Chapter 28 Graphs and Applications
Section 28.2 Basic Graph Terminologies
1. A is an edge that links a vertex to itself.
a. loop
b. parallel edge
c. weighted edge
d. directed edge
#
2. If two vertices are connected by two or more edges, these edges are called .
a. loop
b. parallel edge
c. weighted edge
d. directed edge
#
3. A
is the one in which every two pairs of vertices are connected.
a. complete graph
b. weighted graph
c. directed graph
#
4. What is the number of edges in a complete graph of n vertices?
a. n
b. n – 1
c. n(n–1)/2
d. n*n
#
5. What is the number of edges in a tree of n vertices?
a. n
b. n – 1
c. n(n–1)/2
d. n*n
#
Section 28.4 Modeling Graphs
6. Suppose a graph is created in the following code. What is the output of the following code?
String[] vertices = {“Atlanta”, “Dallas”, “Chicago”, “New York”,
“Seattle”};
int[][] edges = {
{0, 1}, {0, 2},
{1, 0}, {1, 2}, {1, 3}, {1, 4},
{2, 0}, {2, 1}, {2, 3},
{3, 1}, {3, 2}, {3, 4},
{4, 1}, {4, 3}
};
Graph<String> graph1 = new UnweightedGraph<>(vertices, edges);
System.out.println(“The index of vertex Chicago is: ”
+ graph1.getIndex(“Chicago”));
a. 1
b. 2
c. 3
d. 4
e. 5
#
7. Suppose a graph is created in the following code. What is the number of vertices in the graph?
Integer[] vertices = {0, 1, 2, 3, 4};
int[][] edges = {
{0, 1}, {0, 2},
{1, 0}, {1, 2}, {1, 3}, {1, 4},
{2, 0}, {2, 1}, {2, 3},
{3, 1}, {3, 2}, {3, 4},
{4, 1}, {4, 3}
};
Graph<Integer> graph1 = new UnweightedGraph<>(vertices, edges);
System.out.println(“The number of vertices in graph1: ”
+ graph1.getSize());
a. 1
b. 2
c. 3
d. 4
e. 5
#
8. Suppose a graph is created in the following code. What is the degree of vertex 3 in the graph?
Integer[] vertices = {0, 1, 2, 3, 4};
int[][] edges = {
{0, 1}, {0, 2},
{1, 0}, {1, 2}, {1, 3}, {1, 4},
{2, 0}, {2, 1}, {2, 3},
{3, 1}, {3, 2}, {3, 4},
{4, 1}, {4, 3}
};
Graph<Integer> graph1 = new UnweightedGraph<>(vertices, edges);
System.out.println(“The degree of vertex 3: “
+ graph1.getDegree(3));
a. 1
b. 2
c. 3
d. 4
#
Section 28.7 Depth–First Search (DSF)
11. Suppose a graph is created in the following code. Using the dfs algorithm in the text, what is the output for the
path from 4 to 0?
Integer[] vertices = {0, 1, 2, 3, 4};
int[][] edges = {
{0, 1}, {0, 2},
{1, 0}, {1, 2}, {1, 3}, {1, 4},
{2, 0}, {2, 1}, {2, 3},
{3, 1}, {3, 2}, {3, 4},
{4, 1}, {4, 3}
};
Graph<Integer> graph1 = new UnweightedGraph<>(vertices, edges);
UnweigtedGraph<Integer>.Tree dfs = graph1.dfs(0);
System.out.println(dfs.getPath(4));
a. [4, 3, 2, 0]
b. [4, 3, 1, 0]
c. [4, 1, 0]
d. [4, 3, 2, 1, 0]
e. [4, 1, 2, 0]
#
9. The search of a graph first visits a vertex, then it recursively visits all the vertices adjacent to that vertex.
a. depth–first
b. breadth-first
Key:a See Listing 28.8.
#
10. The time complexity of the DFS algorithm is O(|E| + |V|).
a. true
b. false
#
Section 28.9 Breadth-First Search
14. Suppose a graph is created in the following code. Using the bfs algorithm in the text, what is the output for the
path from 4 to 0?
Integer[] vertices = {0, 1, 2, 3, 4};
int[][] edges = {
{0, 1}, {0, 2},
{1, 0}, {1, 2}, {1, 3}, {1, 4},
{2, 0}, {2, 1}, {2, 3},
{3, 1}, {3, 2}, {3, 4},
{4, 1}, {4, 3}
};
Graph<Integer> graph1 = new UnweightedGraph<>(vertices, edges);
UnweightedGraph<Integer>.Tree bfs = graph1.bfs(0);
System.out.println(bfs.getPath(4));
a. [4, 3, 2, 0]
b. [4, 3, 1, 0]
c. [4, 1, 0]
d. [4, 3, 2, 1, 0]
e. [4, 1, 2, 0]
#
13. The time complexity of the BFS algorithm is O(|E| + |V|).
a. true
b. false
Key:a See the paragraph before Figure 28.15.
#
12. The search of a graph first visits a vertex, then all its adjacent vertices, then all the vertices adjacent to
those vertices, and so on.
a. depth–first
b. breadth-first
