Process Technology Equipment
Chapter 15 Vessels
Page 1
CHAPTER 15 Vessels
Table of Contents
Contents
Page
Chapter Overview
2
Class Preparation Checklist
2
Chapter Objectives
2
Agenda
3
Lesson Plan
5
15.0 Vessels
15.1 Types of Vessels
7
8
15.2 Common Components of Vessels
13
15.3 Operating Principles of Vessels
15.4 Potential Problems with Vessels
15.5 Hazards Associated with Improper Operation
15.6 Process Technician’s Role in Operation and
Maintenance
15.7 Typical Procedures
19
19
21
22
22
Summary and Wrap-Up
24
Suggested Student Activities
24
End of Chapter Review Questions
25
Clicker Questions
Appendix
35
39
Process Technology Equipment
Chapter 15 Vessels
CHAPTER 15 Vessels
Chapter Overview
In the process industries, vessels are containers used for storage or the additional
processing of products. Vessels vary in design, purpose, and process requirements.
The process technician is responsible for understanding the purpose of each vessel
along with any associated components and is responsible for the safe operation of all
vessels.
Class Preparation Checklist
1.
Familiarize yourself with the chapter content.
2.
Bring cutaways or other hands-on teaching aids if available.
3.
Copy and distribute any fill-in-the-blank handouts for today's content.
4.
Safety Minute prepared or assigned.
5.
Review the PowerPoint slides associated with this chapter (if used) and
make sure that your computer is correctly set up to navigate the slide deck
smoothly.
6.
Request the appropriate A/V equipment (if needed) and make sure that
your computer is correctly synched with the projector to avoid any delays in
the classroom.
Chapter Objectives
15.1 Identify the purpose, types, and applications of major vessels (NAPTA Vessels).
15.2 Identify the components of vessels and their purpose (NAPTA Vessels).
15.3 Explain the operating principles of vessels (NAPTA Vessels).
15.4 Identify potential problems associated with vessels (NAPTA Vessels).
15.5 Describe safety and environmental hazards associated with vessels (NAPTA
Vessels).
15.6 Describe the process technician’s role in vessel operation and maintenance
(NAPTA Vessels).
15.7 Identify typical procedures associated with vessel operation and maintenance
(NAPTA Vessels).
Process Technology Equipment
Chapter 15 Vessels
Page 3
Class Agenda
Activity
Minutes
PPTs
Handouts
(title, if
any)
1. Welcome to Class
1
1
2. Introduction and Agenda
1
2
3. Safety Minute
2
3
4. Objectives
0.5
4
5. Objectives (cont.)
0.5
5
6. Terms
1
6
7. Terms (cont.)
1
7
8. More Terms
1
8
9. Vessels
1
9
10. Types of Vessels
1
10
11. Atmospheric Storage Tanks
3
11
12. Pressure Storage Tanks
2
12
13. Towers
2
13
14. Reactors
1
14
15. Drums, Dryers, and Filters
2
15
16. High Pressure Cylinders
0.5
16
17. Hoppers, Bins, and Mobile Containers
1
17
18. Hoppers, Bins, and Mobile Containers (cont.)
1
18
19. Common Components of Vessels
3
19
20. Pressure/Vacuum Relief Valves
1
20
21. Pressure Relief Devices
3
21
22. Auxiliary Equipment for Vessels
0.5
22
23. Blanketing and Corrosion Monitoring Systems
1
23
24. Fire Protection and Grounding Systems
1
24
25. Heating and Cooling, Insulation and Tracing
1
25
26. Secondary Containment Systems
1
26
27. Vapor Recovery System and Other
Components
0.5
27
28. Vapor Recovery System and Other
Components (cont.)
0.5
28
29. Operating Principles of Vessels
2
29
30. Potential Problems with Vessels
0.5
30
31. Corrosion and Scale Buildup
1
31
32. Over- and Underpressurization
1
32
33. Operating Upsets, and Shutdowns and Start-
ups
1
33
34. Hazards Associated with Improper Operation
1
34
Process Technology Equipment
Chapter 15 Vessels
Page 4
35. Process Technician’s Role in Operation and
Maintenance
1
35
36. Special Procedures
1
36
37. Typical Procedures
0.5
37
38. Start-up Procedures
0.5
38
39. Start-up Procedures (cont.)
0.5
39
40. Shutdown and Emergency Procedures
0.5
40
41. Shutdown and Emergency Procedures (cont.)
0.5
41
42. Summary and Wrap-Up
4
42
Process Technology Equipment
Chapter 15 Vessels
Page 5
Chapter 15 Lesson Plan
Welcome Everyone to Class
Time: 1 minute
Resources: Slide 1
Introduction and Agenda
Time: 1 minute
Resources: Slide 2
Safety Minute
Time: 2 minutes
Resources: Slide 3
• Announce who is presenting the Safety Minute next class.
Objectives
Time: 0.5 minute
Resources: Slide 4
Process Technology Equipment
Chapter 15 Vessels
Page 6
Objectives (cont.)
Time: 0.5 minute
Resources: Slide 5
Terms
Time: 1 minute
Resources: Slide 6
Terms (cont.)
Time: 1 minute
Resources: Slide 7
Process Technology Equipment
Chapter 15 Vessels
Page 7
More Terms
Time: 1 minute
Resources: Slide 8
15.0 Vessels
Time: 1 minute
Resources: Slide 9
Process Technology Equipment
Chapter 15 Vessels
15.1 Types of Vessels
Time: 1 minute
Resources: Slide 10
Sample Instructor Script:
The most common process vessel types include:
Process Technology Equipment
Chapter 15 Vessels
Page 9
15.1.1 Atmospheric Storage Tanks
Time: 3 minutes
Resources: Slide 11
Sample Instructor Script:
Atmospheric storage tanks are appropriate only for substances that do not contain
15.1.2 Pressure Storage Tanks
Time: 2 minutes
Resources: Slide 12
Process Technology Equipment
Chapter 15 Vessels
Page 10
15.1.3 Towers
Time: 2 minutes
Resources: Slide 13
Process Technology Equipment
Chapter 15 Vessels
Page 11
15.1.4 Reactors
Time: 1 minute
Resources: Slide 14
15.1.5 Drums, Dryers, and Filters
Time: 2 minutes
Resources: Slide 15
Sample Instructor Script:
15.1.6 High Pressure Cylinders
Time: 0.5 minute
Resources: Slide 16
Process Technology Equipment
Chapter 15 Vessels
15.1.7 Hoppers, Bins, and Mobile Containers
Time: 1 minute
Resources: Slide 17
Sample Instructor Script:
15.1.8 Hoppers, Bins, and Mobile Containers (cont.)
Time: 1 minute
Resources: Slide 18
Sample Instructor Script:
Process Technology Equipment
Chapter 15 Vessels
Page 13
15.2 Common Components of Vessels
Time: 3 minutes
Resources: Slide 19
Sample Instructor Script:
Vessels, including tanks and drums, have many components.
A shell is the primary component of a vessel, making up the main part of its body. The
An agitator/mixer is a device used to combine (or mix) the contents inside a vessel.
Mixers are operated using motors located outside the vessels.
A baffle is a vertical or horizontal metal plate placed inside a vessel and used to alter
Process Technology Equipment
Chapter 15 Vessels
Page 14
A gauge hatch is an opening on the roof of a tank used to check tank levels and obtain
samples of the product or chemical.
A sight glass (or gauge glass) level indicator is a gauge placed on a vessel to
determine the height of the liquid level within the vessel.
15.2.1 Pressure/Vacuum Relief Valves
Time: 1 minute
Resources: Slide 20
Process Technology Equipment
Chapter 15 Vessels
Page 15
15.2.2 Pressure Relief Devices
Time: 3 minutes
Resources: Slide 21
Sample Instructor Script:
A pressure relief device discharges or relieves pressure in the event of
Relief valves are used in liquid (incompressible fluid) service to limit the pressure in a
vessel or system. Increased pressure may be the result of a process upset condition,
Process Technology Equipment
Chapter 15 Vessels
valves open more slowly and in proportion to the pressure increase.
15.2.3 Auxiliary Equipment for Vessels
Time: 0.5 minute
Resources: Slide 22
15.2.4 Blanketing and Corrosion Monitoring Systems
Time: 1 minute
Resources: Slide 23
Sample Instructor Script:
Process Technology Equipment
Chapter 15 Vessels
Page 17
15.2.5 Fire Protection and Grounding Systems
Time: 1 minute
Resources: Slide 24
15.2.6 Heating and Cooling, Insulation and Tracing
Time: 1 minute
Resources: Slide 25
Sample Instructor Script:
15.2.7 Secondary Containment Systems
Time: 1 minute
Resources: Slide 26
Process Technology Equipment
Chapter 15 Vessels
15.2.8 Vapor Recovery System and Other Components
Time: 0.5 minute
Resources: Slide 27
15.2.9 Vapor Recovery System and Other Components (cont.)
Time: 0.5 minute
Resources: Slide 28
Sample Instructor Script:
Process Technology Equipment
Chapter 15 Vessels
Page 19
15.3 Operating Principles of Vessels
Time: 2 minutes
Resources: Slide 29
Sample Instructor Script:
When operating a process vessel, tank, tower, column, or drum, proper control of the
15.4 Potential Problems with Vessels
Time: 0.5 minute
Resources: Slide 30
Process Technology Equipment
Chapter 15 Vessels
Page 20
15.4.1 Corrosion and Scale Buildup
Time: 1 minute
Resources: Slide 31
Sample Instructor Script:
15.4.2 Over- and Underpressurization
Time: 1 minute
Resources: Slide 32
Sample Instructor Script:
