Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 1
1. A network’s physical topology refers to the arrangement of the cabling and how the devices connect to each
other.
a.
True
b.
False
ANSWER:
True
POINTS:
1
REFERENCES:
Physical Topologies
QUESTION TYPE:
True / False
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:34 PM
2. The physical bus topology is no longer used because it required extra cable and a central device to connect all
the computers.
a.
True
b.
False
ANSWER:
False
POINTS:
1
REFERENCES:
Physical Bus Topology
QUESTION TYPE:
True / False
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:34 PM
3. A point-to-point topology is typically used for WAN connections or wireless bridges.
a.
True
b.
False
ANSWER:
True
POINTS:
1
REFERENCES:
Point-to-Point Topology
QUESTION TYPE:
True / False
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:34 PM
4. A network’s logical topology often depends on the central device’s electronics.
a.
True
b.
False
ANSWER:
True
POINTS:
1
REFERENCES:
Logical Topologies
QUESTION TYPE:
True / False
Name:
Class:
Date:
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 3
around from the last device to the first device?
a.
physical bus
b.
physical star
c.
physical ring
d.
point-to-point
ANSWER:
c
POINTS:
1
REFERENCES:
Physical Ring Topology
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:34 PM
9. What is an advantage of a point-to-point topology?
a.
data travels on a dedicated link
b.
provides redundancy and fault tolerance
c.
allows many end-device connections
d.
a reliable and fast backbone
ANSWER:
a
POINTS:
1
REFERENCES:
Point-to-Point Topology
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:34 PM
10. What type of logical topology is at work when using an Ethernet hub?
a.
logical bus
b.
logical ring
c.
switched topology
d.
hierarchical topology
ANSWER:
a
POINTS:
1
REFERENCES:
Logical Topologies
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:34 PM
11. In which topology does a central device communicate with two or more other devices and is used in WANs
where a main office has connections to several branch offices via a router?
a.
logical bus
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 4
b.
logical star
c.
switched
d.
Point-to-multipoint
ANSWER:
d
POINTS:
1
REFERENCES:
Point-to-Point Topology
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:34 PM
12. In a token ring network, what is the central device called?
a.
multiport Ethernet switch
b.
multiservice switch
c.
multisession drive
d.
multistation access unit
ANSWER:
d
POINTS:
1
REFERENCES:
Physical Star Topology
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:34 PM
13. What is the most common topology and technology combination in use today?
a.
logical bus / Ethernet
b.
logical bus / wireless LAN
c.
logical ring / token ring
d.
switched / Ethernet
ANSWER:
d
POINTS:
1
REFERENCES:
Logical Topologies
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:34 PM
14. Which of the following is NOT a characteristic of Unshielded Twisted Pair cabling?
a.
contains four pairs of copper wire
b.
susceptible to electrical interference
c.
maximum speed is 100 Mbps
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 5
d.
comes in numbered categories
ANSWER:
c
POINTS:
1
REFERENCES:
Network Technologies and Media
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:34 PM
15. Which of the following is NOT a field in an Ethernet frame header?
a.
Time-to-Live
b.
Type
c.
FCS
d.
Source MAC
ANSWER:
a
POINTS:
1
REFERENCES:
Ethernet Networks
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:34 PM
16. What is in an Ethernet frame’s trailer?
a.
source MAC address
b.
destination MAC address
c.
frame payload
d.
cyclic redundancy check
ANSWER:
d
POINTS:
1
REFERENCES:
Ethernet Networks
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:34 PM
17. What is the media access method used by Ethernet?
a.
CSMA/CD
b.
Token passing
c.
CSMA/CA
d.
Polling
ANSWER:
a
Name:
Class:
Date:
Name:
Class:
Date:
Name:
Class:
Date:
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 9
the center, forming a(n) ____________ star.
ANSWER:
extended
POINTS:
1
REFERENCES:
Physical Star Topology
QUESTION TYPE:
Completion
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:34 PM
28. With a ___________________ antenna, signals are focused in a single direction, which makes them ideal
for placement at one end of long, narrow spaces or to cover distances between buildings.
ANSWER:
unidirectional
POINTS:
1
REFERENCES:
Wi–Fi Antennas
QUESTION TYPE:
Completion
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:34 PM
29. When a wireless computer connects with an AP before it connects with other devices, it is operating in
____________ mode.
ANSWER:
infrastructure
POINTS:
1
REFERENCES:
Wi–Fi Modes of Operation
QUESTION TYPE:
Completion
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:34 PM
30. A ___________ topology is fully redundant and is the most expensive to implement.
ANSWER:
mesh
POINTS:
1
REFERENCES:
Point-to-Point Topology
QUESTION TYPE:
Completion
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:34 PM
Match each item with a statement below.
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 10
a.
logical topology
b.
physical topology
c.
mesh topology
d.
point-to-point topology
e.
collision
f.
CSMA/CA
g.
CSMA/CD
h.
media access method
i.
broadband
j.
baseband
REFERENCES:
Glossary
QUESTION TYPE:
Matching
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:34 PM
31. how the data travels from one device to another
ANSWER:
a
POINTS:
1
32. how the cables connect one device to another
ANSWER:
b
POINTS:
1
33. connects every device to every other device
ANSWER:
c
POINTS:
1
34. direct connection between two devices
ANSWER:
d
POINTS:
1
35. can occur when two devices on the same medium transmit simultaneously
ANSWER:
e
POINTS:
1
36. access method used by Wi–Fi
ANSWER:
f
POINTS:
1
37. devices on the network must listen first before they can transmit
ANSWER:
g
POINTS:
1
Name:
Class:
Date:
43. What are the advantages and disadvantages of a physical star topology?
38. a set of rules governing how and when the network medium can be accessed for transmission
ANSWER:
h
POINTS:
1
39. uses an analog signal to send multiple signals simultaneously
ANSWER:
i
POINTS:
1
40. sends a digital signal using the entire bandwidth
ANSWER:
j
POINTS:
1
41. What is the difference between a network’s physical topology and its logical topology?
ANSWER:
The physical topology of a network refers to the way that all devices are physically
connected. It takes into account the way that the computers are cabled together and
whether they have a central connecting device or not. The logical topology of a
network refers to the way that the signals travel from one network device to another.
Although all the devices may appear to pass data in certain direction, the actual path
the data takes may be different-often it depends on the interconnecting device such as
a hub or switch.
POINTS:
1
REFERENCES:
Physical Topologies
QUESTION TYPE:
Subjective Short Answer
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:46 PM
42. In a physical bus topology, why do the ends of the cable have to be terminated?
ANSWER:
When data is sent onto the network in a physical bus topology, it continues to travel the
length of the network until it loses strength or until it is absorbed by a device. Once the signal
reaches the end of the cable, it will bounce back and interfere with the other signals that
follow it. To eliminate this signal distortion, the ends are terminated with a material that
absorbs the signal so that it cannot bounce back.
POINTS:
1
REFERENCES:
Physical Bus Topology
QUESTION TYPE:
Subjective Short Answer
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:34 PM
Name:
Class:
Date:
QUESTION TYPE:
Subjective Short Answer
HAS VARIABLES:
False
ANSWER:
A physical star is the easiest topology to setup and expand. You are only limited by
your available ports. You can easily expand the number of ports by adding yet
another device and forming an extended star. The centralized design makes
monitoring and managing network traffic easier. With a bus, the bandwidth is limited
to 10Mbps and half-duplex mode. A star can operate at much higher speeds and, if a
switch is used, is capable of operating in full-duplex mode. There is only one main
disadvantage-that is that the central device represents a single point of failure.
POINTS:
1
REFERENCES:
Physical Star Topology
QUESTION TYPE:
Subjective Short Answer
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:47 PM
44. Describe the structure of an Ethernet frame.
ANSWER:
An Ethernet frame is composed of three parts. The first part is called the header. It contains
the source and destination MAC addresses along with a 2-byte type field. The type field is a
code that tells what network protocol is being used in the data portion of the frame. The
second part of the frame is the data portion, which is referred to as the payload. This is the
actual data that an application is sending across the network. The part also includes the
header from the network protocol. The last part of a frame is the FCS, which contains an
error-checking code called a CRC. It is the result of applying a mathematical formula to the
data portion of the frame. It is used to verify that the frame was not damaged in transmission.
POINTS:
1
REFERENCES:
Ethernet Networks
QUESTION TYPE:
Subjective Short Answer
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:34 PM
DATE MODIFIED:
7/19/2019 2:34 PM
45. What is CSMA/CD and how does it work?
ANSWER:
CSMA/CD is the media access method used by Ethernet, which is a set of rules that govern
how and when a device can transmit on an Ethernet network. When two devices transmit a
signal at the same time, they cause a collision to occur. Then the devices must try to transmit
again, and again, causing a bottleneck. To avoid these collisions, CSMA/CD says that a
device must first listen to see whether it can detect any other signal on the medium. If no
other signal is detected, then the device can transmit. If another device transmits at the same
time and a collision occurs, then both transmitting stations must wait for a random period
before they can try to transmit again.
POINTS:
1
REFERENCES:
Ethernet Networks
Name:
Class:
Date:
Name:
Class:
Date:
