106
PROBLEM 10.9 Holes and limited space (in.)
107
PROBLEM 10.11 Dimensioning multiple features (in.)
108
PROBLEM 10.13 Circles and arcs (metric)
109
PROBLEM 10.15 Machine features (in.)
110
PROBLEM 10.17 Repetitive features (in.)
111
PROBLEM 10.19 Dimensioning circles, arcs, and slots (in.)
112
Part 2: Problems 10.21 Through 10.32
PROBLEM 10.21 Dimensioning compound circles and arcs (in.)
113
PROBLEM 10.22 Dimensioning auxiliary views (in.)
114
PROBLEM 10.23 Dimensioning small spaces (in.)
PROBLEM 10.24 Chart drawing (in.) Problem based on original art courtesy TEMCO
115
PROBLEM 10.25 Arrowless dimensioning (in.)
116
PROBLEM 10.27 Forging and machining drawings (metric)
117
PROBLEM 10.28 Angles, holes, and arcs (in.)
118
119
PROBLEM 10.31 CAD/CAM (in.)
120
Part 3: Problems 10.33 Through 10.35
121
PROBLEM 10.35 Rectangular and polar coordinate dimensioning (in.)
Math Problem Solutions
Part 4: Problems 10.36 Through 10.45
