Chapter 12. Solids and Modern Materials
Media Resources
Figures and Tables in Transparency Pack: Section:
Figure 12.11 The Structures of (a) Primitive Cubic, 12.3 Metallic Solids
(b) Body-centered Cubic, and (c) Face-centered
Cubic Metals
Figure 12.12 A Space-filling View of Unit Cells for 12.3 Metallic Solids
Metals with a Cubic Structure
Activities: Section:
Close Packing 12.3 Metallic Solids
Metallic Bonding 12.4 Metallic Bonding
Band Structure 12.7 Covalent-Network Solids
Movies: Section:
Close Packing 12.3 Metallic Solids
Synthesis of Nylon 6,10 12.8 Polymeric Solids
3-D Models: Section:
Water 12.1 Classifications of Solids
Silicon Carbide 12.1 Classifications of Solids
Primitive Cubic 12.2 Structures of Solids
Simple Cubic 12.2 Structures of Solids
Body-Centered Cubic 12.2 Structures of Solids
Chapter 12
162
Phosphorus 12.7 Covalent-Network Solids
Polyethylene 12.8 Polymeric Solids
Buckminsterfullerene 12.9 Nanomaterials
Other Resources
Further Readings: Section:
Pictorial Analogies II: Types of Solids 12.1 Classifications of Solids
The Importance of Understanding Structure 12.2 Structures of Solids
Intelligent Materials 12.3 Metallic Solids
Nickel-Titanium Memory Metal: A “Smart” 12.3 Metallic Solids
Material Exhibiting a Solid-State Phase Change
and Superelasticity
Conducting Midshipmen–A Classroom Activity 12.4 Metallic Bonding
Modeling Extended Bonding in Solids
An Ionic Model for Metallic Bonding 12.4 Metallic Bonding
A Model to Illustrate the Brittleness of Ionic and 12.5 Ionic Solids
Metallic Crystals
The Origin of the Name ‘Nylon’ 12.8 Polymeric Solids
Dr. Baekeland’s Bakelite 12.8 Polymeric Solids
Thermosetting Resins 12.8 Polymeric Solids
Performance Polymers 12.8 Polymeric Solids
Elastomers I: Natural Rubber 12.8 Polymeric Solids
Rubber Reclamation 12.8 Polymeric Solids
Plastic Fantastic 12.8 Polymeric Solids
Solids and Modern Materials
163
Fishing for New Materials 12.9 Nanomaterials
Big Bucks from Small Science 12.9 Nanomaterials
The Smallest Revolution 12.9 Nanomaterials
Live Demonstrations: Section:
Kixium Monolayers: A Simple Alternative to the 12.2 Structures of Solids
Bubble Raft Model for Close-Packed Spheres
Paper-and-Glue Unit Cell Models 12.2 Structures of Solids
Close Packing of Identical Spheres 12.3 Metallic Solids
Memory Metal 12.3 Metallic Solids
Chapter 12
164
Chapter 12. Solids and Modern Materials
Common Student Misconceptions
• Students tend to have difficulty in “seeing” unit cells and crystal lattices; the use of models is often
helpful.
Teaching Tips
• It should be stressed that nanoscience is an interdisciplinary science and background knowledge in
physics, chemistry and biology is needed in order to understand how nanomaterials are designed,
made and applied.
Lecture Outline
12.1 Classifications of Solids
1
,
2
,
3
• Solids are classified by the types of bonds that hold the atoms in place.
• Metallic solids: held together by a delocalized “sea” of shared valence electrons.
12.2 Structures of Solids
• Solids may be classified according to their level of order.
• Crystalline solids have atoms and ions arranged in an orderly repeating pattern.
• Examples: NaCl, quartz, diamond
• Amorphous solids lack the order of crystalline solids.
Solids and Modern Materials
165
Unit Cells and Crystal Lattices
4
,
5
,
6
,
7
,
8
,
9
,
10
,
11
,
12
,
13
,
14
,
15
• Crystalline solids have an ordered, repeating structure.
• The smallest repeating unit in a crystal is a unit cell.
• The unit cell is the smallest unit with all the symmetry of the entire crystal.
• The three-dimensional stacking of unit cells is the crystal lattice.
• Each point in the lattice is a lattice point that represents an identical environment within the
• A square lattice: lattice vectors are equal in length and perpendicular to each other.
• A rectangular lattice: the lattice vectors are perpendicular but of different lengths.
• A hexagonal lattice: the lattice vectors are of the same length and the angle between them is 120˚.
• In three dimensions a lattice is defined by three lattice vectors: a, b, c.
• These define a parallelepiped: a 6-sided figure whose faces are all parallelograms.
• This figure is described by the length of the cell edges (a, b, c) and the angles between the edges
( ).
4
“Primitive Cubic” 3-D Model from Instructor’s Resource CD/DVD
5
“Simple Cubic” 3-D Model from Instructor’s Resource CD/DVD
6
“Body-Centered Cubic” 3-D Model from Instructor’s Resource CD/DVD
7
“Face-Centered Cubic” 3-D Model from Instructor’s Resource CD/DVD
8
“The Importance of Understanding Structure” from Further Readings
Chapter 12
166
• Example: A body-centered cubic lattice has one lattice point at each of the 8 corners plus
one at the center of the unit cell.
• Example: A face-centered cubic lattice has one lattice point at each of the 8 corners plus
one at the center of each of the 6 faces of the unit cell.
Filling the Unit Cell
• A crystal structure is defined by the lattice as well as the location of the atoms relative to the lattice
points.
• Simplest case: a crystal structure made of identical atoms with each atom exactly coincident with
FORWARD REFERENCES
• Quartz – a crystalline solid, and glass – an amorphous solid, will be discussed in Chapter 22
(section 22.10).
12.3 Metallic Solids
16
• Metallic solids or metals consist solely of metal atoms.
• Metallic bonding results from delocalization of valence electrons throughout the solid.
The Structures of Metallic Solids
17
,
18
• The crystal structures of many metals correspond to one of three cubic lattices:
• Primitive cubic (examples: polonium); 1 atom per unit cell.
• Body-centered cubic (examples: sodium and chromium); 2 atoms per unit cell.
• Face-centered cubic (examples: silver, gold, copper, aluminum, lead); 4 atoms per unit cell.
Close Packing
19
,
20
,
21
,
22
• The sharing of valence electrons makes it favorable for the atoms in a metal to pack closely together.
• Layers of atoms are efficiently packed by surrounding each atom by six neighbors.
• A three dimensional structure is formed by stacking additional layers on top of the base layer.
“Close Packing” Movie from Instructor’s Resource CD/DVD
Solids and Modern Materials
167
• There are two choices for the arrangement of the atoms in the third layer.
• Hexagonal close packing (hcp): The third layer atoms are in the depressions that lie directly
over the first layer.
Alloys
23
,
24
,
25
• Alloys contain more than one element and have the characteristic properties of metals.
• Pure metals and alloys have different physical properties.
• An alloy of gold and copper is used in jewelry (the alloy is harder than the relatively soft pure 24
karat gold).
• 14 karat gold is an alloy containing 58% gold.
• Alloys can be divided into 4 categories:
• Substitutional alloys (the solute atoms take the positions normally occupied by a solvent atom)
• The atoms must have similar atomic radii.
• The elements must have similar bonding characteristics.
• The most important iron alloy is stainless steel. It contains C, Cr (from ferrochrome,
FeCr2), and Ni.
• Heterogeneous alloys: The components are not dispersed uniformly (e.g., pearlite steel has two
phases: almost pure Fe and cementite, Fe3C).
• Intermetallic compounds: homogeneous alloys with definite properties and compositions.
• Examples include:
• Ni3Al (a major component of jet aircraft engines).
• Cr3Pt (used to coat razor blades (to increase hardness and ability to maintain a sharp edge),
• Co5Sm (used in permanent magnets in lightweight headsets).
• LaN5 (used as the anode in nickel-metal hydride batteries).
Chapter 12
168
FORWARD REFERENCES
• Coordination numbers in the context of coordination transition metal compounds will be
discussed in detail throughout Chapter 23.
12.4 Metallic Bonding
26
,
27
,
28
,
29
,
30
Electron-Sea Model
• A simple model that accounts for many properties of metals is the electron-sea model.
• An array of metal cations exist in a “sea” of valence electrons.
Molecular-Orbital Model
31
,
32
• Problems with the electron-sea model:
• As the number of electrons increases, the strength of bonding should increase, and the melting
point should increase.
• However, group 6B metals (at the center of the transition metals) have the highest melting points
in their respective periods.
• We turn to molecular-orbital theory for a more general model.
• As the number of orbitals increases, their energy spacing decreases.
• As the chain length goes to infinity the allowed energy states become a continuous band.
• The complex electronic structure of a bulk solid is call a band structure.
• Many of the properties of metals can be understood in terms of its band structure.
• The available electrons do not completely fill the band of orbitals.
• Therefore, electrons can be promoted to unoccupied energy bands.
• Because the energy differences between orbitals are small the promotion of electrons
requires little energy.
FORWARD REFERENCES
• Molecular orbitals will be discussed in the context of the crystal field theory in Chapter 23
(Section 23.6).
26
“Metallic Bonding” Activity from Instructor’s Resource CD/DVD
Solids and Modern Materials
169
12.5 Ionic Solids
33
• Ionic solids are held together by ionic bonds: electrostatic attraction between cations and anions.
• The high melting and boiling points reflect the strength of ionic bonds.
Structures of Ionic Solids
34
,
35
,
36
,
37
,
38
• Ionic solids tend to have close-packed arrangements of ions.
• The arrangement is different from that of metallic solids due to the different radii and different
charges of the cations and anions.
• Three common ionic structure types are commonly found for ionic solids:
• Structure based on a primitive cubic lattice: anions sit on the lattice points at the corners of
the unit cell and one cation sits inside each cell.
• Example: CsCl
• Coordination number: 4
• Tetrahedral coordination environment.
• The relative number of cations and anions determines the most stable structure type.
FORWARD REFERENCES
• Chemistry of nonmetals forming anions in ionic solids will be discussed in Chapter 22.
12.6 Molecular Solids
• Molecular solids consist of atoms or molecules held together by intermolecular forces.
• Weak intermolecular forces give rise to low melting points.
33
“A Model to Illustrate Brittleness of Ionic and Metallic Crystals” from Further Readings
Chapter 12
170
• Intermolecular forces include dipole-dipole, dispersion forces and H-bonds.
• Molecular solids are usually soft.
• They are often gases or liquids are room temperature.
• Efficient packing of molecules is important (because they are not regular spheres).
• Molecular solids show poor thermal and electrical conductivity.
• Examples: Ar(s), CH4(s), CO2(s), sucrose.
FORWARD REFERENCES
• Chapter 24 on organic chemistry will discuss formation and properties of many molecular
substances that are solids at room temperature.
12.7 Covalent-Network Solids
39
,
40
,
41
• Covalent-network solids consist of atoms held together, in large networks or chains, with covalent
bonds.
• In graphite:
• each C atom is arranged in a planar hexagonal ring.
• layers of interconnected rings are placed on top of each other.
• the distance between adjacent C atoms in the same layer is close to that seen in benzene (1.42 Å
vs. 1.395 Å in benzene).
• electrons move in delocalized orbitals (good conductor).
• the distance between layers is large (3.41 Å).
• the layers are held together by weak dispersion forces.
• They slide easily past each other.
39
Figure 12.30 from Transparency Pack
40
“Diamond” 3-D Model from Instructor’s Resource CD/DVD
“Phosphorus” 3-D Model from Instructor’s Resource CD/DVD
Solids and Modern Materials
171
• The band gap is the energy gap between a filled valence band and an empty conduction
band.
• Valence band: forms from bonding molecular orbitals.
• Moving down a group, the band gap decreases.
• C → Si → Ge → Sn
• The band gap increases as the difference in group numbers of elements increases.
Semiconductor Doping
• Electrical conductivity may be influenced by doping.
FORWARD REFERENCES
• Network-covalent solids will be discussed further in Chapter 22.
• The chemistry of Si and Ge will be discussed in Chapter 22 (section 22.10).
12.8 Polymeric Solids
47
,
48
,
49
,
50
• Polymers are molecules of high molecular weight that are made by polymerization (joining together)
of smaller molecules of low molecular mass.
• The building block small molecules for polymers are called monomers.
• Examples of polymers include plastics, DNA, proteins, and rubber.
• Plastics are materials that can be formed into various shapes, usually with heat and pressure.
47
“Pictorial Analogies V: Polymers” from Further Readings
Chapter 12
172
Making Polymers
51
,
52
,
53
,
54
,
55
,
56
,
57
,
58
,
59
,
60
,
61
,
62
,
63
,
64
• Many synthetic polymers have a backbone of C–C bonds.
• Carbon atoms have the ability to form unusually strong stable bonds with each other.
• Example: Ethylene H2C=CH2.
• An amine (R–NH2) condenses with a carboxylic acid (R–COOH) to form water and an
amide.
• A biological example of this reaction is the linking of amino acids to form polymer chains–
proteins!
• A protein is an example of a copolymer–a polymer formed from different monomers.
• Another example of condensation polymerization is the formation of nylon 6,6.
• Diamine and adipic acid are joined to form nylon 6,6.
Structure and Physical Properties of Polymers
65
,
66
,
67
,
68
,
69
,
70
,
71
,
72
,
73
• Synthetic and natural polymers commonly consist of a collection of macromolecules of different
51
“Alkanes: Abundant, Pervasive, Important, and Essential” from Further Readings
52
“Polyethylene” 3-D Model from Instructor’s Resource CD/DVD
53
“Slime: Gelation of Poly(vinyl alcohol) with Borax” From Live Demonstrations
54
“The Gelation of Polyvinyl Alcohol with Borax. A Novel Class Participation Experiment Involving the
Preparation and Properties of a ‘Slime’” from Live Demonstrations
Solids and Modern Materials
173
• The degree of crystallinity reflects the extent of the order.
• Stretching or extruding a polymer can increase crystallinity.
• The degree of crystallinity is also strongly influenced by average molecular mass:
• Low-density polyethylene (LDPE), which is used in plastic wrap, has an average molecular mass
of 104 amu.
• Rubber is cross-linked in a process employing short chains of sulfur atoms.
• Vulcanized rubber has more useful properties.
• It is more elastic and less susceptible to chemical reaction than natural rubber.
FORWARD REFERENCES
• Further mention of sulfur chemistry, including vulcanization of rubber, will be made in
12.9 Nanomaterials
• Nanomaterials have dimensions on the 1 – 100 nm scale.
Semiconductors on the Nanoscale
74
,
75
,
76
,
77
,
78
,
79
,
80
• Semiconductor particles with diameters in the 1 to 10 nm range are called quantum dots.
• Semiconductor band gaps change substantially with size in the 1-10 nm range.
• The smaller the particle, the larger the band gap. Consider cadmium phosphide.
• On a macrolevel it looks black. The band gap is small and it absorbs most of the visible light.
• When the particle is made smaller, the color changes until it looks white.
• No visible light is absorbed.
• The band gap is so large that only UV light can excite electrons to the conduction band.
• By appropriately tuning the band gap of the quantum dots, all colors of the rainbow can be
obtained from one material.
Chapter 12
174
• Quantum wires have also been produced. A quantum wire is a semiconductor wire that may have a
very long length but a diameter that is only a few nanometers.
Metals on the Nanoscale
• The mean free path of an electron is the average distance it moves before bumping into something
Fullerenes, Carbon Nanotubes, and Graphene
81
,
82
,
83
,
84
• In 1985 molecules composed of 60 carbon atoms, C60 molecules, were first described.
• C60 molecules are among a class of molecules of carbon atoms known as fullerenes.
• Buckyball or buckminsterfullerene may be prepared by electrically evaporating graphite in a
helium atmosphere.
• Because fullerenes are composed of individual molecules, they dissolve in various organic solvents
while diamond and graphite do not.
• Carbon nanotubes are sheets of graphite rolled up and capped at one or both ends by half of a C60
molecule.
• It can sustain very high electrical current densities.
FORWARD REFERENCES
• The work of Michael Faraday will be discussed in Chapter 20 (section 20.5).
• Fullerenes will be further discussed in Chapter 22 (section 22.9).
81
Figure 12.48 from Transparency Pack
Solids and Modern Materials
175
Further Readings:
1. John J. Fortman, “Pictorial Analogies II: Types of Solids,” J. Chem. Educ., Vol. 70, 1993, 57–58.
2. Frank Galasso, “The Importance of Understanding Structure,” J. Chem. Educ., Vol. 70, 1993, 287–290.
The relationship between unit cells and the structure of solids is covered in this article.
3. Henry S. Lipson, “The Fifth Bragg Lecture; W. L. Bragg-Scientific Revolutionary,” J. Chem. Educ.,
Vol. 60, 1983, 405–407.
8. Craig A. Rogers, “Intelligent Materials,” Scientific American, September 1995, 154–157.
9. Kathleen R. C. Gissser, Margaret J. Geselbracht, Ann Cappellari, Lynn Hunsberger, Arthur B. Ellis,
John Perepezko, and George Lisensky, “Nickel-Titanium Memory Metal: A “Smart” Material Exhibiting a
Solid-State Phase Change and Superelasticity,” J. Chem. Educ., Vol. 71, 1994, 334–340.
10. Joseph F. Lomax, “Conducting Midshipmen-A Classroom Activity Modeling Extended Bonding in
Solids,” J. Chem. Educ., Vol. 69, 1992, 794–795.
11. Frank Rioux, “An Ionic Model for Metallic Bonding” ,” J. Chem. Educ., Vol. 62, 1985, 383–384.
12. James P. Birk, “A Model to Illustrate the Brittleness of Ionic and Metallic Crystals,” J. Chem. Educ.,
Vol. 62, 1985, 667. Models made from magnets and plexiglass are used to illustrate some properties of
crystals.
Chapter 12
176
21. V. de Zea Bermudez, P. Passos de Almeida, and J. Feria Seita, “How to Learn and Have Fun with
Poly(Vinyl Alcohol) and White Glue,” J. Chem. Educ., Vol. 75, 1998, 1410–1418.
22. Melissa Lee, “Polymers and Processes,” Chemistry in Britain, Vol. 31(9), September 1998.
23. George B. Kauffman, “Wallace Hume Carothers and Nylon, the First Completely Synthetic Fiber,” J.
Chem. Educ., Vol. 65, 1988, 803–808.
28. Kathryn R. Williams, “Rubber Reclamation,” J. Chem. Educ., Vol. 84, 2007, 217-218.
29. George B. Kauffman and Raymond B. Seymour, “Elastomers I: Natural Rubber,” J. Chem. Educ., Vol.
67, 1990, 422–425.
30. Michael Chisholm, “Plastic Fantastic,” Chemistry in Britain, Vol. 34(4), April 1998, 33–36. An
article looking at the uses of polymethyl methacrylate.
31. Mary E. Harris, “Polymers in the Field and Track,” J. Chem. Educ., Vol. 85, 2008, 1323-1325.
Solids and Modern Materials
177
37. Michael Gross, “The Smallest Revolution,” Chemistry in Britain, May 2002, 36–39.
38. Bethany Halford, “A Tube of Tubes,” Chem. Eng. News, August 1, 2004, 23.
Live Demonstrations:
1. Keenan E. Dungey, George Lisensky, and S. Michael Condren, “Kixium Monolayers: A Simple
Alternative to the Bubble Raft Model for Close-Packed Spheres,” J. Chem. Educ., Vol. 76, 1999, 618–619.
2. Daryl L. Ostercamp, “Close Packing of Identical Spheres,” J. Chem. Educ., Vol. 69, 1992, 162. An
overhead projector demonstration of close packing.
6. Bassam Z. Shakhashiri, “‘Slime’: Gelation of Poly(vinyl alcohol) with Borax,” Chemical
Demonstrations: A Handbook for Teachers of Chemistry, Volume 3 (Madison: The University of
Wisconsin Press, 1989), pp. 362–363.
7. Bassam Z. Shakhashiri, “Solid Foams,” Chemical Demonstrations: A Handbook for Teachers of
Chemistry, Volume 3 (Madison: The University of Wisconsin Press, 1989), pp. 348–350. A demonstration
of the formation and destruction of solid foams.
8. Bassam Z. Shakhashiri, “Polyurethane Foam,” Chemical Demonstrations: A Handbook for Teachers of
Chemistry, Volume 1 (Madison: The University of Wisconsin Press, 1983), pp. 216–218. Polyurethane
foam is prepared in this demonstration of polymer formation.
Trusted by Thousands of
Students
Here are what students say about us.
Resources
Company
Copyright ©2022 All rights reserved. | CoursePaper is not sponsored or endorsed by any college or university.
