Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 1
1. When a NIC is in promiscuous mode, it will process only the frames in which the destination MAC address
matches its own MAC address.
a.
True
b.
False
ANSWER:
False
POINTS:
1
REFERENCES:
NIC Basics
QUESTION TYPE:
True / False
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
2. Routers do not forward broadcast packets.
a.
True
b.
False
ANSWER:
True
POINTS:
1
REFERENCES:
Routers
QUESTION TYPE:
True / False
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
3. If a router receives a packet and it does not have an entry in its routing table for the destination network, it
will send the packet to its default route, if configured.
a.
True
b.
False
ANSWER:
True
POINTS:
1
REFERENCES:
Routers Work with IP Addresses and Routing Tables
QUESTION TYPE:
True / False
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
4. A computer’s default gateway setting is the MAC address of a router on a remote network.
a.
True
b.
False
ANSWER:
False
POINTS:
1
REFERENCES:
Routers Work with IP Addresses and Routing Tables
QUESTION TYPE:
True / False
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 2
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
5. The name assigned to a wireless network is called the SSID.
a.
True
b.
False
ANSWER:
True
POINTS:
1
REFERENCES:
Wireless NICs
QUESTION TYPE:
True / False
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
6. Which device receives a frame and reads the source and destination MAC addresses before forwarding the
frame out another port?
a.
router
b.
switch
c.
repeater
d.
hub
ANSWER:
b
POINTS:
1
REFERENCES:
Basic Switch Operation
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
7. What does a switch do if it doesn’t find the destination MAC address in its switching table?
a.
sends an error to the sending device
b.
discards the frame
c.
sends an ARP to learn the MAC address
d.
forwards the frame out all ports
ANSWER:
d
POINTS:
1
REFERENCES:
Basic Switch Operation
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 3
8. Which of the following is NOT a function of a hub?
a.
cleans up the signal
b.
transmits the frame out the correct port
c.
receives the signal from a connected computer on one of its ports
d.
regenerates the signal
ANSWER:
b
POINTS:
1
REFERENCES:
Multiport Repeaters and Hubs
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
9. How does a switch “learn” MAC addresses?
a.
All the MAC addresses must be entered manually.
b.
The switch comes loaded with the most frequently used addresses.
c.
It reads the source address and keeps a record of which port the sending computer is on.
d.
The switch uses a mathematical formula to determine what the MAC address would be for each
computer connected to it.
ANSWER:
c
POINTS:
1
REFERENCES:
Basic Switch Operation
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
10. Which of the following is true about hubs?
a.
Devices on a hub have to share the available bandwidth.
b.
They can operate in full-duplex and half-duplex mode.
c.
They maintain a table of MAC addresses.
d.
They can handle several computer conversations simultaneously.
ANSWER:
a
POINTS:
1
REFERENCES:
Multiport Repeaters and Hubs
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
11. What does a switch store in its switching table?
a.
The frame’s source MAC address and the port it was received on.
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 4
b.
The frame’s destination MAC address and the port it was received on.
c.
The frame’s source IP address and the port it was received on.
d.
The frame’s destination IP address and the port it was received on.
ANSWER:
a
POINTS:
1
REFERENCES:
Network Switches
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
12. What type of frame is addressed to a specific computer?
a.
broadcast
b.
unicast
c.
multicast
d.
anycast
ANSWER:
b
POINTS:
1
REFERENCES:
Network Interface Cards
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
13. Just as a switch keeps records of MAC addresses that it has learned, so does your computer. What protocol
does your computer use to learn MAC addresses?
a.
ARP
b.
ICMP
c.
DHCP
d.
IP
ANSWER:
a
POINTS:
1
REFERENCES:
Network Switches
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
14. What does it mean if the full-duplex indicator on a switch port is on?
a.
The switch is detecting collisions.
b.
The port can transmit and receive frames simultaneously.
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 5
c.
Bandwidth sharing is enabled.
d.
The MAC address table is full.
ANSWER:
b
POINTS:
1
REFERENCES:
Network Switches
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
15. What component of the computer contains a MAC address?
a.
motherboard
b.
NIC
c.
CPU
d.
BIOS
ANSWER:
b
POINTS:
1
REFERENCES:
NIC Basics
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
16. A MAC address is composed of two 24-bit numbers. What does the first 24-bit number represent?
a.
A unique serial number assigned by the manufacturer.
b.
The address it uses for a multicast packet.
c.
The decryption key used for security purposes.
d.
The organizationally unique identifier.
ANSWER:
d
POINTS:
1
REFERENCES:
NIC Basics
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
17. What command issued from the command prompt will show the route that a packet travels from the issuing
computer to another computer?
a.
route
b.
tracert
c.
ipconfig
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 6
d.
arp
ANSWER:
b
POINTS:
1
REFERENCES:
Routers Work with IP Addresses and Routing Tables
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
18. What is the purpose of the default route?
a.
It serves as a guideline for how to configure routes.
b.
It’s a route set by Microsoft so that all information comes to their servers first.
c.
It’s where the router sends all packets with destination addresses of which it has no knowledge.
d.
It’s a route that all routers use to get to the Internet.
ANSWER:
c
POINTS:
1
REFERENCES:
Routers Work with IP Addresses and Routing Tables
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
19. A wireless access point is most like which other network device, in that all computers send signals through
it to communicate with other computers?
a.
switch
b.
router
c.
hub
d.
modem
ANSWER:
c
POINTS:
1
REFERENCES:
Wireless Access Points
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
20. When referring to network bandwidth, what is the basic unit of measurement?
a.
bytes per second
b.
bits per second
c.
bandwidth per second
d.
bytes per minute
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 7
ANSWER:
b
POINTS:
1
REFERENCES:
Multiport Repeaters and Hubs
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
21. In some wireless network configurations, a computer must send a special message to the AP before it can
transmit data. What is this message called?
a.
RTS
b.
ARP
c.
CTS
d.
DNS
ANSWER:
a
POINTS:
1
REFERENCES:
Basic AP Operation
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
22. Which of the following is true about a NIC?
a.
For incoming messages, it creates frames from packets.
b.
For outgoing messages, it assembles bit signals into frames.
c.
For incoming messages, it adds a source and destination MAC address.
d.
For outgoing messages, it converts frame data into bit signals.
ANSWER:
d
POINTS:
1
REFERENCES:
NIC Basics
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
23. What command would you issue from the command prompt to test whether your computer has connectivity
to the network?
a.
ping IPaddress
b.
arp -d IPaddress
c.
ipconfig IPaddress
d.
ipconfig /all
ANSWER:
a
Name:
Class:
Date:
Copyright Cengage Learning. Powered by Cognero.
Page 8
POINTS:
1
REFERENCES:
Network Switches
QUESTION TYPE:
Multiple Choice
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
24. Which of the following are features of a router? (Choose all that apply)
a.
connects computers to the LAN
b.
connects LANs to one another
c.
works with MAC addresses
d.
forwards broadcast packets
e.
works with packets
ANSWER:
b, e
POINTS:
1
REFERENCES:
Routers
QUESTION TYPE:
Multiple Response
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 3:14 PM
25. Which of the following are true about routers? (Choose all that apply.)
a.
break up a network into functional groups
b.
make larger broadcast domains
c.
work with IP addresses
d.
forward broadcasts out all connected ports
e.
allow computers on different networks to communicate
ANSWER:
a, c, e
POINTS:
1
REFERENCES:
Routers
QUESTION TYPE:
Multiple Response
HAS VARIABLES:
False
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 3:15 PM
26. The ______________ address is composed of two 24-bit numbers.
ANSWER:
MAC
POINTS:
1
REFERENCES:
NIC Basics
QUESTION TYPE:
Completion
HAS VARIABLES:
False
Name:
Class:
Date:
Name:
Class:
Date:
Name:
Class:
Date:
POINTS:
1
37. indicates that the wireless computer can transmit data
ANSWER:
g
POINTS:
1
38. device that connects a computer with the network medium
ANSWER:
h
POINTS:
1
39. designated port on a hub or switch used to connect to another hub or switch
ANSWER:
i
POINTS:
1
40. amount of data that can be transferred on a network in a specified interval
ANSWER:
j
POINTS:
1
41. Why is the NIC considered the “gatekeeper”?
ANSWER:
The NIC’s responsibility is to examine every frame that is received and either allow it access
to the computer or reject it. In order for the frame to be accepted, the destination MAC
address must match the NIC’s MAC address, or it is refused. There are two exceptions to this
rule. If the destination MAC address is a broadcast, then the NIC accepts it. If the NIC is put
in promiscuous mode, then it will accept all frames.
POINTS:
1
REFERENCES:
NIC Basics
QUESTION TYPE:
Subjective Short Answer
HAS VARIABLES:
False
STUDENT ENTRY MODE:
Basic
DATE CREATED:
7/19/2019 2:33 PM
DATE MODIFIED:
7/19/2019 2:33 PM
42. What are the major differences between a hub and a switch?
ANSWER:
The major difference is that switches are intelligent. They examine each frame that they
receive for the destination MAC address and then send the frame out the correct port for that
address. A hub simply accepts a frame from one of its ports and then sends it out all ports. A
switch also keeps a table of MAC addresses so that it knows where to send a frame. Because
a switch can control where it sends a frame, devices that are connected to a switch can
communicate at the same time, allowing each device to access the full network bandwidth.
With a hub, only one device can transmit at a time so the bandwidth is shared among all
connected devices. Also, because a switch controls the flow of frames, there is little chance
of a collision. In a hub, collisions might occur frequently when under heavy use.
POINTS:
1
REFERENCES:
Network Switches
QUESTION TYPE:
Subjective Short Answer
Name:
Class:
Date:
Name:
Class:
Date:
Name:
Class:
Date:
