CompTIA Network+ N10-007 Cert Guide
Chapter 11 Network Management
1) What is the name of the instrument pictured here?
A) Multimeter
B) Crimper
C) Pliers
D) Bit-error rate tester
2) When you are working with copper cabling (as opposed to fiber optic), a ________ can check
a variety of a cable's electrical characteristics.
A) loopback plug
B) protocol analyzer
C) toner probe
D) multimeter
3) Imagine that you have been troubleshooting a network cable (either copper or fiber optic), and
you determine that there is a break in the cable. What would you use to identify exactly where
the break exists?
A) Throughput tester
B) Punch-down tool
C) Toner probe
D) Time domain reflectometer
4) What does a throughput tester do?
A) Locate faults in a cable
B) Identifies which pair of wires connects back to an end user's location
C) Observes how a network performs under a heavy load
D) Prevents static discharge from damaging other components
5) What are the components of a SNMPv1 and SNMPv2c network management solution?
A) SNMP manager, SNMP agent, Management Information Base
B) SNMP agent, MD5, CBC-DES56
C) Management Information Base, SNMPv3, NMS, SNMP
D) SNMP application, SNMP manager, SNMP router
6) Which of the following is one of the three broad categories of SNMP message types?
A) SNMP GET, SNMP SET, SNMP trap
B) SNMP GET, SNMP SET, SNMP GO
C) SNMP Transmit, SNMP Receive, SNMP Capture
D) SNMP Message, SNMP Time, SNMP Date
7) What are the two primary components in a syslog solution?
A) Syslog transfers and syslog captures
B) Syslog messengers and syslog transmitters
C) Syslog servers and syslog clients
D) Syslog time stamps and syslog severity levels
8) Match the number with the letter. Match all the syslog severity level numbers and descriptions
with the name of the alert.
______ 1 Warnings
______ 2 Informational
______ 3 Emergencies
______ 4 Notifications
______ 5 Debugging
______ 6 Critical
______ 7 Alerts
______ 8 Errors
9) Which is not a log type in Windows Event Viewer?
A) Application log
B) Security log
C) System log
D) Syslog log
10) What kind of information would you find in an application log?
A) Information about software running on the OS
B) Information about applying for a job
C) Information about successful and failed login attempts
D) Information about events generated by the OS
11) What are the two primary functions of a BERT?
A) Pattern generator
B) Error detector
C) Throughput measurement
D) Cable certification
12) Which device is used by a technician needing to check a voice line, commonly by connecting
directly into the line at a distribution point?
A) BERT
B) Toner
C) Butt set
D) TDR
13) What is the name of the device that is used to ensure that a cable is able to support the
frequencies that it was installed to carry?
A) BERT
B) Toner
C) Butt set
D) Cable certifier
14) Which function of a multimeter is used to measure the resistance of a cable?
A) Ohmmeter
B) Voltmeter
C) Ammeter
D) Continuity checker
15) Which is an example of a protocol analyzer?
A) Nmap
B) Wireshark
C) Nessus
D) Sniffer
16) What is the name of the tool that is used to connect the individual conductors of a cable to a
66 or 110 block?
A) Compression tool
B) AMP tool
C) Punch-down tool
D) Crimper
8
17) What is the name of the tool is used to find a specific wire from one location to another
remote location (another office)?
A) Butt set
B) AMP tool
C) Punch-down tool
D) Toner probe
18) What is the name of the configuration management procedure that involves the collection of
information about a system under normal operating conditions, to be used as a comparison when
conditions are abnormal?
A) Baselining
B) Change management
C) Network documentation
D) Normalization
19) What type of encryption is used with SNMP Version 3?
A) AES
B) DES-56
C) SHA
D) RC4
20) What device is used to measure the magnitude of an input signal versus frequency within the
full frequency range of the instrument?
A) Time domain reflectometer
B) Spectrum analyzer
C) Throughput tester
D) Protocol analyzer
