PROBLEM 6.124
A 100-lb force directed vertically downward is applied to the
toggle vise at C. Knowing that link BD is 6 in. long and that
a = 8 in., determine the horizontal force exerted on block E.
PROBLEM 6.125
The control rod CE passes through a
horizontal hole in the body of the toggle
system shown. Knowing that link BD is 250
mm long, determine the force
Q
required to
hold the system in equilibrium when
20.
PROBLEM 6.126
Solve Problem 6.125 when (a)
0,
(b)
6.
PROBLEM 6.125
The control rod CE passes
through a horizontal hole in the body of the
toggle system shown. Knowing that link BD
is 250 mm long, determine the force
Q
required to hold the system in equilibrium
when
20.
PROBLEM 6.126 (Continued)
PROBLEM 6.127
The press shown is used to emboss a small seal at E.
Knowing that P 250 N, determine (a) the vertical
component of the force exerted on the seal, (b) the reaction
at A.
PROBLEM 6.128
The press shown is used to emboss a small seal at E.
Knowing that the vertical component of the force exerted on
the seal must be 900 N, determine (a) the required vertical
force
P
, (b) the corresponding reaction at A.
PROBLEM 6.129
The pin at B is attached to member ABC and can slide freely along the
slot cut in the fixed plate. Neglecting the effect of friction, determine
the couple
M
required to hold the system in equilibrium when
30 .
PROBLEM 6.130
The pin at B is attached to member ABC and can slide freely along the
slot cut in the fixed plate. Neglecting the effect of friction, determine
the couple
M
required to hold the system in equilibrium when
60 .
PROBLEM 6.131
Arm ABC is connected by pins to a collar at B and to crank CD at
C. Neglecting the effect of friction, determine the couple
M
required to hold the system in equilibrium when
0.
PROBLEM 6.132
Arm ABC is connected by pins to a collar at B and to crank CD at
C. Neglecting the effect of friction, determine the couple
M
required to hold the system in equilibrium when
90 .
