1. All network switches require substantial configuration before they can be put into operation in a network.
a.
True
b.
False
ANSWER:
False
POINTS:
1
REFERENCES:
Network Switches in Depth
QUESTION TYPE:
True / False
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
2. More VLANs mean fewer logical networks, so the network is less complex.
a.
True
b.
False
ANSWER:
False
POINTS:
1
REFERENCES:
Advanced Switch Features
QUESTION TYPE:
True / False
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
3. Routers can be used to control network access by inspecting the source and destination address information
of packets.
a.
True
b.
False
ANSWER:
True
POINTS:
1
REFERENCES:
Routers in Depth
QUESTION TYPE:
True / False
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
4. A distance-vector protocol sends updates to its neighbors that include the contents of its routing table.
a.
True
b.
False
ANSWER:
True
POINTS:
1
REFERENCES:
Routing Protocols
QUESTION TYPE:
True / False
HAS VARIABLES:
False
Name:
Class:
Date:
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 3
a.
cut-through
b.
fragment-free
c.
store-and-forward
d.
auto-negotiate
ANSWER:
a
POINTS:
1
REFERENCES:
Frame Forwarding Methods
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
9. Which switching method reads a minimum of 64 bytes of an Ethernet frame before forwarding the frame?
a.
cut-through
b.
fragment-free
c.
store-and-forward
d.
auto-negotiate
ANSWER:
b
POINTS:
1
REFERENCES:
Frame Forwarding Methods
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
10. You have four switches, A, B, C, and D. Switch A is connected to Switch C and Switch B is connected to
Switch D. Furthermore, Switch A and B are connected and Switch C and D are connected. One of the
connections is in blocking mode. What protocol must be running on the switches?
a.
RIP
b.
SNMP
c.
NTP
d.
STP
ANSWER:
d
POINTS:
1
REFERENCES:
Advanced Switch Features
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
11. Which of the following is NOT a function that would be found in a managed switch?
a.
the ability to stop switching loops using STP
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 4
b.
the ability to transfer its switching table with neighboring switches
c.
the creation of VLANS to logically separate resources
d.
to limit access to the network by enabling security on individual ports
ANSWER:
b
POINTS:
1
REFERENCES:
Advanced Switch Features
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
12. Your colleagues are discussing the operation of a device in which packets are routed between VLANs on
the device rather than having to exit the device to be routed. What type of device are they most likely
discussing?
a.
access point
b.
managed switch
c.
Layer 3 switch
d.
router
ANSWER:
c
POINTS:
1
REFERENCES:
Multilayer Switches
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
13. When a router’s interface is configured to connect with a switch trunk port to route packets between
VLANs, what is this called?
a.
multi-homed router
b.
dynamic router
c.
link-state router
d.
router on a stick
ANSWER:
d
POINTS:
1
REFERENCES:
Router Interfaces
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
14. In which type of routing protocol is a router’s routing table copied to neighboring routers to share
internetwork information?
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 5
a.
distance-state protocol
b.
link-state protocol
c.
hybrid protocol
d.
distance-vector protocol
ANSWER:
d
POINTS:
1
REFERENCES:
Routing Protocols
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
15. What has occurred when all routers in a network have accurate information after a change in the network?
a.
delivery
b.
convergence
c.
congestion
d.
concurrence
ANSWER:
b
POINTS:
1
REFERENCES:
Routing Protocols
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
16. Which of the following is a common link-state routing protocol?
a.
OSPF
b.
RIPv2
c.
EIGRP
d.
BGP
ANSWER:
a
POINTS:
1
REFERENCES:
Routing Protocols
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
17. What command issued from a command prompt will display the routing table in Windows?
a.
route table
b.
route print
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 6
c.
route delete
d.
route config
ANSWER:
b
POINTS:
1
REFERENCES:
Access Control Lists
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
18. What category of routing protocol is used to route packets between autonomous systems?
a.
distance-vector
b.
link-state
c.
EGP
d.
IGP
ANSWER:
c
POINTS:
1
REFERENCES:
Routing Protocols
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
19. What type of hacker uses a scanning device to find unsecured wireless networks and breaks into those
networks?
a.
white hat
b.
wardriver
c.
script kiddy
d.
phisher
ANSWER:
b
POINTS:
1
REFERENCES:
Basic Wireless Settings
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
20. In general, what level of security should you use with your access points?
a.
the easiest to configure
b.
wireless encryption protocol
c.
the most secure your systems supports
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 7
d.
RADIUS
ANSWER:
c
POINTS:
1
REFERENCES:
Wireless Security Options
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
21. What is the name of the value assigned to a routing protocol to indicate its reliability compared with other
routing protocols that might be in use on the same router?
a.
metric
b.
administrative distance
c.
hop count
d.
ACL
ANSWER:
b
POINTS:
1
REFERENCES:
Routing Tables
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
22. Which advanced feature of a NIC allows a computer to download an OS from the network instead of from a
local drive?
a.
onboard coprocessor
b.
advanced configuration power management interface
c.
shared system memory
d.
preboot execution environment
ANSWER:
d
POINTS:
1
REFERENCES:
Advanced Features of NICs
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
23. On a router configured to use RIP, the number of routers a packet must travel through before it reaches its
destination is called what? (Choose two.)
a.
metric
b.
hop count
c.
timestamp
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 8
d.
aging time
ANSWER:
a, b
POINTS:
1
REFERENCES:
Routing Tables
QUESTION TYPE:
Multiple Response
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 3:08 PM
24. Which of the following would be found in a router’s routing table? (Choose all that apply.)
a.
timestamp
b.
destination network
c.
next hop
d.
MAC address
e.
metric
ANSWER:
a, b, c, e
POINTS:
1
REFERENCES:
Routing Tables
QUESTION TYPE:
Multiple Response
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 3:09 PM
25. Access control lists can be configured based on which of the following? (Choose all that apply.)
a.
protocol
b.
source MAC address
c.
TCP port
d.
destination MAC address
e.
source IP address
ANSWER:
a, c, e
POINTS:
1
REFERENCES:
Access Control Lists
QUESTION TYPE:
Multiple Response
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 3:09 PM
26. When a switch receives a ____________ frame, it floods the frame out all ports.
ANSWER:
broadcast
POINTS:
1
REFERENCES:
Creating the Switching Table
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 9
QUESTION TYPE:
Completion
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
27. A switch that is configured to use the Spanning Tree Protocol will place a port in ____________ mode if
sending traffic to it may cause a switching loop.
ANSWER:
blocking
POINTS:
1
REFERENCES:
Advanced Switch Features
QUESTION TYPE:
Completion
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
28. A router’s final task when handling a packet is to send the packet on to its next and possibly final
destination; this is referred to as packet ____________.
ANSWER:
forwarding
POINTS:
1
REFERENCES:
Router Interfaces
QUESTION TYPE:
Completion
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
29. One type of security for wireless networks involves entering a list of the MAC addresses for the devices that
are allowed to access the network and excluding all others. This is called MAC ____________.
ANSWER:
filtering
POINTS:
1
REFERENCES:
Wireless Security Options
QUESTION TYPE:
Completion
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
30. A ____________ is used to make connections between the network interface card and the other vital
components of the computer, such as the central processing unit.
ANSWER:
bus
POINTS:
1
Name:
Class:
Date:
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 11
36. configured to carry VLAN traffic
ANSWER:
f
POINTS:
1
37. routing protocol category in which the routing protocol is used to exchange routing information between
autonomous systems
ANSWER:
g
POINTS:
1
38. sends the status of all its interface links to all other routers in the internetwork
ANSWER:
h
POINTS:
1
39. value that tells routers the best path to the destination network
ANSWER:
i
POINTS:
1
40. routing protocol category in which the routing protocol is used to exchange routing information within an
autonomous system
ANSWER:
j
POINTS:
1
41. Briefly describe the three types of switching methods.
ANSWER:
Cut-through switching is the fastest; it reads the destination MAC address and sends the
frame out. Store-and-forward switching is the slowest; it stores the entire message and then
sends it to the correct port. Fragment-free switching is the middle man; it reads enough to
make sure the packet is not fragmented and then sends it out.
POINTS:
1
REFERENCES:
Frame Forwarding Methods
QUESTION TYPE:
Subjective Short Answer
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
42. What does the Spanning Tree Protocol do?
ANSWER:
The Spanning Tree Protocol is used to detect whether there is a possibility of a switching
loop caused by redundant paths. If a loop is possible, it places one of the ports in blocking
mode to prevent it.
POINTS:
1
REFERENCES:
Advanced Switch Features
QUESTION TYPE:
Subjective Short Answer
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
Name:
Class:
Date:
Name:
Class:
Date:
Name:
Class:
Date:
50. What is BGP and how is it used?
ANSWER:
BGP is classified as an exterior gateway protocol used to route packets between autonomous
systems. BGP is a path-vector routing protocol, which analyzes the characteristics of all
autonomous systems lying in the path between the router and each destination network so
that it can form a nonlooping routing topology. BGP is used between ISPs, but it can also be
used on border routers of large organizations’ networks.
POINTS:
1
REFERENCES:
Routing Protocols
QUESTION TYPE:
Subjective Short Answer
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
