Chapter 13 – Project Scheduling
True / False
1. Critical activities are those that can be delayed without delaying the entire project.
a. True
b. False
2. PERT and CPM are applicable only when there is no dependence among activities.
a. True
b. False
3. A path through a project network must reach every node.
a. True
b. False
4. A critical activity can be part of a noncritical path.
a. True
b. False
5. When activity times are uncertain, an activity’s most likely time is the same as its expected time.
a. True
b. False
6. The earliest finish time for the final activity is the project duration.
a. True
b. False
7. The length of time an activity can be delayed without affecting the project completion time is the slack.
a. True
b. False
Chapter 13 – Project Scheduling
8. When activity times are uncertain, total project time is normally distributed with mean equal to the sum of the means of
all of the critical activities.
a. True
9. Crashing refers to an unanticipated delay in a critical path activity that causes the total time to exceed its limit.
a. True
b. False
10. Constraints in the LP models for crashing decisions are required to compare the activity’s earliest finish time with the
earliest finish time of each predecessor.
a. True
b. False
11. The project manager should monitor the progress of any activity with a large time variance even if the expected time
does not identify the activity as a critical activity.
a. True
b. False
12. The variance in the project completion time is the sum of the variances of all activities in the project.
a. True
b. False
13. The latest finish time for an activity is the largest of the latest start times for all activities that immediately follow the
activity.
a. True
b. False
Chapter 13 – Project Scheduling
14. The earliest start time for an activity is equal to the smallest of the earliest finish times for all its immediate
predecessors.
a. True
b. False
15. The linear programming model for crashing presented in the textbook assumes that any portion of the activity crash
time can be achieved for a corresponding portion of the activity crashing cost.
a. True
b. False
16. All activities on a critical path have zero slack time.
a. True
b. False
17. The difference between an activity’s earliest finish time and latest finish time equals the difference between its earliest
start time and latest start time.
a. True
b. False
18. It is possible to have more than one critical path at a time.
a. True
b. False
19. Activities require time to complete while events do not.
a. True
b. False
20. Precedence relationships among activities is critical in CPM analysis but not in PERT.
a. True
b. False
Chapter 13 – Project Scheduling
21. The normal distribution tends to be a better approximation of the distribution of total time for shorter projects where
the critical path has relatively few activities.
a. True
b. False
Multiple Choice
22. PERT and CPM
a. are most valuable when a small number of activities must be scheduled.
b. have different features and are not applied to the same situation.
c. do not require a chronological relationship among activities.
d. have been combined to develop a procedure that uses the best of each.
23. Which is not a significant challenge of project scheduling?
a. deadlines exist.
b. activities are independent.
c. many employees could be required.
d. delays are costly.
24. Arcs in a project network indicate
a. completion times.
b. precedence relationships.
c. activities.
d. the critical path.
25. The critical path
a. is any path that goes from the starting node to the completion node.
b. is a combination of all paths.
c. is the shortest path.
d. is the longest path.
Chapter 13 – Project Scheduling
26. The earliest start time rule
a. compares the starting times of all activities for successors of an activity.
b. compares the finish times for all immediate predecessors of an activity.
c. determines when the project can begin.
d. determines when the project must begin.
27. Activities following a node
a. can begin as soon as any activity preceding the node has been completed.
b. have an earliest start time equal to the largest of the earliest finish times for all activities entering the node.
c. have a latest start time equal to the largest of the earliest finish times for all activities entering the node.
d. None of the alternatives is correct.
28. Activities G, P, and R are the immediate predecessors for activity W. If the earliest finish times for the three are 12,
15, and 10, then the earliest start time for W
a. is 10.
b. is 12.
c. is 15.
d. cannot be determined.
29. Activities K, M and S immediately follow activity H, and their latest start times are 14, 18, and 11. The latest finish
time for activity H
a. is 11.
b. is 14.
c. is 18.
d. cannot be determined.
30. When activity times are uncertain,
a. assume they are normally distributed.
b. calculate the expected time, using (a + 4m + b)/6.
c. use the most likely time.
d. calculate the expected time, using (a + m + b)/3.
31. To determine how to crash activity times
Chapter 13 – Project Scheduling
a. normal activity costs and costs under maximum crashing must be known.
b. shortest times with crashing must be known.
c. realize that new paths may become critical.
d. All of the alternatives are true.
32. Slack equals
a. LF − EF.
b. EF − LF.
c. EF − LS.
d. LF − ES.
33. Activities with zero slack
a. can be delayed.
b. must be completed first.
c. lie on a critical path.
d. have no predecessors.
34. In deciding which activities to crash, one must
a. crash all critical activities.
b. crash largest-duration activities.
c. crash lowest-cost activities.
d. crash activities on the critical path(s) only.
35. For an activity with more than one immediate predecessor activity, which of the following is used to compute its
earliest finish (EF) time?
a. the largest EF among the immediate predecessors.
b. the average EF among the immediate predecessors.
c. the largest LF among the immediate predecessors.
d. the difference in EF among the immediate predecessors.
36. Which of the following is always true about a critical activity?
a. LS = EF.
b. LF = LS.
c. ES = LS.
Chapter 13 – Project Scheduling
d. EF = ES.
37. For an activity with more than one immediate successor activity, its latest-finish time is equal to the
a. largest latest-finish time among its immediate successors.
b. smallest latest-finish time among its immediate successors.
c. largest latest-start time among its immediate successors.
d. smallest latest-start time among its immediate successors.
38. Which of the following is a general rule for crashing activities?
a. Crash only non-critical activities.
b. Crash activities with zero slack.
c. Crash activities with the greatest number of predecessors.
d. Crash the path with the fewest activities.
39. To calculate an activity’s latest finish time, you should consider its
a. predecessors’ latest finish times
b. predecessors’ latest start times
c. successors’ earliest start times
d. successors’ latest start times
40. A critical activity is
a. an activity that consumes no time but shows precedence between events.
b. a milestone accomplishment within the project.
c. an activity with zero slack.
d. the beginning of an event.
41. The main difference between CPM and PERT is
a. the use of different activity time estimates.
b. PERT analysis is less expensive to conduct.
c. PERT lends itself to computerization while CPM networks must be constructed manually.
d. CPM integrates time and cost performance while PERT is based solely on time performance.
Chapter 13 – Project Scheduling
42. In PERT, the activity duration time is equal to the
a. pessimistic time.
b. optimistic time.
c. most likely time.
d. mean duration.
43. In CPM, for activities with more than one immediate predecessor activity, which of the following is used to compute
its earliest finish (EF) time
a. largest EF among the immediate predecessors
b. smallest LF among the immediate predecessors
c. smallest EF among the immediate predecessors
d. average of EFs among the immediate predecessors
44. A critical activity is one that
a. is preventing another activity from being started
b. has no room for schedule slippage
c. must be started immediately
d. represents a milestone event
Subjective Short Answer
45. From this schedule of activities, draw the PERT/CPM network.
Activity Immediate
Predecessor
A —
B A
C B
D B
E A
F C, D
G E, F
Chapter 13 – Project Scheduling
46. From this PERT/CPM network, determine the list of activities and their predecessors.
47. A cookie recipe gives the following numbered steps.
1. Preheat oven.
2. Grease cookie sheets.
3. Cream shortening and sugar.
4. Add eggs and flavoring.
5. Measure and sift dry ingredients.
6. Add dry ingredients to mixture.
7. Drop by spoonfuls onto sheets and bake for 10 minutes.
Although the steps are numbered, they do not always reflect immediate precedence relationships. Develop a table that lists
the immediate predecessors for each activity.
Chapter 13 – Project Scheduling
48. A senior MIS design class project team has developed the following schedule of activities for their project, using their
best estimate of completion times. Both written and oral reports are required. Draw the project network. Can they
complete the project in the 38 class days remaining until the end of the semester?
Activity Time Immediate Predecessor
A. Find client 4 —
B. Write prospectus 2 A
C. Obtain approval from client and professor 3 B
D. Complete programming 12 C
E. Do industry background research 10 —
F. Write final paper 6 D, E
G. Write oral report 5 D, E
49. A project network is shown below. Use a forward and a backward pass to determine the critical path, and then fill out
the table below. Activity times are in weeks.
Chapter 13 – Project Scheduling
Activity Precedence
Activities Activity
Time (weeks)
ES
LS
EF
LF
Slack Critical
Path?
A
B
C
D
E
F
G
H
I
Now assume that the times listed are only the expected times instead of being fixed times. Is the probability of being
finished in fewer than 25 weeks more or less than 50%?
Chapter 13 – Project Scheduling
50. A project network is shown below. Use a forward and a backward pass to determine the critical path, and then fill out
the table below. Activity times are in weeks.
Activity Precedence
Activities Activity
Time (weeks)
ES
LS
EF
LF
Slack Critical
Path?
A
B
C
D
E
F
G
H
I
Now assume that the times listed are only the expected times instead of being fixed times. Is the probability of being
finished in more than 28 weeks more or less than 50%?
Chapter 13 – Project Scheduling
51. Use the following network of related activities with their duration times (weeks) to complete a row for each activity
under the column headings below.
Activity Immediate
Predecessors Activity
Time (weeks)
ES
LS
EF
LF
Slack Critical
Path?
A
B
C
D
E
F
Chapter 13 – Project Scheduling
G
H
52. Use the following network of related activities with their duration times (weeks) to complete a row for each activity
under the column headings below.
Activity Immediate
Predecessors Activity
Time (weeks)
ES
LS
EF
LF
Chapter 13 – Project Scheduling
Slack Critical
Path?
A
B
C
D
E
F
G
H
I
J
53. Given the following network with activities and times estimated in days,
Chapter 13 – Project Scheduling
Activity Optimistic Most
Probable Pessimistic
A 2 5 6
B 1 3 7
C 6 7 10
D 5 12 14
E 3 4 5
F 8 9 12
G 4 6 8
H 3 6 8
I 5 7 12
J 12 13 14
K 1 3 4
a. What are the critical path activities?
b. What is the expected time to complete the project?
c. What is the probability the project will take more than 28 days to complete?
Chapter 13 – Project Scheduling
54. The critical path for this network is A – E – F and the project completion time is 22 weeks.
Activity Normal
Time Crash
Time Normal
Cost Crash
Cost
A 12 8 8,000 12,000
B 14 10 5,000 7,500
C 8 8 10,000 10,000
D 5 3 6,000 8,000
E 4 3 5,000 7,000
F 6 5 9,000 12,000
