Chapter Tests
and Problems
ChaPTer 18 Welding ProCesses
and rePresenTaTions TesT
INSTRUCTIONS
Answer the questions with short, complete statements or
drawings as needed.
QUESTIONS
For Questions 1 through 10, given the following welding sym–
bols with letters (a, b, c, etc.) pointing to various components,
identify the components related to each letter.
1. (in.)
2-6
e
f
a
b
c
d
3
8
2. (in.)
d
b
c
a
3
8
1
4
1
4
X
3. (in.)
a
b
c
1
21
16
4. (in.)
c
a
b
d
e
3
8
3
8608
G
608
5. (in.) e
c
b
a
d
1
16
3
8
308
6. (in.)
a
e
d
b
c
1
41
8
458
2
7. (metric)
bd
a
GTAW
c
e
(6)
10 mm
8. (metric)
c
ab
RSEW
4 mm
9.
a
b
c
DPT
MT
59728_ch18_EOC_ptg01.indd 1 03/02/16 10:35 am
11. Define field weld and show an example of the field weld
symbol.
12. List five types of weld joints.
13. Name four categories of the most common welding
processes.
14. Describe what is meant by arrow side, other side, and both
sides.
15. When is it possible to omit the weld size?
16. What are prequalified welded joints?
10. b
c
a
RT
308
59728_ch18_EOC_ptg01.indd 2 03/02/16 10:35 am
