PROBLEM 4.19
The bracket BCD is hinged at C and attached to a control
cable at B. For the loading shown, determine (a) the
tension in the cable, (b) the reaction at C.
PROBLEM 4.20
Solve Problem 4.19, assuming that
0.32 m.a
PROBLEM 4.19 The bracket BCD is hinged at C and
attached to a control cable at B. For the loading shown,
determine (a) the tension in the cable, (b) the reaction at C.
PROBLEM 4.21
The 40-ft boom AB weighs 2 kips; the distance from the
axle A to the center of gravity G of the boom is 20 ft. For
the position shown, determine (a) the tension T in the cable,
(b) the reaction at A.
PROBLEM 4.22
A lever AB is hinged at C and attached to a control cable at A. If
the lever is subjected to a 500-N horizontal force at B,
determine (a) the tension in the cable, (b) the reaction at C.
PROBLEM 4.23
For each of the plates and loadings shown, determine the reactions at A and B.
PROBLEM 4.23 (Continued)
PROBLEM 4.24
For each of the plates and loadings shown, determine the reactions at A and B.
PROBLEM 4.24 (Continued)
PROBLEM 4.25
A rod AB hinged at A and attached at B to cable BD
supports the loads shown. Knowing that 200 mm,d
determine (a) the tension in cable BD, (b) the reaction at A.
PROBLEM 4.26
A rod AB, hinged at A and attached at B to cable BD,
supports the loads shown. Knowing that 150 mm,d
determine (a) the tension in cable BD, (b) the reaction at A.
