1. An IP address is composed of 48 bits that are grouped together into 8-bit octets and are represented by a
decimal number from 0 to 255.
a.
True
b.
False
ANSWER:
False
POINTS:
1
REFERENCES:
IPv4 Addressing
QUESTION TYPE:
True / False
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
2. To determine the network ID of an IP address, computers use a logical AND operation between the IP
address and the subnet mask.
a.
True
b.
False
ANSWER:
True
POINTS:
1
REFERENCES:
Binary Math
QUESTION TYPE:
True / False
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
3. The decimal equivalent of the binary number 10000001 is 133.
a.
True
b.
False
ANSWER:
False
POINTS:
1
REFERENCES:
Binary Math
QUESTION TYPE:
True / False
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
4. Route summarization can combine multiple routing table entries into a single entry.
a.
True
b.
False
ANSWER:
True
POINTS:
1
REFERENCES:
Supernetting
QUESTION TYPE:
True / False
Name:
Class:
Date:
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 3
network. You have 300 workstations that regularly access the Internet. What process must be in operation on
your network to allow all the workstations to have access to the Internet using only one public IP address?
a.
DHCP
b.
DNS
c.
ARP
d.
PAT
ANSWER:
d
POINTS:
1
REFERENCES:
Network Address Translation
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
9. You have just run the ipconfig command and after you did you see that your IP address is 0.0.0.0. What
option did you use on the ipconfig command?
a.
/flush
b.
/all
c.
/release
d.
/renew
ANSWER:
c
POINTS:
1
REFERENCES:
IP Configuration Command-Line Tools
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
10. Which part of a computer’s IP address configuration indicates the portion of the address that specifies the
network ID?
a.
DNS address
b.
subnet mask
c.
default gateway
d.
MAC address
ANSWER:
b
POINTS:
1
REFERENCES:
IPv4 Addressing
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 4
11. What is the decimal equivalent to the binary number 11100000?
a.
98
b.
160
c.
196
d.
224
ANSWER:
d
POINTS:
1
REFERENCES:
Binary Math
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
12. What is the network ID of the IP address 172.19.48.16 with subnet mask 255.255.240.0?
a.
172.19.0.0
b.
172.19.32.0
c.
172.19.48.0
d.
172.19.240.0
ANSWER:
c
POINTS:
1
REFERENCES:
Binary Math
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
13. The last 64 bits of an IPv6 address are the interface identifier. What is frequently used as part of the
interface identifier?
a.
the IP address
b.
a DHCP server
c.
an ARP broadcast
d.
the MAC address
ANSWER:
d
POINTS:
1
REFERENCES:
IPv6 Address Structure
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
14. What is the hexadecimal number F equal to in binary?
a.
0011
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 5
b.
1011
c.
1001
d.
1111
ANSWER:
d
POINTS:
1
REFERENCES:
IPv6 Address Structure
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
15. What is the decimal equivalent to the hexadecimal number D?
a.
13
b.
15
c.
12
d.
10
ANSWER:
a
POINTS:
1
REFERENCES:
IPv6 Address Structure
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
16. How many bits are available in an IPv6 network for creating subnets when the prefix is /48 and the host ID
is 64 bits?
a.
48
b.
16
c.
32
d.
64
ANSWER:
b
POINTS:
1
REFERENCES:
IPv6 Unicast Addresses
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
17. Which IP address is a Class C address?
a.
225.100.149.20
b.
125.88.1.66
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 6
c.
193.19.101.11
d.
177.14.23.19
ANSWER:
c
POINTS:
1
REFERENCES:
IP Address Classes
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
18. Which subnet mask should you use if you want 16 bits of host address space?
a.
255.255.0.0
b.
255.16.0.0
c.
255.255.255.16
d.
255.255.255.0
ANSWER:
a
POINTS:
1
REFERENCES:
Subnetting
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
19. If your original network address with prefix is 172.16.0.0/16, what should your new network address with
prefix be if you need 16 subnets?
a.
172.16.16.0/16
b.
172.16.0.0/24
c.
172.16.0.0/28
d.
172.16.0.0/20
ANSWER:
d
POINTS:
1
REFERENCES:
Subnetting
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
20. Your network address is 192.168.100.0. What prefix allows you to assign 30 host addresses?
a.
/29
b.
/30
c.
/27
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 7
d.
/28
ANSWER:
c
POINTS:
1
REFERENCES:
Subnetting
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
21. You computer’s IP address is 201.18.149.37/28. Which of the following is a valid default gateway for this
address?
a.
201.18.149.46
b.
201.18.149.17
c.
201.18.149.32
d.
201.18.149.48
ANSWER:
a
POINTS:
1
REFERENCES:
Configuring IPv4 Addresses
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
22. Which of the following is an invalid IP address/prefix to assign to a host?
a.
172.31.0.255/16
b.
172.16.255.128/25
c.
201.18.149.32/26
d.
10.255.0.0/8
ANSWER:
b
POINTS:
1
REFERENCES:
Configuring IPv4 Addresses
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
23. When using the route command at a command prompt, which entry indicates the default route?
a.
Network Destination 255.255.255.255 Netmask 0.0.0.0
b.
Network Destination 0.0.0.0 Netmask 0.0.0.0
c.
Network Destination 0.0.0.0 Netmask 255.255.255.255
d.
Network Destination 255.255.255.255 Netmask 255.255.255.255
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 8
ANSWER:
b
POINTS:
1
REFERENCES:
Configuring the Default Gateway
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
24. Which command displays the contents of the local DNS cache?
a.
ping /dns
b.
nslookup /show
c.
netsh show dnscache
d.
ipconfig /displaydns
ANSWER:
d
POINTS:
1
REFERENCES:
IP Configuration Command-Line Tools
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
25. Which of the following are solutions to the shortage of available IPv4 addresses? (Choose all that apply.)
a.
IPv6
b.
private addressing
c.
subnetting
d.
supernetting
e.
NAT
ANSWER:
a, b, c, e
POINTS:
1
REFERENCES:
Network Address Translation
QUESTION TYPE:
Multiple Response
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 3:11 PM
26. IPv4 addresses are written in dotted ____________ notation.
ANSWER:
decimal
POINTS:
1
REFERENCES:
IPv4 Addressing
QUESTION TYPE:
Completion
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
Name:
Class:
Date:
Name:
Class:
Date:
Name:
Class:
Date:
36. A value used to express how many bits of an IP address are network ID bits.
ANSWER:
f
POINTS:
1
37. An address that always refers to the local computer.
ANSWER:
g
POINTS:
1
38. A value assigned to the gateway based on the speed of the interface used to access the gateway.
ANSWER:
h
POINTS:
1
39. A network communication in which a packet is addressed so that more than one destination can receive it.
ANSWER:
i
POINTS:
1
40. An IP address that can be used to communicate only on the local subnet.
ANSWER:
j
POINTS:
1
41. What does APIPA stand for, and what does it do?
ANSWER:
APIPA stands for Automatic Private IP Addressing. APIPA provides a computer with an IP
address when the computer cannot contact a DHCP server.
POINTS:
1
REFERENCES:
Private IP Addresses
QUESTION TYPE:
Subjective Short Answer
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
42. What is CIDR and why is it used?
ANSWER:
Classless Interdomain Routing (CIDR) allows IP addresses to be configured with subnet
masks regardless of the address class. CIDR provides flexibility in IP address assignment and
subnetting. From CIDR came CIDR notation where an IP address can be written as
address/prefix such as 192.168.10.5/26 where the /26 indicates the number of 1 bits in the
subnet mask.
POINTS:
1
REFERENCES:
Classless Interdomain Routing
QUESTION TYPE:
Subjective Short Answer
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
Name:
Class:
Date:
POINTS:
1
REFERENCES:
IPv6 Overview
QUESTION TYPE:
Subjective Short Answer
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:52 PM
43. A range of addresses is reserved for private addressing in each class. What are those ranges?
ANSWER:
For Class A, all addresses beginning with 10 For Class B, addresses from 172.16 to 172.31
For Class C, addresses from 192.168.0 to 192.168.255
POINTS:
1
REFERENCES:
Private IP Addresses
QUESTION TYPE:
Subjective Short Answer
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
44. What is the difference between NAT and PAT?
ANSWER:
NAT translates a private IP address to a public IP address and there is a one to one ratio of
private to public addresses. PAT includes the port number which is unique for each
translation so a single public IP address can be used to translate multiple private IP addresses.
POINTS:
1
REFERENCES:
Network Address Translation
QUESTION TYPE:
Subjective Short Answer
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
45. List and describe three of the seven discussed improvements that IPv6 has over IPv4.
ANSWER:
Larger address space-IPv4 addresses are 32 bits, which provide a theoretical four
billion addresses. IPv6 addresses are 128 bits, so the number of possible addresses
can be expressed as 34 followed by 37 0s, or 340 trillion trillion trillion. Hierarchical
address space-Unlike IPv4, in which numbers in the address have little meaning other
than the address class, and the network ID and host ID, IPv6 addresses have a more
defined structure. Autoconfiguration-IPv6 can be self-configuring or autoconfigured
from a router or server running IPv6 or through DHCPv6. Built-in quality of service
(QoS) support-IPv6 includes built-in fields in packet headers to support QoS
strategies. Built-in support for security-From the ground up, IPv6 is built to support
secure protocols, such as Internet Protocol Security (IPsec). Support for mobility-
With built-in support for mobility, routing IPv6 packets generated by mobile devices
over the Internet is more efficient than with IPv4. Extensibility-IPv6 uses extension
headers instead of IPv4’s fixed-size 40-byte header.
Name:
Class:
Date:
46. How does the ARP protocol work? How can you display and delete the local ARP cache?
ANSWER:
When an IP packet is sent to a destination on the local network, the sending device must have
the destination’s MAC address. The source computer retrieves the MAC address by sending a
broadcast ARP request packet to the local network. The ARP request packet essentially asks
“Who has IP address A.B.C.D?” The computer on the local network that’s assigned the IP
address sends an ARP reply message containing its MAC address. You can display the ARP
cache with the command arp -a and you can delete it with arp -d.
POINTS:
1
REFERENCES:
IP Configuration Command-Line Tools
QUESTION TYPE:
Subjective Short Answer
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
47. How can an IPv6 interface ID be assigned to a host?
ANSWER:
An IPv6 interface ID can be assigned to a host in these ways: Using the 48-bit MAC
address-Because a MAC address is only 48 bits, the other 16 bits come from the
value fffe inserted after the first 24 bits of the MAC address. In addition, the first two
0s that compose most MAC addresses are replaced with 02. A randomly generated
permanent interface identifier-The interface ID is generated randomly but is a
permanent assignment maintained through system restarts.
POINTS:
1
REFERENCES:
IPv6 Address Structure
QUESTION TYPE:
Subjective Short Answer
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:52 PM
48. What is an IPv6 link-local address?
ANSWER:
Addresses starting with fe80 are called link-local IPv6 addresses and are self-configuring.
Link-local addresses can’t be routed and are somewhat equivalent to Automatic Private IP
Addressing (APIPA) in IPv4.
POINTS:
1
REFERENCES:
IPv6 Address Types
QUESTION TYPE:
Subjective Short Answer
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
49. What is an IPv6 anycast address?
Name:
Class:
Date:
ANSWER:
Anycast addressing is a cross between unicast and multicast. Multiple nodes are assigned the
same address, and packets sent to that address are delivered to the “closest” node. So
although packets sent with a multicast address are delivered to multiple destinations, the
anycast address is sent to only one of a group of nodes sharing the same anycast address.
POINTS:
1
REFERENCES:
IPv6 Address Types
QUESTION TYPE:
Subjective Short Answer
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
50. How does a computer know when to send packets to the default gateway?
ANSWER:
The sending computer must first know its network address. It determines this by doing a
logical AND operation between its IP address and subnet mask, which results in the network
ID of the address. The next step is to determine whether the destination computer’s address is
on the same network or a different network. The same AND calculation is done between the
destination computer’s IP address and the sending computer’s subnet mask. The result is the
destination computer’s network ID. If the network ID of the sending computer is different
than the network ID of the destination, the packet is sent to the router or default gateway.
POINTS:
1
REFERENCES:
Configuring the Default Gateway
QUESTION TYPE:
Subjective Short Answer
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:35 PM
DATE MODIFIED:
7/19/2019 2:35 PM
