COS20016: OPERATING SYSTEM CONFIGURATION
LAB 01
Lab 01: Computer Hardware Components
Objectives
By the end of this lab you should be able to:
• Identify different hardware components of a computer.
• Recognize different specifications and types of Major hardware component.
Please write the answer in your own words and do not copy and paste from the google.
Otherwise no mark will be given.
Task 1. Hardware Components
In this part, we will take a look at the inside of the PC case, as shown in Figure 1.
Figure 1: Inside a PC case
1.1 Find out and write down the main functionalities of the following hardware components.
Hardware
Component
Main Functionality
PSU
PSU – PSU provides computers low-voltage regulated dc power, for example
computer can still keep trade on time while its being switch off.
CPU
CPU – An CPU helps computers to carry out instructions of a computer
program.
Motherboard
Motherboard – Motherboard helps to connects all hardware together to
function properly.
RAM
RAM – A RAM is used to stores data that are currently being used, data that
are stored in a RAM will be erased when computer is switch off.
Graphics Card
Graphics Card – Graphics card helps computer to process graphic data then
display it on the monitor.
Optical Drive
Optical Drive – an optical drive is for users to insert CD, VCD or DVD to it
and run it.
[IMPORTANT] This lab should be completed individually.
COS20016: OPERATING SYSTEM CONFIGURATION
LAB 01
Hard Drive
Hard Drive – Is used to save data, data that are being saved in hard-drive will
not be erased even when computer is being switched off.
IDE Cable
IDE Cable – IDE cable are used to connect some hard drives and optical
drives to each other and also to the motherboard.
Task 2. Input and Output
2.1 In the table below, tick on the type of device (input or output), if neither, specify the type of the
device
Devices
Output
Other
(Specify)
Digital Camera
Digital Camera can
be a output or an
input devices. Take
pictures(Input),
send to
computer(output)
