Test Bank—Chapter Two (Data Manipulation)
The following table is from Appendix C of the text. It is included here so that it can be incorporated in tests
for student reference. Questions in this test bank refer to this table as the “language description table.”
Op–
code Operand Description
1 RXY LOAD the register R with the bit pattern found in the memory cell whose address is XY.
Example: 14A3 would cause the contents of the memory cell located at address A3 to be placed
in register 4.
2 RXY LOAD the register R with the bit pattern XY.
Example: 20A3 would cause the value A3 to be placed in register 0.
3 RXY STORE the bit pattern found in register R in the memory cell whose address is XY.
Example: 35B1 would cause the contents of register 5 to be placed in the memory cell whose
address is B1.
4 0RS MOVE the bit pattern found in register R to register S.
Example: 40A4 would cause the contents of register A to be copied into register 4.
5 RST ADD the bit patterns in registers S and T as though they were two’s complement representations
and leave the result in register R.
Example: 5726 would cause the binary values in registers 2 and 6 to be added and the sum placed
in register 7.
6 RST ADD the bit patterns in registers S and T as though they represented values in floating-point
notation and leave the floating-point result in register R.
Example: 634E would cause the values in registers 4 and E to be added as floating-point values
and the result to be placed in register 3.
7 RST OR the bit patterns in registers S and T and place the result in register R.
Example: 7CB4 would cause the result of ORing the contents of registers B and 4 to be placed in
register C.
8 RST AND the bit patterns in register S and T and place the result in register R.
Example: 8045 would cause the result of ANDing the contents of registers 4 and 5 to be placed in
register 0.
9 RST EXCLUSIVE OR the bit patterns in registers S and T and place the result in register R.
Example: 95F3 would cause the result of EXCLUSIVE ORing the contents of registers F and 3 to
be placed in register 5.
A R0X ROTATE the bit pattern in register R one bit to the right X times. Each time place the bit that
started at the low-order end at the high-order end.
Example: A403 would cause the contents of register 4 to be rotated 3 bits to the right in a circular
fashion.
B RXY JUMP to the instruction located in the memory cell at address XY if the bit pattern in register R
is equal to the bit pattern in register number 0. Otherwise, continue with the normal sequence of
execution. (The jump is implemented by copying XY into the program counter during the execute
phase.)
Example: B43C would first compare the contents of register 4 with the contents of register 0. If
the two were equal, the pattern 3C would be placed in the program counter so that the next
instruction executed would be the one located at that memory address. Otherwise, nothing would
be done and program execution would continue in its normal sequence.
C 000 HALT execution.
Example: C000 would cause program execution to stop.
Multiple Choice Questions
1. Which of the following is not contained in a CPU?
A. Instruction register B. Program counter
C. General-purpose register D. Memory cell
2. Which of the following instructions (as described in the language description table) changes the contents
of a memory cell?
A. 10AB B. 20AB C. 30AB D. 40AB
3. Which of the following instructions (as described in the language description table) places 00000000 in
register A?
A. 1A00 B. 2A00 C. 3A00 D. 200A
4. Which of the following instructions (as described in the language description table) places 00000000 in
register 5?
A. 25FF B. 9555 C. 15FF D. 8555
5. Which of the following instructions (as described in the language description table) will not change the
contents of register 5?
A. 1508 B. 2508 C. A503 D. A508
6. Which of the following instructions (as described in the language description table) is equivalent to
requesting that register A be rotated to the left by three bits?
A. AA05 B. AA03 C. AA08 D. AA01
7. Which of the following instructions (as described in the language description table) changes the contents
of register 7?
A. 4077 B. 4075 C. 4057 D. 37BB
8. Which of the following is not a form of parallel processing?
A. SISD B. MIMD C. SIMD
9. In which of the following locations is information most readily available for manipulation by the CPU?
A. Cache memory B. Main memory
C. Mass storage D. General-purpose registers
10. The bus in a computer is an example of which form of communication?
A. Serial B. Parallel C. Neither A nor B
11. Which of the following instructions does not fall in the category of arithmetic/logic instructions?
A. ROTATE B. ADD C. OR D. JUMP
12. Which of the following instructions falls in the category of data transfer instructions?
A. LOAD B. AND C. ROTATE D. JUMP
13. Which of the following is not a component of a machine instruction?
A. Op-code B. Port C. Operand
14. Which of the following is not an activity performed entirely within a CPU?
A. Fetch instructions B. Perform Boolean operations
C. Perform arithmetic operations D. Move data between registers
15. What mask in register F would cause the instruction 8AAF (refer to the language description table) to
put a 0 in the most significant bit of register A without disturbing the other bits?
A. 11111110 B. 00000001 C. 10000000 D. 011111111
16. What mask in register F would cause the instruction 7AAF (refer to the language description table) to
put a 1 in the most significant bit of register A without disturbing the other bits?
A. 11111110 B. 00000001 C. 10000000 D. 011111111
17. Which of the following instructions will not produce the same result as the other two? (Refer to the
language description table.)
A. A502 B. A506 C. A50A
18. Which of the following instructions will not produce the same result as the other two? (Refer to the
language description table.)
A. 9555 B. 2500 C. 1500
19. If register A contained the pattern 00000000, which of the following instructions could alter the
contents of register 0? (Refer to the language description table.)
A. 700A B. 800A C. 900A
20. Which of the following instructions (as described in the language description table) is essentially an
unconditional jump?
A. B033 B. B133 C. B233 D. B333
21. Which step of the machine cycle examines the op-code of the next instruction to be executed?
A. Load B. Fetch C. Decode D. Execute
22. An ARM based processor is an example of what kind of computer architecture?
A. DSL B. CISC C. RISC D. Pentium
Fill-in-the-blank/Short-answer Questions
1. If register 0 contains the pattern 01101001 before executing the instruction A003 (see the language
description table), what bit pattern will be in register 0 after the instruction is executed?
____________
2. If registers 5 and 6 contain the bit patterns 5A and 58 respectively, what bit pattern will be in register 4
after executing the instruction 5456? (See language description table.)
____________
3. If registers 5 and 6 contain the bit patterns 5A and 58 respectively, what bit pattern will be in register 4
after executing the instruction 6456? (See language description table and assume a floating-point format in
which the most significant bit is the sign bit, the next three bits represent the exponent field in excess
notation, and the last four bits represent the mantissa.)
____________
4. Write the answer to each of the following logic problems.
10101010 10101010 10101010
AND 11110000 OR 11110000 XOR 11110000
5. Suppose registers E and F contained AA and CC, respectively. What bit pattern would be in register D
after executing each of the following instructions (see language description table)?
A. 7DEF __________
B. 8DEF __________
C. 9DEF __________
6. If registers 0, 1, and 2 contain the patterns A5, A5, and B7, respectively, which of the following
instructions will result in a jump to location AA? (Refer to the language description table.)
A. B0AA B. B1AA C. B2AA
____________
7. If registers 0 and 1 contain the patterns B5 and F0, respectively, what will be in register 1 after executing
each of the following instructions? (Refer to the language description table.)
A. A102 __________
B. 4001 __________
C. 4010 __________
8. Suppose the instruction B1A5 (as described in the language description table) is stored in main memory
at addresses E0 and E1. Moreover, suppose registers 0 and 1 both contain the pattern FF. What value will
be in the CPU’s program counter immediately after executing the instruction?
____________
9. Suppose the instruction B1A5 (as described in the language description table) is stored in main memory
at addresses E0 and E1. Moreover, suppose registers 0 and 1 contain the patterns FF and 75, respectively.
What value will be in the CPU’s program counter immediately after executing the instruction?
____________
10. Encode each of the following commands in terms of the machine language described in the language
description table.
A. __________ LOAD register 7 with the value A5.
B. __________ LOAD register 7 with the contents of the memory cell at address A5.
C. __________ ADD the contents of registers 5 and 6 as thought they were values in two’s
complement notation and leave the result in register 4.
D. __________ OR the contents of registers 5 and 6, leaving the result in register 4.
11. Encode each of the following commands in terms of the machine language described in the language
description table.
A. __________ ROTATE the contents of register 7 to the right 5 bit positions.
B. __________ JUMP to the instruction at address B2 if the content of register 2 equals that of
register 0.
C. __________ ADD the contents of registers 5 and 6 as thought they were values in floating–
point notation and leave the result in register 4.
D. __________ AND the contents of registers 5 and 6, leaving the result in register 4.
12. Decode each of the following instructions that were encoded using the language description table.
A. 4034 ___________________________________________________________
B. 8023 ___________________________________________________________
C. B288 ___________________________________________________________
D. 2345 ___________________________________________________________
13. Decode each of the following instructions that were encoded using the language description table.
A. A004 ___________________________________________________________
B. 1234 ___________________________________________________________
C. 5678 ___________________________________________________________
D. C000 ___________________________________________________________
14. The following table shows a portion of a machine’s memory containing a program written in the
language described in the language description table. Answer the questions below assuming that the
machine is started with its program counter containing 00.
address content
00 21
01 0B
02 14
03 04
04 C0
05 00
A. What bit pattern will be in register 4 when the machine halts?
___________
B. What bit pattern will be in register 1 when the machine halts?
___________
15. The following table shows a portion of a machine’s memory containing a program written in the
language described in the language description table. Answer the questions below assuming that the
machine is started with its program counter containing 00.
address content address content
00 10 07 00
01 02 08 C0
02 24 09 00
03 04 0A C0
04 B4 0B 00
05 0A 0C C0
06 C0 0D 00
A. What bit pattern will be in register 0 when the machine halts?
___________
B. What bit pattern will be in register 4 when the machine halts?
___________
C. What bit pattern will be in the program counter when the machine halts?
___________
16. The following table shows a portion of a machine’s memory containing a program written in the
language described in the language description table. Answer the questions below assuming that the
machine is started with its program counter containing 00.
address content address content
00 25 07 00
01 03 08 C0
02 20 09 00
03 F9 0A C0
04 53 0B 00
05 05 0C C0
06 33 0D 00
A. What bit pattern will be in register 5 when the machine halts?
____________
B. What bit pattern will be in register 0 when the machine halts?
____________
C. What bit pattern will be in register 3 when the machine halts?
____________
D. What bit pattern will be at memory location 00 when the machine halts?
____________
17. The following table shows a portion of a machine’s memory containing a program written in the
language described in the language description table. Answer the questions below assuming that the
machine is started with its program counter containing 00.
address content address content
00 25 07 00
01 03 08 34
02 A5 09 04
03 02 0A B0
04 35 0B 03
05 03 0C C0
06 24 0D 00
A. What bit pattern will be in register 5 when the machine halts?
____________
B. What bit pattern will be in the program counter when the machine halts?
____________
C. What bit pattern will be at memory location 04 when the machine halts?
____________
18. Below is a short routine written in the machine language described in the language description table and
stored in a machine’s memory beginning at address 50. What must be in the memory cell at address 40 to
avoid an unending loop?
Address Instruction
50 2001
52 1340
54 8330
56 B352
58 …
________________________________________
19. The following table shows a portion of a machine’s memory containing a program written in the
language described in the language description table. Answer the questions below assuming that the
machine is started with its program counter containing 00.
address content address content
00 B0 07 C0
01 03 08 00
02 25 09 23
03 B0 0A B0
04 0C 0B 03
05 C0 0C B0
06 00 0D 07
A. How many instructions will be executed before the machine halts?
____________
B. What bit pattern will be in the program counter when the machine halts?
____________
20. The following table shows a portion of a machine’s memory containing a program written in the
language described in the language description table. Answer the questions below assuming that the
machine is started with its program counter containing 00.
address content address content
00 20 07 12
01 02 08 B2
02 21 09 0C
03 01 0A B0
04 22 0B 06
05 01 0C C0
06 52 0D 00
A. What bit pattern will be in register 2 when the machine halts?
___________
B. How many times will the instruction at address 06 be executed before the machine halts?
___________
21. What is used to differentiate memory used for instructions and memory used for data?
22. What is the output from the following python statement?
print(bin(0b11001100 & 0b11110000)
23. What is the output from the following python statement?
print(bin(0b11001100 | 0b11110000)
24. What is the output from the following python statement?
print(bin(0b11001100 ^ 0b11110000)
24. Suppose a user enters 1.5 to the prompt of the following python program. What value will be printed
following the prompt?
PI = 3.14
radius = float(input(“Radius of a circle? “))
circumference = 2 * PI * radius
print(circumference)
25. Suppose a user enters 2 to the prompt of the following python program. What value will be printed
following the prompt?
PI = 3.14
radius = float(input(“Radius of a circle? “))
area = PI * radius**2
print(area)
ANSWER: 12.56
Vocabulary (Matching) Questions
The following is a list of terms from the chapter along with descriptive phrases that can be used to produce
questions (depending on the topics covered in your course) in which the students are ask to match phrases
and terms. An example would be a question of the form, “In the blank next to each phrase, write the term
from the following list that is best described by the phrase.”
Term Descriptive Phrase
op-code The part of a machine instruction that identifies the basic operation to
be performed
machine language A means of encoding instructions
machine cycle The process of fetching and executing instructions that is repeated
over and over by the CPU
register A location within a CPU for temporary data storage
masking A means of isolating particular bits within a bit pattern
bus The communication path between a CPU and main memory
memory-mapped I/O The technique of communicating with peripheral devices as though
they were memory cells
pipeling A means of processing more than one instruction at a time
instruction register Register whose contents is modified upon performing the fetch step of
the machine cycle
stored-program concept A technique of recording programs in main memory from where they
can be accessed and executed
program counter Used by the CPU to keep its place in the program being executed
main memory from where they can be retrieved and executed
controller The interface between “a computer” and a peripheral device
modem Modulator-demodulator
port The “connection” through which a CPU communicates with a
peripheral device
USB A communication system by which a variety of peripheral devices can
be connected to a computer
clock Used to synchronize the operations within a computer
status word A means by which a peripheral device reports its condition
bps A means of measuring the rate of data transfer
RISC A computer whose machine language contains a minimal set of
Instructions
cache High-speed memory located within the CPU which is used to retain a
copy of portions of main memory that is of current interest
handshaking Refers to the two-way communication that takes place between a
computer an a peripheral device
multi-core A computer processer architecture that provides true parallel processing
bandwidth Refers to a communication path’s maximum capacity for transferring
data
DMA The ability of a peripheral device to communicate directly with a
computer’s main memory
General Format Questions
1. Describe the machine cycle.
2. Explain the concept of throughput and techniques by which throughput is increased.
3. What is the difference between a conditional jump instruction and an unconditional jump instruction?
4. The following is a routine encoded in the machine language described in the language description table.
Explain (in a single sentence) what the routine does. (Explain what the entire routine does as a unit rather
than reciting what each instruction does.)
12A0
32B0
12A1
32B1
12A2
32B2
5. The following is a routine encoded in the machine language described in the language description table.
Explain (in a single sentence) what the routine does. (Explain what the entire routine does as a unit rather
than reciting what each instruction does.)
210F
12A0
8212
32A0
6. The following table shows a portion of a machine’s memory containing a program written in the
language described in the language description table. What will happen if the machine is started with its
program counter containing 00?
address content
00 21
01 B0
02 31
03 04
04 C0
05 00
7. Using the machine language described in the language description table, write a sequence of instructions
that will place the pattern FF in the memory cell at address A0.
8. Using the machine language described in the language description table, write a sequence of instructions
that will place a 1 in the most significant bit of the memory cell at address A0 without disturbing the other
bits.
9. Using the machine language described in the language description table, write a sequence of instructions
that will add five to the value (represented in two’s complement notation) stored at memory address A0.
10. Using the machine language described in the language description table, write a sequence of
instructions that will subtract one from the value (represented in two’s complement notation) stored at
memory address A0.
11. Using the machine language described in the language description table, write a sequence of
instructions that will shift the contents of the memory cell at address A0 three bit positions to the right
while filling the holes at the left end with 0s.
