Machine Tool Practices, 11e (Kibbe)
Section B – Hand Tools
1) Two basic principles always taken into consideration by persons familiar with the proper use
of shop pressers are:
A) Personal safety and the care of the workpiece to prevent it from being damaged
B) Care not to overload the press by tying to press an oversized part and personal safety
C) Always use the largest press available for every job as the part being pressed might stick half
way through with a small press. Personal safety
D) Care should be taken not to press too fast, as this creates friction which produces heat
2) You can use the arbor press or shop press to:
A) Drill holes in metal parts
B) Install and remove mandrels, bushings, bearings and shafts
C) Make keyseats on shafts
D) All of the above
3) An arbor press designed with a rack and pinion is what type?
A) Hydraulic
B) Mechanical
C) Gear driven
D) Hydro-mechanical
34) To avoid failures from seizing when pressing a shaft or mandrel, you should:
A) Press them together dry
B) Apply a high– pressure lubricant to the bore and shaft
C) Use a good grade of lubricating oil on both parts and don’t stop after you start pressing
D) Used sulfurized cutting oil on both parts
45) A loose arbor press ram may cause:
A) A keyway broach to “hog” in or a bushing to twist out of alignment
B) A loss of pressure making it difficult to force a broach through the work
C) Keyway broach to twist and cause an excessively wide keyway and a mandrel to “hog” in half
way through the bore
D) None of the above
56) The amount of pressure you should apply to a bushing in an arbor press would be:
A) Just the amount needed to push it through the bore and then considerablye more force applied
to make sure it is seated
B) About 5 tons
C) Between 10 and 30 tons
D) Just the amount needed to push it through the bore and when slight additional pressure is felt,
stop pressing
67) A ball bearing that is on a shaft or in a housing should be removed:
A) By applying pressure only to the race that is supported securely
B) Only by pressing on the inner race when the outer race is in a housing or by pushing on the
outer race when the inner race is on a shaft
C) By pressing on and supporting any part of the bearing that is available
D) B and C above
78) A mandrel will slip into a bore on one of its ends. Why then does it press tightly in a bore?
A) It is made very slightly tapered so that it is somewhat larger at one end
B) It has been made rough by a knurling process in the center thus enlarging it slightly
C) The high– pressure lubricant applied to its surface causes the bore to tighten
D) It is made in a “barrel” shape so that it is slightly larger in the center that at the ends
89) What two important things should be done before pressing in a bushing?
A) Oil the bushing and start it in the bore with a hammer before you start pressing
B) Clean all the oil off the bushing and wash your hands so you won’t get contaminated
C) Chamfer and lubricate the bore
D) None of the above
910) Broaching can be done on both internal and external surfaces.
101) When using keyway broaches in an arbor press, you should avoid:
A) Using an ill– fitting guide bushing and having less than two broach teeth contacting the
workpiece
B) Lack of lubrication of the broach and using the broach on hard materials
C) Loose press rams and a lack of clearance for the broach through the press plate
D) All of the above
112) Parallel clamps are mostly used for:
A) Holding work for delicate measuring and layout setups
B) Holding hardened steel precision parallels
C) Clamping workpieces on the bench for filing and sawing
D) Clamping workpieces on machines such as drill presses
123) C-clamps are mostly used by machinists for:
A) Holding delicate measuring and layout setups
B) Holding vises on milling machines and shapers
C) Clamping workpieces on the bench for filing and sawing
D) Clamping workpieces on machines such as drill presses
134) Large water pump pliers can be used:
A) For unfinished packing nuts, pipe and pipe fittings
B) To loosen arbor nuts
C) For any bolt and nut it will extend to fit
D) All of the above
15) One type of tool that is least likely to slip when holding small parts, is the:
A) Water pump pliers
B) Parallel jaw cutting pliers
C) Slip joint pliers
D) Lever jawed wrench
146) Ball peen hammers under 10 oz. may be used for:
A) Repositioning work in a machine vise
B) General heavy bending and hammering
C) Hammering on wrench handles to break loose stubborn threads
D) Layout work
157) When adjusting a finished work piece in a machine vise, use a:
A) 8– ounce ball peen hammer
B) Maul
C) Plastic or rawhide mallet
D) 3– pound ball peen hammer
168) An advantage of the adjustable wrench is that one tool can be used for many sizes. What is
one of its disadvantages?
A) If it is adjusted too loosely, it will slip and round off the nut or bolt head. This is also hard on
the users knuckles
B) It is bulkier than an end wrench and will not fit in some places
C) A and B above
D) There are no disadvantages
179) Pipe wrenches should be used only on:
A) Nut and bolt heads
B) Ground and polished surfaces
C) Pipe and pipe fittings
D) None of the above
1820) ________ wrenches are widely used by machinists and mechanics to provide the correct
amount of tightening pressure on a screw or nut.
1921) Standard screwdrivers will slip and damage the slot if:
A) The blade is too narrow or too wide
B) The point is misshapen
C) The hardness or temper has been drawn out by overheating
D) All of the above
202) When clamping parts with finished surfaces in a bench vise:
A) A cheater should be used on the handle to gain leverage
B) They should be gripped very lightly so that rough jaws will not mar finished surfaces
C) They should be gripped very lightly so the smooth surface will not cause it to slip out of the
jaws
D) Soft jaws should be used
213) The pitch of a hacksaw blade is the same as the:
A)) Thickness of the blade
B) Set of the blade
C) Number of teeth per inch
D) Kerf cut by a blade
224) To start a hacksaw cut easily:
A) Draw the saw backwards
B) Use short quick strokes
C) Mark the starting point with a center punch
D) Mark the starting point with a file
235) The speed for hack sawing is generally ________ strokes per minute?
A) 30
B) 50
C) 70
D) 90
246) Which of the following conditions is most likely to cause a hacksaw blade to break?
A) Sawing too fast
B) Pressure on the return stroke
C) A new blade in an old cut
D) Tubing cut with a 32– tooth blade
257) Set on a hacksaw blade can be:
A) 18 teeth per inch
B) Wavy
C) .025 in.
D) 1/2 inch
268) The pitch of a hacksaw blade to cut off a piece of aluminum from a 1– inch square bar
should be:
A) Straight set
B) Wavy set
C) 32 tooth (fine)
D) 14 tooth (coarse)
279) Which of the following conditions will cause a hacksaw blade to dull quickly?
A) Too short a saw blade
B) A Too slow sawing speed that is too slow
C) No pressure on the return stroke
D) AToo fast sawing speed that is too fast
2830) A new hacksaw blade should not be used to finish a cut started with an old blade because:
A) The set would wear rapidly
B) The pitch is too coarse
C) The kerf would wear rapidly
D) It would take too long
31) The preferred hacksaw blade pitch for cutting off very thin wall tubing is:
A) 14 tooth
B) 18 tooth
C) 24 tooth
D) 32 tooth
32) A general rule when selecting a hacksaw blade is use a:
A) Blade with a least three teeth in contact with the cutting area
B) Coarse blade for hard materials
C) Fine pitch saw for soft materials
D) Blade with the greatest number of teeth per inch
33) A file that has no teeth on its edge is called a:
A) Straight edge
B) Safe edge
C) Flat edge
D) Smooth edge
34) A mill file is:
A) Milled
B) Single cut
C) Double cut
D) Square
2935) Files are cleaned with a:
A) Brush card
B) Bench brush
C) File cleaner
D) File card
306) Which of the following can be used to keep a file from pinning?
A) Vegetable oil
B) Chalk
C) A thin coat of bluing
D) Cutting oil
317) Which kind of file should be used on soft materials?
A) Knife
B) Flat
C) Curved tooth
D) Coarse
328) Which kind of file should be used to obtain a smooth finish on the workpiece?
A) Single cut
B) Cross cut
C) Smooth cut
D) Double cut
339) On which type of file is coarseness designated by a number?
A) Machine
B) Mill
C) Needle (Swiss pattern)
D) Curved tooth
3440) The life a a file is shortened by:
A) Letting one file lie on top of another
B) Filing too fast
C) Too much pressure on the file when filing
D) All of the above
3541) A flat surface may be obtained by the process of:
A) Filing only on the forward stroke
B) Short stroke filing
C) Draw filing
D) Filing only on the return stroke
3642) Pinning can cause deep scratches on a workpiece.
3743) Files do not make good pry bars because they are:
A) Too tough
B) Not long enough
C) Too brittle
D) The wrong shape
3844) File handles are used to:
A) Extend the file
B) Extend the file life
C) Protect the file
D) Protect the file user
3945) Hand reamers can be readily identified by the:
A) Markings on the neck
B) Square end on the shank
C) Length of the body
D) Length of the flutes
406) A hole with a slot in it should never be reamed with a:
A) Short starting taper reamer
B) Slightly undersized reamer
C) Straight flute reamer
D) Spiral flute reamer
417) To make a hole .002 inch larger than a nominal size:
A) Wiggle the reamer slightly in the hole
B) Use a spiral flute reamer
C) Ream with an expansion reamer, or adjustable hand reamer
D) Drill with a twist drill
428) When a reamer is rotated in reverse, it will:
A) Leave a very smooth finish
B) Reduce the heat buildup
C) Become dull very quickly
D) Break long stringy chips
439) Stock allowance in inches, for hand reaming should be between:
A) .016 to .020 in.
B) .006 to .010 in.
C) .011 to .015 in.
D) .001 to .005 in.
50) The exact size of a hand reamer is determined by:
A) Measuring over the margins with a micrometer
B) Reading the size stamped on the neck of the reamer
C) Measuring the shank diameter and adding .003 inch
D) Reaming a hole and measuring its size
51) When reaming, the:
A) Length of the flutes determines the depth of the hole
B) Holes produced by one reamer will vary in size
C) Reamer alignment is checked with a square
D) Reamer always aligns itself with the existing hole
4452) A hand reamer should be rotated backward to remove it from a hole.
4553) A hand reamer should be turned with an adjustable wrench.
4654) To reduce chatter while reaming a hole, which reamer should you select?
A) Spiral flute
B) Straight flute
C) High speed steel
D) Carbon steel
4755) Spiral pointed taps are used:
A) To tap shallow blind holes
B) As thread forming taps
C) To tap through holes
D) To tap deep holes
56) Fluteless spiral pointed taps are used to tap:
A) Deep holes
B) Tough materials
C) Holes in sheet metal
D) Nuts
4857) A set of taps consists of three taps:
A) Roughing, sizing, bottoming
B) Starting, roughing, finishing
C) Taper, plug, and bottoming
D) Starting, sizing, finishing
4958) Spiral fluted taps are used:
A) For through holesBecause they tend to push chips ahead of them
B) To cut undersized threads
C) To cut oversized threads
D) To tap deep blind holes
509) Thread forming taps:
A) Push the chips ahead of them
B) Cannot be used on a drill press
C) Produce only small chips
D) Produce no chips
60) Serial taps of the same nominal size:
A) Can be used in any sequence
B) Are used in mass production
C) Have different pitch diameters
D) Have the same pitch diameters
561) The size of a tap is marked on the:
A) End
B) Shank
C) Handle
D) Body
62) The difference between the taps in a standard (not serial) set is found on the:
A) Pitch diameter
B) Chamfer
C) Shank
D) Flutes
5263) Taps are surface treated to:
A) Be used on automatic machines
B) Improve their wear resistance
C) Improve their appearance
D) Keep them from corroding
5364) The rake angle of the cutting edge of a tap varies:
A) On thread forming taps
B) For shallow or deep holes
C) To allow lubricant to penetrate
D) For different materials
5465) Taps can be surface treated by:
A) Anodizing
B) Tempering
C) Nitriding
D) Nickel plating
5566) What type of tap should be used to push the chips ahead of the tap?
A) Gun
B) Bottoming
C) Plug
D) Thru
5667) A tap is driven with:
A) A tap handle
B) An adjustable wrench
C) A combination wrench
D) Pliers
5768) The alignment of a tap is checked with a:
A) Plum bob
B) Square
C) Dividers
D) Level
5869) To thread to the bottom of a blind hole, which tap should you use?
A) Taper
B) Pointed
C) Plug
D) Bottoming
5970) The thread length (depth) inof a tapped hole should be how many times the diameter of
the screw to achieve maximum strength of the threads?
A) One-half
B) One and one-half
C) Two and one-half
D) Three and one-half
6071) The size of a tap drill is important because it:
A) Regulates the percentage of threads
B) Determines the depth of the hole
C) Determines the size of the thread
D) Forms the major diameter
6172) Taps may break when tapping:
A) If the chips clog the flutes
B) Because the tap drill was too large
C) If the tap used is too sharp
D) If the holes are drilled too deep
73) Dull taps:
A) Should be honed more frequently
B) Should be used with slower cutting speeds
C) Produce oversized threads
D) Produced polished threads
6274) Tap cutting speeds that are too high:
A) May cause tap breakage or dulling
B) Use too much cutting oil
C) May cause burnished threads
D) All of the above
6375) Rough threads in a tapped hole can be caused by:
A) Chips clogging the flutes
B) Insufficient lubrication
C) Dull taps
D) All of the above
6476) Tap drill sizes are based upon the drill diameter being ________% of the thread size.
A) 75
B) 80
C) 90
D) 66
6577) The strength of a tapped holes is determined by:
A) The depth of thread engagement
B) The material being tapped
C) The percentage of thread depth cut
D) All of the above
6678) A die is turned with a:
A) Die handle
B) Die stock
C) Die wrench
D) Die plate
6779) A round split adjustable die is expanded and contracted by:
A) Die adjuster
B) Tapered wedges
C) Nut
D) Screw
6880) The chamfer on the cutting end of a die:
A) Provides space for cutting fluid
B) Gives extra chip clearance
C) Is unnecessary
D) Distributes the cutting action over a number of threads
6981) You have to choose between four pieces of stockrods to cut a 1/2-13 UNC thread. Which
inch diameter rod will you use?
A) .503
B) .500
C) .497
D) .515
7082) A rod should be chamfered before threading to:
A) Provide additional chip clearance
B) Make the die start easier
C) Reduce its diameter
D) Retain cutting oil
7183) The lead of a screw is:
A) Part of an engine lathe
B) The chamfer on the end of a threaded part
C) The distance that a threaded mating part will move when rotated one revolution
D) A lead bolt
7284) To check a die cut thread, use:
A) A thread pitch micrometer
B) A mating nut
C) A thread ring gage the same size as the mating part
D) Anyll of the above depending on the accuracy desired
7385) While cutting threads with a hand die, the die is frequently reversed or backed off to:
A) Cool the die
B) Lubricate the die
C) Break the chips
D) All of the above
7486) Adjustable two– piece dies are assembled:
A) With the tapered threadschamfer toward the guide
B) Without the guide
C) With the chamfer away from the guide
D) None of the above
7587) Re-threading dies are used to:
A) Re-cut rusty or damaged threads
B) Cut occasional new threads
C) Repair damaged threads on hardened bolts
D) All of the above
7688) Pedestal grinders in the machine shop are mostly used for:
A) Semi-precision grinding of parts to layout lines
B) Sharpening lawn mower and tiller blades
C) Tool grinding
D) Grinding welds and snagging
89) Some heavy duty off-hand grinders are used exclusively for rough grinding. When is it
permissible to use tool grinders for rough grinding?
A) When there is only a small amount of metal to remove
B) Never
C) When only one side of the wheel is used where tools are not sharpened
D) When only nonferrous metals are ground on aluminum oxide wheels
7790) Grinding wheels on a pedestal grinder are usually sharpened and dressed with a:
A) Diamond
B) Desmond dresser or similar device
C) Dressing stick
D) Crush roll
7891) When installing a new grinding wheel, the wheel should first be ________ tested.
A) balance
B) ring
C) crack
D) vibration
7992) On a pedestal grinder, the left side of the spindle has left-handed threads, and the right side
has right-handed threads.
8093) A ________ must be installed between the wheel and flanges on each side of the wheel.
A) lock washer
B) blotter
C) bushing
D) spacer
8194) Tools can be damaged on a pedestal grinder if they are:
A) Overheated
B) Kept too cool by frequent quenching in water
C) Ground on a freshly dressed wheel
D) Ground on a wheel that is too coarse
95) Two of the greatest safety hazards on the pedestal grinder are:
A) Getting the part too hot so it burns your fingers and using a glazed wheel
B) Not using gloves and having the wrong grade wheel
C) Long hair hanging near a rotating wheel and the tool rest and spark guard out of adjustment
D) Lack of a properly dressed wheel and rough grinding on a machine reserved for tool grinding
96) Nonferrous metals such as aluminum and brass should never be ground on the aluminum
oxide wheels found on most pedestal grinders.
