLAN
Apply the Bernoulli equation, the continuity equation, and finally the momentum
equation.
SOLUTION
Force and momentum diagrams
Continuity equation
Momentum equation (x-direction)
38
Momentum equation (y-direction)
39
6.26: PROBLEM DEFINITION
Situation:
Awaterjetisdeflected by a fixed vane.
v1=30ft/s, ˙m=35lbm/s = 1.086 slug/s.
Find:
Force of the water on the vane (lbf).
Sketch:
PLAN
Apply the Bernoulli equation, and then the momentum equation.
SOLUTION
Force and momentum diagrams
Momentum equation (x-direction)
y-direction
Since the forces acting on the vane represent a state of equilibrium, the force of water
onthevaneisequalinmagnitude&oppositeindirection.
