4-122 A cylindrical aluminum block is heated in a furnace. The length of time the block should be kept in the furnace and the
amount of heat transferred to the block are to be determined.
Assumptions 1 Heat conduction in the cylindrical block is two-dimensional, and thus the temperature varies in both axial x-
and radial r- directions. 2 Heat transfer from the bottom surface of the block is negligible. 3 The thermal properties of the
aluminum are constant. 4 The heat transfer coefficient is constant and uniform over the entire surface. 5 The Fourier number
is > 0.2 so that the one-term approximate solutions (or the transient temperature charts) are applicable (this assumption will
be verified).
Properties The thermal properties of the aluminum block are given to be k = 236 W/m.C, = 2702 kg/m3, cp = 0.896
kJ/kg.C, and = 9.7510-5 m2/s.
Analysis This cylindrical aluminum block can physically be formed by the
intersection of an infinite plane wall of thickness 2L = 60 cm and a long cylinder of
radius ro = D/2 = 7.5 cm. Note that the height of the short cylinder represents the half
thickness of the infinite plane wall where the bottom surface of the short cylinder is
adiabatic. The Biot numbers and corresponding constants are first determined to be
102.0
)C W/m.236(
)m 3.0)(C. W/m80(2
=
== k
hL
Bi
0164.1 and 3135.0 11 ==→ A
0254.0
)C W/m.236(
)m 075.0)(C. W/m80(2
=
== k
hr
Bi o
0063.1 and 2217.0 11 ==→ A
Noting that
2
/Lt
=
and assuming > 0.2 in all dimensions and thus the one-term
approximate solution for transient heat conduction is applicable, the product solution
for this problem can be written as
7627.0
)075.0(
)1075.9(
)2217.0(exp)0063.1(
)3.0(
)1075.9(
)3135.0(exp)0164.1(
120020
1200300
),0(),0(),0,0(
2
5
2
2
5
2
cyl
1
wall
1cylwallblock
2
1
2
1
=
−
−=
−
−
==
−−
−−
tt
eAeAttt
Solving for the time t gives
t = 306 s = 5.1 min
We note that
2.03317.0
m) 3.0(
s) /s)(306m 1075.9(
2
25
2
wall
=
==
−
L
t
L
z
Cylinder
Ti = 20C
r0
Furnace
T = 1200C
L
4-103
4-104
4-123 Prob. 4-121 is reconsidered. The effect of the final center temperature of the block on the heating time and the
amount of heat transfer is to be investigated.
Analysis The problem is solved using EES, and the solution is given below.
"GIVEN"
2*L=0.30 [m]
2*r_o=0.15 [m]
T_i=20 [C]
T_infinity=1200 [C]
T_o_o=300 [C]
h=80 [W/m^2-C]
"PROPERTIES"
k=236 [W/m-C]
rho=2702 [kg/m^3]
c_p=0.896 [kJ/kg-C]
alpha=9.75E-5 [m^2/s]
"ANALYSIS"
"This short cylinder can physically be formed by the intersection of a long cylinder of radius r_o and a plane wall
of thickness 2L"
"For plane wall"
Bi_w=(h*L)/k
"From Table 4-1 corresponding to this Bi number, we read"
lambda_1_w=0.2224 "w stands for wall"
A_1_w=1.0083
tau_w=(alpha*time)/L^2
theta_o_w=A_1_w*exp(-lambda_1_w^2*tau_w) "theta_o_w=(T_o_w-T_infinity)/(T_i-T_infinity)"
"For long cylinder"
Bi_c=(h*r_o)/k "c stands for cylinder"
"From Table 4-2 corresponding to this Bi number, we read"
lambda_1_c=0.2217
A_1_c=1.0063
tau_c=(alpha*time)/r_o^2
theta_o_c=A_1_c*exp(-lambda_1_c^2*tau_c) "theta_o_c=(T_o_c-T_infinity)/(T_i-T_infinity)"
(T_o_o-T_infinity)/(T_i-T_infinity)=theta_o_w*theta_o_c "center temperature of cylinder"
V=pi*r_o^2*(2*L)
m=rho*V
Q_max=m*c_p*(T_infinity-T_i)
Q_w=1-theta_o_w*Sin(lambda_1_w)/lambda_1_w "Q_w=(Q/Q_max)_w"
Q_c=1-2*theta_o_c*J_1/lambda_1_c "Q_c=(Q/Q_max)_c"
J_1=0.1101 "From Table 4-3, at lambda_1_c"
Q/Q_max=Q_w+Q_c*(1-Q_w) "total heat transfer"
4-105
To,o
[C]
time
[s]
Q
[kJ]
50
100
150
200
250
300
350
400
450
500
550
600
650
700
750
800
850
900
950
1000
37.79
79.48
123.1
168.9
217
267.7
321.3
378.1
438.7
503.4
572.9
647.9
729.5
818.9
917.7
1028
1153
1298
1469
1678
605.5
1238
1870
2502
3134
3766
4398
5031
5663
6295
6927
7559
8191
8823
9456
10088
10720
11352
11984
12616
0200 400 600 800 1000
0
200
400
600
800
1000
1200
1400
1600
1800
0
2000
4000
6000
8000
10000
12000
14000
To,o [C]
time [s]
Q [kJ]
4-106
