1. Why should a driveshaft maintain flexibility while continuously transferring torque between powertrain components?
a.
drivetrain components change angles in relation to each other during operation
b.
must continuously change length as drive axles react to torque and road changes
c.
driveshafts expand and contract with temperature changes
d.
all of the above
d
2. What factors determine the required driveshaft diameter and wall thickness?
a.
maximum torque load
b.
gross vehicle weight
c.
type of operation
d.
all of the above
d
3. Which of the following is a function of the slip yoke used on a driveshaft?
a.
slips to dampen clutch engagement and road shock
b.
allows the driveshaft to change length as differential carrier operating angle changes
c.
permits the transmission slide back for service
d.
all of the above
ANSWER:
b
4. Which of the following components consists of a hardened, splined stubb, welded to the end of a driveshaft tube, and
mates to a yoke with matching internal splines?
a.
universal joint
b.
slip yoke
c.
hanger bearing
d.
cardan joint
ANSWER:
b
5. Which of the following components contains a forged journal cross and trunnions?
a.
slip yoke
b.
center support
c.
universal joint
d.
hanger bearing
6. When a universal joint assembly is equipped with a standpipe, what is the function of the standpipe?
a.
improves access to the zerk fittings
b.
aligns the trunnions during assembly
c.
prevents reverse flow of hot lubricant during operation
d.
all of the above
ANSWER:
7. Which of the following terms is another way of describing a U-joint cross?
a.
spider
b.
hanger
c.
yoke
d.
spline
8. When a one-piece, parallel-joint driveline arrangement with 2 universal joints is used, which of its angles must be equal
and opposite?
a.
working angles of its two U- joints
Name:
Class:
Date:
b.
angles of both mating yokes
c.
angle of the transmission output shaft and the axle pinion shaft
d.
all of the above
9. Which of the following describes a broken back driveline arrangement?
a.
working angles of its U-joints are equal
b.
companion flanges or yokes are not parallel
c.
both A and B
d.
neither A nor B
10. Which of the following would represent ideal operating conditions for a pair of universal joints on a propeller shaft?
a.
maximum operating angle of 3 degrees
b.
minimum operating angle of 1/2 degree
c.
operating angles each U-joint should be within 1 degree
d.
all of the above
d
11. What is usually considered to be the maximum recommended length for a single-piece driveshaft operating at speeds
of 3,000 rpm?
a.
50 inches (127 centimeters)
b.
70 inches (178 centimeters)
c.
90 inches (228 centimeters)
d.
95 inches (240 centimeters)
b
12. Which of the following operating conditions requires the most frequent lubrication of the driveshaft?
a.
4×4 vocational off-highway
b.
pick-up and delivery
c.
linehaul trucking
d.
less-than-load
13. A technician greasing a driveshaft slip spline assembly applies lubricant until it appears at the pressure relief hole.
What should be done next?
a.
cover the relief hole with a finger and add some more lubricant
b.
cease applying lube to avoid over-greasing
c.
continue applying lube until it appears at the slip yoke seal
d.
both A and C
14. How often should a typical driveshaft hanger bearing be lubricated?
a.
when U-joints are lubed
b.
they are usually factory lubricated and are not serviceable
c.
each time the slip yoke is lubed
d.
both A and C
Name:
Class:
Date:
15. Which of the following types of universal joint damage would most likely result from improper installation?
a.
galling
b.
spalling
c.
pitting
d.
brinelling
d
16. When are the two universal joints on a driveshaft operating in-phase?
a.
transmission and rear axle are on the same horizontal plane
b.
the two shaft sections are on the same vertical plane
c.
the slip-yoke lugs and the tube-yoke lugs are aligned with each other
d.
all of the above
17. All of the following conditions can cause driveshaft vibration EXCEPT:
a.
driveshaft out-of-balance
b.
insufficient difference in U-joint operating angles
c.
improper phasing
d.
unequal U-joint working angles
b
18. When lubricating universal joints, which of the following is best practice?
a.
apply grease until you hear the first trunnion seal pop
b.
pump grease until it exits from all four trunnion seals
c.
apply two shots of grease per trunnion
d.
disassemble and hand pack each bearing cap
b
19. Which of the following are recommended lubricants for heavy-duty truck U-joints?
a.
lithium-based grease with EP additives
b.
NLGI grade 1 or 2 grease
c.
NLGI grade 3 or 4 grease
d.
both A and B
d
20. When greasing a driveshaft U-joint, grease exits from three trunnion seals but not the fourth. What should be done
next?
a.
heat the trunnion with a rosebud
b.
loosen the bearing cap on the affected trunnion and try again
c.
remove the U-joint and hand pack each bearing cap
d.
replace the U-joint
b
21. What is used on a driveline hanger bearing to buffer driveshaft vibrations and road shock?
a.
coaxial springs
b.
rubber insulators
Name:
Class:
Date:
c.
gusset braces
d.
vertical springs
22. What is usually regarded as the absolute maximum length a driveshaft should be without adding a center support
bearing?
a.
70-inches (178 cm)
b.
75-inches (190 cm)
c.
80-inches (203 cm)
d.
90-inches (228 cm)
23. Technician A says that as driveshafts speeds increase, permissable U-joint working angles also increase. Technician B
says that when a truck diesel engine is run at a rated speed and the transmission is in overdrive, driveshaft speeds can
exceed 3000 rpm. Who is correct?
a.
Technician A only
b.
Technician B only
c.
Both A and B
d.
Neither A nor B
24. Technician A says that a driveshaft with U-joints speeds up and slows down once per rotation. Technician B says that
to avoid torsional vibrations, the rear U-joint needs to cancel out the non-uniform rotation of the forward U-joint. Who is
correct?
a.
Technician A only
b.
Technician B only
c.
Both A and B
d.
Neither A nor B
25. If a driveshaft is assembled out-of-phase which of the following must have occured?
a.
U-joint assembled backward
b.
transmission yoke has been changed
c.
differential carrier yoke has been changed
d.
driveshaft has been separated at the slip splines
26. Technician A says that to properly lubricate a driveshaft U-joint with twin zerks, grease must be pumped into both
nipples. Technician B says that if grease exits all four trunnion seals on a U-joint, it indicates that it has been properly
greased and purged. Who is correct?
a.
Technician A only
b.
Technician B only
c.
Both A and B
d.
Neither A nor B
27. What is the function of the hanger bearing shim pack used between the bearing mount and the chassis crossmember?
a.
dampens chassis vibrations
b.
dampens road shock
c.
sets driveshaft angles
d.
both A and B
28. Technician A says that driveshaft U-joints are expensive and engineered to last the life of the vehicle. Technician B
says that replacing driveline propeller shaft assemblies is a common shop practice. Who is correct?
a.
Technician A only
b.
Technician B only
c.
Both A and B
d.
Neither A nor B
Name:
Class:
Date:
d
29. Which of the following methods of separating a U-joint from a driveshaft yoke when it is on the truck, is preferred?
a.
hydraulic jack on yoke hub
b.
50 lb (25 kg) slide hammer on yoke
c.
16 lb (7 kg) sledge hammer
d.
two-jaw U-joint puller
d
30. A driveshaft U-joint has failed. Technician A says that the complete driveshaft assembly should be removed from the
chassis to replace the U-joint. Technician B says that the driveshaft must be separated at the slip spline to make the repair.
Who is correct?
a.
Technician A only
b.
Technician B only
c.
Both A and B
d.
Neither A nor B
d
31. When chips and flakes of metal separate from a U-joint trunnion race due to metal fatigue, how would the failure be
categorized?
a.
brinelling
b.
false brinelling
c.
spalling
d.
galling
32. Which of the following is recommended to be applied to the exterior of a set of U-joint bearing caps before
installation into the yokes?
a.
never-seize compound
b.
engine lube
c.
chassis grease
d.
silicone RTV compound
33. When installing a U-joint into a heavy-duty truck driveshaft, where should the lube zerk be located?
a.
180 degrees offset from the zerk at the other end
b.
90 degrees offset from the zerk at the other end
c.
aligned with the zerk at the other end
d.
it does not matter
34. Technician A says that U-joint bearing caps and trunnions once in use should be regarded as a matched set and not
interchangeable. Technician B says that when one U-joint fails on a driveshaft, its opposite one must also be changed.
Who is correct?
a.
Technician A only
b.
Technician B only
c.
Both A and B
d.
Neither A nor B
35. What equipment is required to test and balance a driveshaft when it is on chassis?
a.
electronic inclinometer
b.
strobe light and balance sensor
c.
protractor and chalkline
d.
good intuition
b
Name:
Class:
Date:
36. When attempting to dynamically balance a truck driveline, which of the following must be done?
a.
all the wheels must be off the ground
b.
the frame must be level
c.
the transmission and differential carrier must be at the same angle raised as on the ground
d.
all of the above
d
37. When checking the dynamic balance of a truck driveshaft, an initial spin up indicates the balance is out. Which of the
following should be performed FIRST before proceeding?
a.
remove any existing balance weights with a chisel
b.
clamp one steel washer to the counterbalance position
c.
remove the propeller shaft assembly
d.
replace both the U-joints
38. When performing dynamic balance of a truck driveshaft using counterweights and a hose clamp, where should the
hoseclamp worm be positioned when testing?
a.
180 degrees offset from counterweight
b.
90 degrees offset from counterweight
c.
over the counterweight
d.
it does not matter
39. What is the recommended tool used to measure the operating angles of driveline components?
a.
protractor
b.
electronic inclinometer
c.
balance sensor and strobe
d.
carpenter’s level
b
40. Which of the following methods can be used to adjust drive carrier operating angle when correcting driveline angles
on a truck with a leaf spring rear suspension?
a.
cold bend axle housing
b.
install axle shim wedges
c.
rotate axle stubbs
d.
shim the U-joint
b
41. If you add shims to a longitudinal torque rod attached to the forward drive axle carrier in a tandem drive truck, which
of the following will result?
a.
only the working angles of the U-joints in the front driveshaft will change
b.
only the working angles of the U-joints in the rear driveshaft will change
c.
the working angles of the U-joints in both driveshafts will change
d.
no U-joint working angles will be affected
42. What instrument should be used to measure driveshaft runout?
a.
inclinometer
b.
dial indicator
c.
outside micrometer
d.
bore gauge
Name:
Class:
Date:
ANSWER:
b
43. When measuring the total indicated runout (TIR) of a driveshaft, you record 0.003” (0.08 mm) positive and 0.005”
(0.13 mm) negative through one shaft revolution. What is the TIR?
a.
0.015 inch (0.05 mm)
b.
minus 0.002 inch (minus 0.05 mm)
c.
0.008 inch (0.21 mm)
d.
0.002 inch (0.05 mm)
ANSWER:
44. Which of the following would indicate that a driveshaft was likely ovalled when measuring it with a dial indicator?
a.
needle deflects twice in one revolution
b.
needle deflects only on the negative side of the scale
c.
needle deflects only on the positive side of the scale
d.
needle travel greater than 0.010 inch (0.25 mm)
45. Technician A says that a PTO driveshaft should be made of a solid steel bar when the auxiliary it drives has to be
driven at a speed greater than 1200 rpm. Technician B says that solid PTO driveshafts can be made from round section,
square section, and hex section steel stock. Who is correct?
a.
Technician A only
b.
Technician B only
c.
Both A and B
d.
Neither A nor B
ANSWER:
b
46. Technician A says that the maximum permissable operating angles of U-joints decrease as driveshaft rpm increases.
Technician B says that a driveshaft that turns at a maximum of 3500 rpm should have U-joint working angles of 3 degrees
or less. Who is correct?
a.
Technician A only
b.
Technician B only
c.
Both A and B
d.
Neither A nor B
ANSWER:
47. Technician A says that a driveshaft with U-joints speeds up and slows down twice per full rotation. Technician B says
that minimize torsional vibrations, U-joint working angles should be set as high as possible. Who is correct?
a.
Technician A only
b.
Technician B only
c.
Both A and B
d.
Neither A nor B
ANSWER:
48. Which of the following driveshaft tube ratings would be most common in linehaul highway tractors?
a.
1500 series
b.
1600 series
c.
1700 series
d.
1800 series
49. Technician A says that because PTO driveshafts are commonly driven at speeds lower than 1200 rpm, solid steel stock
shafts can be used. Technician B says that because PTO driveshafts are used intermittently and at lower speeds, precision
balancing is not usually required. Who is correct?
a.
Technician A only
b.
Technician B only
c.
Both A and B
d.
Neither A nor B
ANSWER:
Name:
Class:
Date:
50. When a 1/4 inch (6 mm) shim is added to a rear carrier torque arm, by how much will the rear carrier U-joint
operating angle be altered?
a.
1/4 degree
b.
1/2 degree
c.
3/4 degree
d.
1 degree
