11) In the figure above, which structure can change to regulate the amount of CO2 entering the
leaf?
A) structure A
B) structure B
C) structure C
D) structure D
12) In the figure above, if the leaf is like a solar panel receiving light energy and converting it to
another form of energy, structure A is like what part of the solar panel?
A) the clear covering that allows sunlight in where it can be converted to another type of energy
B) the wires leading the transformed energy to the point of energy use or storage
C) the point of attachment of the solar panel to a rooftop
D) the cells in the panel that trap light energy
31.3 Scenario Questions
After reading the paragraph below, answer the questions that follow
The redwood groves in Northern California are one of America’s greatest natural resources.
Redwoods can live more than 2,000 years and grow taller than 350 feet. When tourism became
popular in the late 1800s, large tunnels were cut through the center of several of these giant trees
to allow wagons to pass through (and to attract tourists to the location). Even today, visitors wait
in line to be photographed driving their cars through a tunnel. When the groves were converted
into national parks, the tunneling was discontinued, but several tunneled trees are still alive.
1) Which of the following correctly lists the sequence of tissues a tunnel would pass through
(starting from the outer surface of the tree and passing through the central core)?
A) cork, cork cambium, secondary phloem, vascular cambium, sapwood, heartwood
B) epidermis, cortex, primary phloem, primary xylem, heartwood, sapwood
C) heartwood, wood rays, cork cambium, secondary xylem, secondary phloem, vascular
cambium
D) bark, wood rays, growth rings, lateral meristems, primary phloem, secondary phloem
